Side 1/8

AIRLESS PAINT

SPRAYER

650W

INSTRUCTION MANUAL

SPECIFICATIONS

Input Power: 650W

Voltage: 230-240V ~ 50Hz

Max. Pressure: 3000psi (21MPa)

Max. Flow Rate: 1.09±10% l/min

Spray Tip Size: 515

Outlet Paint Connector: 1/4-18NPSM

Max. Hose Pressure: 12000psi (83MPa)

High Pressure Hose: 7.6m

Full-load Current: 2.0~3.1A

Short Circuit Rating: 5kA

Paint Temperature: 5~40°C

Weight: 7.69kg

ASG-6000

WHAT’S IN THE BOX

Airless Sprayer

IN ORDER TO MAKE A CLAIM UNDER THIS

WARRANTY YOU MUST RETURN THE PRODUCT

TO YOUR NEAREST BUNNINGS WAREHOUSE WITH

YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO

RETURNING YOUR PRODUCT FOR WARRANTY

PLEASE TELEPHONE OUR CUSTOMER SERVICE

HELPLINE:

Australia 1800 069 486

New Zealand 0508 069 486

1 YEAR REPLACEMENT WARRANTY

Your product is guaranteed for a period of 12 months from

the original date of purchase. If a product is defective it will

be replaced in accordance with the terms of this warranty.

Warranty excludes consumable parts, for example: carbon

brushes, chuck, depth rod, chuck key, auxiliary handle.

WARNING

The following actions will result in the warranty being void.

• If the tool has been operated on a supply voltage other

than that speciﬁed on the tool.

• If the tool shows signs of damage or defects caused

by or resulting from abuse, accidents or alterations.

• Failure to perform maintenance as set out within the

instruction manual.

• If the tool is disassembled or tampered with in any way.

WARRANTY

TO ENSURE A SPEEDY RESPONSE PLEASE

HAVE THE MODEL NUMBER AND DATE OF

PURCHASE AVAILABLE. A CUSTOMER SERVICE

REPRESENTATIVE WILL TAKE YOUR CALL

AND ANSWER ANY QUESTIONS YOU MAY

HAVE RELATING TO THE WARRANTY POLICY

OR PROCEDURE.

OZITO Australia/New Zealand (Head Ofﬁce) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.

The beneﬁts provided under this warranty are in addition

to other rights and remedies which are available to you at law.

Our goods come with guarantees that cannot be excluded

at law. You are entitled to a replacement or refund for a major

failure and for compensation for any other reasonably foreseeable

loss or damage. You are also entitled to have the goods repaired

or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure.

Generally you will be responsible for all costs associated with

a claim under this warranty, however, where you have suffered

any additional direct loss as a result of a defective product you

may be able to claim such expenses by contacting our customer

service helpline above.

ozito.com.au

High Pressure Hose

Hex Key and Spanner x 2

Cleaning Brush

Fine Needle x 3

0517

Spray Gun

ONLINE MANUAL

Scan this QR Code with your

mobile device to take you to

the online manual.

KNOW YOUR PRODUCT SETUP & PREPARATION

1. ASSEMBLY

1 Pressure Control Dial

2 Stand

3 Return Pipe

4 Paint Outlet

5 Filter

6 Inlet Hose

7 Priming Lever

8 On/Off Switch

9 Carry Handle

AIRLESS SPRAY GUN

2 Reposition pump on frame,

so legs face backwards.

Reconnect pump to frame

with four bolts.

1 Remove four bolts from

frame.

Hose Connection

Frame Connection

1 Connect high pressure

hose to paint outlet and

tighten.

2 Connect other end of hose

to gun swivel and tighten.

10 Nozzle Tip

11 Spray gun

12 7.6m High pressure hose

13 Spray Gun Filter

14 Spanner x 2

15 Hex Key

16 Fine Needle x 3

17 Cleaning Brush

3 Ensure all connections have been correctly tightened with a

19mm spanner.

4 Connect the inlet hose

and return pipe to the

back of the unit. Secure

the return pipe by

releasing the tabs on the

hose clamp.

5 Secure inlet hose by

tightening screw on hose

clamp with a at head

screwdriver.

WARNING! ENSURE THE TOOL IS DISCONNECTED

FROM THE POWER SUPPLY BEFORE PERFORMING

ANY OF THE FOLLOWING OPERATIONS.
