*SHIPPING

WEIGHT

MINIMUM

12 (.3)

18 (.460

22.25 (.57)

34.25 (.87)

46.25 (1.17)

58.25 (1.48)

70.25 (1.78)

82.25 (2.09)

94.25 (2.39)

106.25 (2.70)

118.25 (3)

*SHIPPING

WEIGHT

MAXIMUM

18 (.46)

24 (.61)

34.25 (.87)

58.25 (1.48)

70.25 (1.78)

82.25 (2.09)

94.25 (2.39)

106.25 (2.70)

118.25 (3)

130.25 (3.31)

142.25 (3.61)

*SHIPPING

WEIGHT

MODEL#

ADD012018

ADD018024

ADD0203

ADD0305

ADD0406

ADD0507

ADD0608

ADD0709

ADD0810

ADD0911

ADD1012

MODELS: ADD012018, ADD018024, ADD0203, ADD0305, ADD0406, ADD0507, ADD0608, ADD0709, ADD0810, ADD0911, ADD1012

SPECIFICATIONS

..attached to

round beam.

..attached to

I-beam.

Multi-Display Carousel models

MD220, MD320, MD390, MD420,

MD520, MD620, MD227, MD297,

MD327, MD397, MD427, MD527,

MD627

CEILING

BALANCED MAXIMUM LOAD CAPACITY for all

Extension Columns for Multi-Display Mounts: 800 lb (363 kg)

Shipping weight based on single unit shipment.

Per unit shipping weight may be less for bulk orders.

Balanced Maximum Load Capacity includes the combined weight

of the Multi-Display Carousel or Dual Jumbo Mount (page 2) and all

equipment (TVs and VCRs). All TVs and VCRs must be of the

same model for proper balance/stability.

Extension

Column

*SHIPPING

WEIGHT

lb (kg)

4.5 (2)

3 (1.4)

8 (3.6)

9.8 (4.4)

13 (5.9)

16.5 (7.5)

18 (8.2)

19.5 (8.8)

21 (9.5)

22.5 (10.2)

28 (12.7)

Peerless Industries, Inc.

3215 W. North Ave. phone: (708) 865-8870

Melrose Park, IL 60160 fax: (708) 865-2941

ISSUED: 8-25-94 SHEET NO:139-9507-3 8-19-03 page 1 of 2

TECHNICAL DATA SHEET

EXTENSION COLUMN FOR MULTI-DISPLAY

MOUNTS

Protected by U.S. Patent no. 5127617 and 5487524. International patents pending.

Truss Ceiling Decoupler

model DCT300...

Structural Ceiling

Decoupler model DCS400

Multi-Display Carousels, Multi-Display Dual

Jumbo Mounts, Structural Ceiling Decoupler, and

Truss Ceiling Decoupler are sold separately. For

additional information see Technical Data Sheets

for these products.

The Extension Column for Multi-Display Mounts

is one of three elements required for Multi-

Display Ceiling Mount installations. It is available

in several lengths which are adjustable at 1"

increments (see specifications, above right).

See page 2 for

Multi-Display Dual

Jumbo Mounts

Architects specifications:

The extension column shall be a Peerless model ADD_____ . It shall offer a ___ inch

range of height adjustment at 1" increments. It shall be constructed of steel tubing and

finished in scratch resistant black fused epoxy. It shall be UL Listed. Assembly and

installation shall be done according to the instructions provided by the manufacturer.

4.5" (114mm)

5.3" (135mm)

4.7" (119mm)

8.8" (224mm)

*SHIPPING

WEIGHT

lb (kg)

5 (2.3)

5.5 (2.5)

8.2 (3.7)

13.3 (6)

16 (7.3)

21 (10)

22 (11)

24 (11)

26 (12)

30.3 (13.7)

34 (15.4)

LENGTH (L) - adjustable at

1"increments

in. (meter)

Produkt Specifikationer

Mærke:	Peerless-AV
Kategori:	Flad panel støtte
Model:	ADD106
Højde:	1900 mm
Vægt:	6500 g
Produktfarve:	Sort
Kontroltype:	Ikke tilgængelig
Husmateriale:	Metal
Monteringstype:	Loft
Maksimal vægtkapacitet:	544 kg
