Thank you for choosing the state of the art
Genesis microphone from MXL
®
.
Your new Genesis microphone was designed and
engineered in the USA by our world class team of
electrical and audio engineers, and is built for the
most critical sound applications. As the agship of
the MXL
®
product family, the Genesis exhibits a
warmth and intimacy previously only found in
microphones costing many times more.
The MXL
®
Genesis features individually selected
components, chosen for their superior sonic capabilities.
One of the key components is the Mullard 12AT7 tube,
which is universally accepted as one of the most musical
tubes available. Your Genesis will provide many years
of outstanding service, and will always ensure you get
the nest quality recordings attainable.
To assist you in obtaining the best possible results
from your MXL
®
Genesis microphone, we have
provided some tips, tricks and answers to
commonly asked questions.
We encourage you to review these materials.
1
10
GENESIS Specs
Type: Vacuum Tube Studio Condenser
Microphone
Tube Type: Mullard 12AT7 or equivalent
Diaphragm: 6 micron gold-sputtered
Frequency Response: 20 Hz – 20 kHz
Polar pattern: Cardioid
Output Impedance: 200 ohms
Pre-Attenuation Switch: 0 dB, -10 dB
High Pass Filter: 6 dB/octave @ 150 Hz
Equivalent noise: 18db (A-weighted IEC 268-4)
S/N Ratio: 78dB (Ref. 1Pa A-weighted)
Max SPL for .5% THD: 130 dB/140 dB (0dB, -10 dB pad)
Power Requirements: Dedicated power supply
Size: 59mm x 240mm
Weight: 1.55 lbs.
Metal Finish: Red with Gold Grill
Warranty
Marshall microphones are guaranteed against defects in material and
workmanship for three years (except tube which is 90 days) from date of
purchase. Should you encounter any problem with this unit, promptly contact
the company you purchased it from for assistance. The original dated sales
receipt will be necessary for any warranty claim. Do not send any unit directly
to us without prior authorization from our service department!
Warranty coverage is limited to repair or replacement (at our option) of the
microphone, and does not cover incidental damages due to use of this unit,
nor damage caused by accidental misuse of this product.
