MXL CR89 Manual

MXL Mikrofon CR89

Læs gratis den danske manual til MXL CR89 (2 sider) i kategorien Mikrofon. Denne vejledning er vurderet som hjælpsom af 38 personer og har en gennemsnitlig bedømmelse på 4.4 stjerner ud af 19.5 anmeldelser. Har du et spørgsmål om MXL CR89, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/2

Low-Noise

Condenser Microphone

A Division of Marshall Electronics

310-333-0606



800-800-6608



Fax: 310-333-0688

www.mxlmics.com



sales@mxlmics.com

Warranty

MXL microphones are guaranteed against defects in materials and workmanship

for one year from the date of purchase. If you encounter any problem with this unit,

promptly contact the company from which you purchased it for assistance. The

original dated sales receipt will be necessary for any warranty claim. Do not send

any unit directly to us without prior authorization from our service department.

Warranty coverage is limited to repair or replacement (at our option) of the

microphone, and does not cover incidental damages due to use of this unit, nor

damage caused by accidental misuse of this product.

Low Noise Condenser Microphone

Power Requirements

IMPORTANT - This unit requires phantom power at 48 volts, +/- 4 volts, in order to

operate. Each unit has been thoroughly checked before shipping, so if you do not

hear sound, check that the phantom power on your mixer or separate power supply is

switched on.

Microphone Cables

This microphone connects to a mixer or preamp via XLR cable (not included). The

microphone cable can have a profound effect on the sound of any microphone.

Even the nest microphones will sound poor if the interconnect cable allows noise

to enter, or causes distortion and loss of information. Use only the best microphone

cable your budget will allow. We recommend Mogami cable for the best results.

Thank you for choosing the MXL CR89 Condenser Microphone. For best results,

please take a few moments to read this manual and familiarize yourself with

proper operation and care of your microphone.

• MXL Cr89 microphone

• Shockmount

• Aluminum Flight case

• Microber Cleaning Cloth

Care

Dust and foreign material can degrade the performance of a microphone over time so always

store the unit in its case. For vocals closer than 3”, use a pop lter or a foam windscreen to

avoid getting moisture on the diaphragm as this can substantially degrade the microphone’s

performance. Store the microphone in its original packaging in a cool, dry place along with the

included packet of silica gel. These steps will help keep the mic in proper working order and

sounding its best for many years to come.

General Characteristics

The MXL Cr89 is a large diaphragm condenser microphone wrapped in sharply

contrasted black and chrome. The sound is every bit as bold as the body; the Cr89 can

handle subtle acoustic guitar tones and loud vocals with the same sonic integrity. The

Cr89 has low noise circuitry and a very low proximity effect, making it ideal for up-close

recording. At home on instruments and vocals, the Cr89’s body design minimizes body

resonance while the tuned grill cavity reduces standing waves and harmonic distortion.

Shockmount

The high isolation shockmount may shift during shipping. Simply shift the elastic bands to

center the microphone in the assembly. Be sure that the wire clamp does not rest on the

chassis of the mount, as this impairs mechanical isolation. Slide the shockmount up the

body of the microphone and stop just below the pad switch for the most secure hold.

Contents

Unpack your MXL Cr89 microphone carefully and verify that all of the following items

are included:

If any of these items are missing or damaged, contact the company from which you

purchased the microphone.

Type: ....................................................................Condenser microphone

Capsule: ...................................................................................................................................

32mm capsule with Gold-sputtered, 6 micron diaphragm

Frequency Response: ......................................................20 Hz – 20 kHz

Polar Pattern: Cardioid .....................................................................................

Sensitivity: -32dB re 1 V/Pat ..........................................................................

Impedance: ......................................................................................150 ohms

Max SPL for 0.5% THD: 138 dB SPL ...............................................................

S/N Ratio: ............................................... 80 dB (Ref. 1 Pa A-weighted)

Equivalent Noise Level: .................... 14 dB (A-weighted IEC 651)

Dynamic Range: 124dB ....................................................................................

Power requirements: .......................................48V Phantom power

Size and Weight: 64mm x 185mm / 2.5in. x 7.3in. 840g / 1.85lbs

Metal Finish: Black with black chrome accents .............................

Technical Specications

Frequency ChartPolar Pattern

Produkt Specifikationer

Mærke:	MXL
Kategori:	Mikrofon
Model:	CR89
