Side 1/2
Marshall Electronics
Professional Audio Division
Phone: 310-333-0606
800-800-6608
Fax: 310-333-0688
www.mxlmics.com
sales@mxlmics.com
V67N
Small Diaphragm
Thank you for choosing the MXL V67N Condenser microphone. With proper
care, this mic will provide many years of satisfaction. To get the best results,
please take a few moments to read this manual.
Enjoy your microphone!
The MXL Team
General Characteristics
This microphone includes two interchangeable capsules with
gold-sputtered diaphragms. One capsule is designed for a cardioid
pick-up pattern; the other capsule is designed for an omni-directional
pickup pattern. Condenser microphones are very sensitive, readily
revealing very subtle sonic details. They also tend to pick up sounds
outside the pattern more than some designs, which can lead to
powerful feedback if you are not careful. We strongly advise
experimentation with placement and isolation requirements with the gain
initially set low to avoid equipment (and ear) damage.
Contents
Unpack your MXL V67N microphone carefully and verify that all of the
following items are included:
• MXL V67N microphone
• Omni-directional capsule
• Hard mount mic stand adapter
If any of these items are missing or damaged, contact the company from
which you purchased the microphone.
Power Requirement
The MXL V67N requires 48V phantom power (± 4V). If no sound is picked
up by the microphone, make sure that the phantom power on your mixer
or separate power supply is switched on.
Microphone Cable
The microphone cable can have a profound effect on the sound of
any microphone. Even the finest microphone will sound poor if the
interconnect cable allows noise to enter or causes distortion and loss of
information. We recommend that you use the best microphone cable that
your budget will allow.
Care
Dust and foreign material can reduce the performance of a microphone
over time, so you should store the MXL V67N in its case when not in use.
Specifications
Type Pressure gradient condenser mic
Diaphragm 22mm Gold-sputtered, 6 micron
Frequency Response 20 Hz – 20 kHz
Polar Pattern Cardioid/Omni
Impedance <300 ohms
Sensitivity -49dB re 1 V/Pa
S/N Ratio 78 dB
Equivalent Noise -16dBA (A weighted IEC 651)
Max SPL for 0.5% THD 148dB SPL
Power Requirement 48V Phantom Power (+/- 4V)
Current Consumption 5.2mA
Size 124mm x 23mm
Weight 0.2 lbs
Metal Finish Green with gold grill
Polar PatternFrequency Chart
Warranty
Marshall microphones are guaranteed against defects in materials and
workmanship for one year from date of purchase. Should you encounter
any problem with this unit, promptly contact the company from which
you purchased it from for assistance. The original dated sales receipt
will be necessary for any warranty claim. Do not send any unit directly
to us without prior authorization from our service department. Warranty
coverage is limited to repair or replacement (at our option) of the
microphone, and does not cover incidental damages due to use of this
unit, nor damage caused by accidental misuse of this product.
0
90270
180
Omni
Card idio
SS100416a
