Warranty

Marshall microphones are guaranteed against defects in material and workmanship for Three years from date of

purchase. Should you encounter any problem with this unit, promptly contact the company you purchased it from

for assistance. The original dated sales receipt will be necessary for any warranty claim. Do not send any unit

directly to us without prior authorization from our service department!

Warranty coverage is limited to repair or replacement (at our option) of the microphone, and does not cover inci-

dental damages due to use of this unit, nor damage caused by accidental misuse of this product.

Congratulations on your purchase of the MXL V67i Dual Capsule Cardioid Condenser microphone. MXL

microphones are the result of world-class engineering and manufacturing capabilities. They are designed to

provide you with outstanding performance and exceptional value. A high quality studio microphone is one

of the essential tools in any musician’s equipment arsenal. To help you obtain the best results from your new

purchase, we encourage you to take a few minutes to review this owners’ manual and the accompanying

MXL applications guide.

A Little Background Information

MXL condenser microphones use what is known as a cardioid pickup pattern, which is more sensitive

to sound waves arriving at the front of the microphone as opposed to those arriving from the sides or

rear. The V67i is unique in that it has two capsules and, hence, two front sides - Bright and Warm.

Cardioid microphones make an excellent choice for many recording applications. While there are no

hard and fast rules for microphone positioning, the setups in the included applications guide are a good

place to begin as they work well in many recording situations - though we encourage you to experiment.

While the included microphone clip will serve you well in many recording environments, we nonethe-

less recommend you consider using a shockmount with your microphone - particularly if you nd your

V67i is picking up oor noises that are transmitted through the microphone stand. Shockmounts de-

couple the microphone from the micstand and the environment. With a shockmount, you minimize oor

noise as well as any noise induced by people handling the microphone stand. In professional recording

studios, shockmounts are considered “standard equipment” for all recording applications. MXL has a

shockmount available for your V67i.

Exercise care while handling your microphone. Your microphone’s capsules are the “crown jewels” of

the instrument. Avoid jarring or dropping the microphone. These vibrations - including tapping on the

microphone to “test” its operation - can cause damage to the capsules and other electronics. You should

also protect the capsules from wind. Avoid testing the microphone by blowing into it. If you nd your-

self recording an outdoor performance, you would be well advised to use a windscreen as protection for

your microphone.

The V67i features a solid state preamp with balanced transformer output. As a condenser microphone,

the V67i requires 48Volt Phantom Power and will not operate without external power.

As a matter of fact, your MXL V67i is internally wired with Mogami cable. For additional information

on Mogami cable, please visit www.mogamicable.com

Understanding the V67i: Basic Operation

As you already know, the MXL V67i is unique in that it has two capsules. Designed to provide you with

a versatile instrument capable of addressing a wide range of studio applications, the V67i is like having

two mics in one - with the front side having a warm, lush sound, and the microphone’s back side simu-

lating some of the brighter sounding vintage capsules characteristic of early 60s tube microphones.

Switching Capsules (and knowing which one is active)

As you look at the front of the V67i (the side with the MXL logo and the microphone’s name), there is

a Warm/Bright (Wm/Brt) switch located on the upper-most part of the microphone’s green body. This

switch enables you to select the capsule you prefer.

Located directly above the V67i’s Wm/Brt switch, you’ll notice “Wm” is labeled on the gold ring that

secures the microphone’s protective grill. Similarly, there is a “Brt” identier on the opposite (back)

side of the ring. These labels identify the V67i’s two capsules. Further, there is a RED LED for each

capsule located inside the microphone grill at the base of the capsules. Depending upon which capsule

is active, you will see the lit LED as you face the side of the microphone that is currently engaged.

CAUTION – Always lower your volume levels when switching capsules, otherwise, speaker or head-

phone damage could occur.

The V67i’s Attenuation and Low Frequency Roll-Off Switches

You will nd the V67i’s Attenuation and Low Frequency Roll-Off switches located on the back side of

the microphone along the upper-most part of the instrument’s green body. For best results, you should

experiment with these settings.

The Low Frequency Roll-Off switch is identied with two markings: and

When in the position, the low frequency roll-off switch enables the V67i to compensate for

proximity effect or to eliminate wind noise during outdoor recording.

The Attenuation switch is identied with two markings: and ─6. When in the ─6 position, the

V67i is optimized for handling high sound pressure levels (SPL).

Using the Supplied Microphone Clip

1. Secure the microphone clip to your microphone stand. On the microphone clip, you will nd an ad-

justment for angling the position of the microphone. Angle the clip so the ring is horizontal and parallel

to the oor.

2. Holding the microphone upright and rmly in one hand, unscrew and remove the black knurled ring

that secures the microphone’s base.

3. Holding the microphone upright in one hand, place the microphone into the “cup” portion of the mi-

crophone clip and then tighten the black knurled ring back onto the base of the microphone. Your V67i

is now supported by the microphone clip.

For More Information

For additional information about your MXL V67i, how to contact technical support, as well as informa-

tion on other products manufactured by MXL, please visit us online at www.mxlmics.com.

Unpack Your Microphone

Begin by examining the contents of your MXL V67i system.

You should have the following components: • One V67i microphone

• Microphone clip (this holds the microphone)

• Protective microphone pouch

• Protective wooden box

A Few Words About the Microphone Cable

While the MXL V67i is an excellent transducer - capturing and converting acoustical energy into

electrical energy that devices such as recorders can understand - the cable that carries the microphone’s

output into your mixer and other equipment is equally important. For best results, we encourage you to

use a high quality XLR cable of suitable length for use in your particular recording environment. MXL

recommends Mogami cable, as this is the choice of professional recording studios everywhere.
