Side 1/2

Marshall Electronics

Professional Audio Division

Phone: 310-333-0606  800-800-6608 Fax: 310-333-0688

www.mxlmics.com sales@mxlmics.com

LSM-5GR

Dynamic Microphone

Thank you for choosing the MXL LSM-5GR Dynamic microphone. With

proper care, this mic will provide many years of satisfaction. To get the best

results, please take a few moments to read this manual.

Enjoy your microphone!

The MXL Team

General Characteristics

This microphone is a cardioid dynamic microphone. This microphone

incorporates a high end boost for clear, crisp performances. For a warmer,

richer tone, the MXL LSM-7GN is available. The LSM-5GR microphone

was designed primarily as a vocal microphone for on-stage use. The term

“cardoid response” means that the LSM-5GR is most sensitive to sound

arriving from the front, and less sensitive to sound from the rear and sides.

Rugged construction and a steel mesh grill ensure the LSM-5GR will

perform consistently in nearly all environments. the LSM-5GR features

a standard 3-pin male XLR type connector. The microphone can be

connected to the rest of your equipment using a standard microphone

cable ﬁtted with a female 3-pin type XLR collector.

Contents

Unpack your MXL LSM-5GR microphone carefully and verify that all of the

following items are included:

• MXL LSM-5GR microphone

• Hard mount mic stand adapter

If any of these items are missing or damaged, contact the company from

which you purchased the microphone.

Microphone Cable

The microphone cable can have a profound effect on the sound of

any microphone. Even the ﬁnest microphone will sound poor if the

interconnect cable allows noise to enter or causes distortion and loss of

information. We recommend that you use the best microphone cable that

your budget will allow.

Care

Dust and foreign material can reduce the performance of a microphone

over time, so you should store the MXL LSM-5GR in its case when not in

use.

Speciﬁcations

Type Dynamic

Frequency Response 40Hz-15kHz

Polar Pattern Cardioid

Impedance 600 ohms

Sensitivity -54dB re 1 V/Pa

Size 7.09in x 1.93in /180mm x 49mm

Weight 0.61 lbs/277g

Metal Finish Gray

Polar PatternFrequency Chart

Warranty

Marshall microphones are guaranteed against defects in materials

and workmanship for three years from date of purchase. Should you

encounter any problem with this unit, promptly contact the company

from which you purchased it from for assistance. The original dated sales

receipt will be necessary for any warranty claim. Do not send any unit

directly to us without prior authorization from our service department.

Warranty coverage is limited to repair or replacement (at our option) of the

microphone, and does not cover incidental damages due to use of this

unit, nor damage caused by accidental misuse of this product.

90270

180

Produkt Specifikationer

Mærke:	MXL
Kategori:	Mikrofon
Model:	LSM-5GR
Type:	Mikrofon til interview
Vægt:	295 g
Produktfarve:	Grå
Frekvensområde:	40 - 15000 Hz
Forbindelsesteknologi:	Ledningsført
Plug and play:	Ja
Mikrofonindgangsimpedans:	600 ohm (Ω)
Mikrofonretningstype:	Kardioid
Mikrofon sensitivitet:	54 dB
