Side 1/1

V1. JUNE , 23, 2015

(FIG B)

MICRO_USB

CABLE

CHARGING DOCK

TWIST TO REMOVE

HOLD

LOW MED HIGH

STROBE

3 x CLICKS

(FIG A)

1 x CLICK

HOLD

2 x CLICKS

MOONLIGHT

OFF

TURBO

2 x CLICKS

STROBE

3 x CLICKS

TURBO

BATTERY AND SAFETY WARNINGS:

DANGER:

• The pre-installed battery is specially designed for the S30R

BATON II. Please do not unload the pre-installed battery or apply

it to other products.

• Do not turn the light directly to human eyes, otherwise it will

cause blindness for seconds or hurt the eyes permanently.

WARNING:

• Do not use the turbo mode continuously when the environmen-

tal temperature is high,in case the flashlight body is too hot to

hold.

• Read user manual carefully when the inserted battery need to

be replaced, ensure battery is inserted with the negative (-) end

pointing to the head of flashlight (LED side) . If the light is about

to be put aside for a long time or be transported, please unscrew

the tail cap lightly to cut off the circuit of electricity.

NOTICE:

• Please keep the charging dock clean, and wipe it with cotton

fabric dipped in alcohol before charging.

• The extended USB port on the charging dock is designed for

data transmission for cell phones or other digital products, the

charging dock won’t work if the current of input load is more than

1000 mA.

• The flashlight is able to be powered by user’s 18650 or CR123A,but

charging is unavailable.

Technical Support Inquiries

techsupport@olightworld.com

Customer Service

cs@olightworld.com

Visit www.olightworld.com to see our

complete product line of portable

illumination tools.

MADE IN CHINA

WARRANTY

Within 30 days of purchase: Return to retailer

from which you purchased for repair or replacement.

Within 5 years of purchase: Return to Olight for

repair or replacement.

This warranty does not cover normal wear and tear,

modifications, misuse, disintegrations, negligence,

accidents, improper maintenance, or repair by anyone

other than an Authorized retailer or Olight itself.

INSIDE THE BOX

S30R Baton

Ⅱ

, (2) o-rings, charging dock, Micro-USB

cable, rechargeable 18650 battery, user manual

Thank you for purchasing the Olight S30R Baton

Ⅱ

flashlight! Please read this manual carefully before

using this product.

S30R BATON

RECHARGEABLE VARIABLE-OUTPUT SIDE-SWITCH

LED FLASHLIGHT

USER MANUAL

FLASHLIGHT SPECIFICATIONS

OUTPUT & RUNTIME

STROBE

LED

VOLTAGE

CANDELA

BEAM DISTANCE

BATTERY TYPE

BODY TYPE

WATERPROOF

IMPACT RESISTANCE

DIMENSIONS

WEIGHT

10HZ

CREE XM-L2

3.0V TO 8.4V

9,600 cd

196 meters/ 643 feet

1 x 18650 (included)

TYPE-III HARD ANODIZED ALUMINUM

IPX8

1.5 meters

L 117.5mm x D 26mm / 4.65 x 1.02 in

128g / 4.52 oz (with battery)

All performance claim to ANSI/NEMA FL1-2009 standard.

PRODUCT PARTS

CHARGEING-DOCK SPECIFICATIONS

WEIGHT

INPUT

CHARGING CURRENT

DIMENSIONS

24g / 0.85 oz

DC 5V

4.2V, 1000mA

55 x 50 x 16mm / 2.17 x 1.97 x 0.63 in

SIDE SWITCH

CHARGING PORT

POCKET CLIP

HOW TO OPERATE

Please screw the tailcap tightly at the first use.

ON/OFF: single click the side switch. The flashligt

always turn on at the last output modes.

CHANGE BRIGHTNESS LEVEL (FIG A)

Press and hold the side switch ,the brightness levels

will cyclely repeat the loop of low – medium – high,

reelease the switch at the desired levels.

MOONLIGHT: from off status, press and hold the

side switch for 1 second to activate moonlight mode,

or directly turn the light on by singly clicking the side

switch if the previous modes is moonlight.

TURBO MODE: double click the side switch to

activate turbo mode, double click again return to the

last output mode.

STROBE MODE: triple click the side switch to

activate the strobe mode, other operation on the

switch will deactivate the strobe mode.

BATTERY CHARGING: (FIG B)

To charge the flashlight, place the flashlight on the top of

charging dock, then connect the charging dock to a USB

power supply or computer USB port. The charging

indicator will light turn red when charging start. When the

flashlight is fully charged the charging indicator will turn

green.

SUPPORTED BATTERIES

• 1 x 18650 Lithium-Ion battery (included)

TURBO

Please maintain the flashlight

charging port clean

HIGH

MED

LOW

MOONLIGHT

3200mAh

Battery

3600mAh

Battery

110

1020

600

LUMENS

MIN

120

1020

600

LUMENS

MIN

450

LUMENS

160

MIN

100

LUMENS

HRS

LUMENS

HRS

LUMENS

DAYS

450

LUMENS

180

MIN

100

LUMENS

HRS

LUMENS

HRS

LUMENS

DAYS

EXTENDED USB PORT

INDICATOR

CHARGING PORT

MICRO-USB

INPUT

LOW POWER

INDICATOR

BATTERY REPLACEMENT

If the pre-installed rechargeable battery runs out of power,

user can insert other batteries such as 2×CR123A or

1×18650 with protection board into the light.
