C
ongratulations on your purchase of the MXL uChat. The MXL uChat connects to your
computer’s USB port to give you two-way conferencing over the internet via Skype
™
,
AIM, iChat and other web conferencing software programs. The MXL uChat also includes a
high quality electromagnetic speaker that can replace bulky computer speakers and delivers
outstanding sound quality. Please read the following instructions carefully so you can
experience the maximum benets of this product.
Please note! MXL microphones are the result of world-class engineering and manufacturing capabilities and
are designed to provide you with outstanding performance and exceptional value. Although Marshall MXL
has tested the following applications at the time of manufacture, quality or results may vary by end user.
R
Introduction
Getting Started
Minimum requirements:
►
PC or Mac with USB audio input
►
Windows XP Home/Professional
►
Windows Vista
►
Mac OSX 10.1 or later
►
Web Conferencing software
Getting Started
In order to use the MXL uChat, you will
need to have web conferencing software
like Skype
™
, AIM, or iChat installed on
your computer. Many of these applications
are free or low cost. Check the appropriate
websites to download the latest version.
2
Setup
This microphone/speakerphone is a USB
(Universal Serial Bus) device, meaning
it’s a plug and play microphone that will
interface with Windows and Macintosh
computers without the need for any special
drivers. The MXL uChat will operate with
both USB 2.0 (high speed USB) and USB 1.1
data buses. We recommend connecting your
microphone directly to the computer’s USB
port as opposed to using a USB hub as USB
hubs can interfere with the performance of
various USB devices.
In addition to the USB input, the MXL uChat
includes a headphone output jack for private
conversations and an extension jack that can
be used for additional microphones in a panel
setting or to increase your degree of coverage.
The MXL uChat also includes a handy mute
button so your side of the conversation can be
quickly muted.
When headphones are plugged into the
MXL uChat the speaker automatically
mutes. The speaker will regain function as
soon as the headphones are unplugged.
The headphone jack accepts most head-
phones; however, the maximum headphone
volume will vary by manufacturer and
model so care should always be exercised
when rst plugging in your headphone.
USB
Input
Extension
Mic Input
Headphone/
line output
