Side 1/2
1. PREPARATION BEFORE ASSEMBLY
I. Check Contents- Unpack your PKWFD04 Water System to
check the contents to ensure the unit contains all the
components listed on page 2 of this user's guide.
II. Prep Micro-Ceramic Filter Dome- Soak the Micro-
Ceramic Filter Dome in a clean cool water for about 15 to 30
minutes. Then scrub rmly on the dome on all sides with a
brush or scouring pad under cool running water.
Ill. Prep Multi-Stage Filter Cartridge- Rinse the Multi-Stage
Filter Cartridge under cool running water for 10 to 15 minutes
to ush out loose sediments. Make sure the water that comes
out from the bottom of the lter is clean and clear of any
debris before rst use.
IV. Prep MineralStones- Take the mineral stones out of the
Mineral Stone Case. Place the case upside down and look for
the seam around the edge. Use a knife with a round tip or
small at screw driver, place it at the seam and push rmly all
the way down to pry open the bottom cover. Take the mineral
stones out of the case and rinse thoroughly. Then place the
stones in a pot and boil in water for about 10 minutes. Drain
the stones and allow to air dry thoroughly. Wash and dry the
plastic case thoroughly. The cleaned mineral stones can Note:
be used with or without the plastic case. If used without the
case, the stones can be scattered loose at the bottom of the
Bottom Tank.
V. Clean the Tanks- Wash the Top Tank and Bottom Tank with
mild detergent. Rinse and dry thoroughly.
14
The PKWFD04 Water System mimics the process of a mineralspring,
transforming your ordinary tap water into pure, clean, great-tasting drinking
water the way Mother Nature intended.
5. FAQS
Q: Why does it take so long for the water to drain from the top tank?
A: The ceramic dome is possibly clogged with ceramic dust, sediment or other
particles. Remove the dome from the top tank and soak in coolclean water for 30
minutes. Then scrub rmly with a brush or scouring pad on allsides. Remember
to clean the ceramic dome regularly.
Q: What can I do when oat valve is too large to t into my dispenser?
A: If the oat valve is too large (Dispenser model only), you will need to remove the
bottle support collar from the dispenser. Hold the bottle support collar
dispenser, twist it counter-clockwise by about one inch (or until it clicks) and
pull it o. The bottle support collar is removable on alldispenser models for
cleaning purposes.
Q: Why is my Zen Water System leaking?
A: If the leak is around the spigot (Countertop model only), tighten the nut
clockwise by a quarter turn. Test for leak again. If leak persists, tighten the nut by
another quarter. Repeat until leak stops. Do not over-tighten the nut as it may
damage the tank. If the system is leaking from where the top and the bottom
tank connect, empty the top tank because the bottom tank is overow. Fillthe
top tank with only the amount of water that the bottom tank has space to store.
Q: Where can I order lters?
A: Replacement lters can be purchased at www.NutrichefKitchen.com.
Q: Is the plastic BPA free?
A: The plastic tanks are made from styrene acrylonitrile which is free of BPA.
32
3. BEFORE FIRST USE
Check for leaks around the spigot (Countertop model only). If there’s a leak,
simply tighten the nut by one quarter turn. Test for leak again. If there’s still a
leak, tighten nut by another quarter turn. Repeat until the leak stops.
Allow one to two full upper tanks to filter through lower tank before
consumption. Discard the first two tanks of water.
The first couple of tanks may take up a few hours to completely filter through
the cycle. As the ceramic and mineral loosen up, the filter cycle time will
gradually decrease. (See FAQs on page 4 if it takes longer than 5 to 7 hours to
drain the first tank).
4. CARE & MAINTENANCE
IMPORTANT
• Do not place or expose unit under direct sunlight. Extended exposure to direct
sunlight may result in formation of moss/algae.
• Do not use PKWFD04 Water System with water that is micro biologically unsafe or
of unknown quality without adequate disinfection before or after the system.
• Do not use detergent to wash any filters or parts (unless specified in instructions).
• Do not overflow either the top tank or the bottom tank.
• Hot water should not be used in PKWFD04 Water System
(Max 85˚F / 29˚C–Min 30˚F/0˚C).
FILTER REPLACEMENT & ROUTINE MAINTENANCE
• MICRO-CERAMIC FILTER DOME
Replace every 1 year or 1,000 gallons whichever comes first
Scrub and clean every 2 to 4 weeks or as frequently as necessary
• 5-STAGE MINERAL FILTER CARTRIDGE
Replace every 6 months or 500 gallons whichever comes first
• MINERAL STONE CASE
Boil mineral stones every 6 months to re-activate mineral properties
Replace every 3 to 5 years or when mineral stones are noticeably eroded
• TOP AND BOTTOM TANKS
Wash every 3 months or as frequently as necessary
Please visit www.NutrichefKitchen.com for a complete Filter Replacement and
Maintenance schedule
2. ASSEMBLY
Countertop Model
(4G-MP, 6G-MP, 8G-MP)
Starting from the bottom…
1. Insert water faucet through lower tank with 1
silicone ring on the outside and 2 silicone ring
inside the lower tank
Tighten water faucet with nut.
2. Place cleaned mineral stones inside the bottom
tank. Place the bottom tank inside the base.
3. Place middle ring on the bottom bank.
4. Screw 5-stage mineral filter cartridge onto
cartridge ring. Place assembly onto middle rin
5. Un-screw wing nut and silicone rings from the
stem of the ceramic filter dome. Insert the stem
of the ceramic filter dome through the top tan
with one silicone ring on each side of the tank
Tighten dome with nut.
6. Place the top tank on top of the middle ring.
Cover with lid.
Dispenser Model
(4G-WB)
Starting from the bottom…
1. Remove silicone rings and nut from the float
valve. Insert anti-spill device through hole in
the bottom tank with one silicone ring on
each side of the tank.
2. Place the bottom tank onto your water cooler or
dispenser. (If anti-spill device is too large to fit
into dispenser, see FAQs on page 4.)
3. Place the cleaned mineral stones inside the
bottom tank.
4. Place middle ring on the bottom tank.
5. Screw 5-stage mineral filter cartridge onto
the cartridge ring.
Place assembly onto the middle ring.
6. Un-screw the wing nut and silicone rings from
the stem of the ceramic filter dome. Insert the
stem of ceramic filter dome through the top tank
with one silicone ring on each side of the tank.
Tighten dome with nut.
7. Place upper tank on top of the middle ring. Cover with lid.
1. LID
2. UPPER TANK
3. MIDDLE BASE
4. DOME CERAMIC
5. CARTRIDGE FILTER
6. MINERAL STONE
7. LOWER TANK
8. WATER FAUCET
9. BOTTOM BASE
