MONOBLOCK SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >90dB
Subsonic and Low Pass Crossovers: 24dB per octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 1 ohm
Typical Efciency: 80%
Damping Factor: Greater than 200
FOUR CHANNEL SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 20kHz
Signal to Noise Ratio: >110dB
High and Low Pass Crossovers: 18dB per Octave
Low Pass Crossover Range: 40Hz to 400Hz
High Pass Crossover Range: 20Hz to 400Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 4 ohm Bridged or 2 ohm Stereo
Typical Efciency: 50%
Damping Factor Greater than 200
Ti1500.1
Dynamic Power 14.4Vdc >1% THD 1100 x 1 @ 2 ohm
1500 x 1 @ 1 ohm
RMS Power 14.4Vdc ≤ 1% THD 900 x 1 @ 2 ohm
1250 x 1 @ 1 ohm
Recommended Fuse Size: 100A
Minimum Power/Ground Wire Size: 4 Gauge
Dimensions: 16.85” L x 9.8” W x 2.5” H
428mm x 252mm x 62mm
Ti2500.1
Dynamic Power 14.4Vdc >1% THD 1500 x 1 @ 2 ohm
2500 x 1 @ 1 ohm
RMS Power 14.4Vdc ≤ 1% THD 1100 x 1 @ 2 ohm
1650 x 1 @ 1 ohm
Recommended Fuse Size: 200A
Minimum Power/Ground Wire Size: 1/0 Gauge
Dimensions: 20.4” L x 9.8” W x 2.5” H
518mm x 252mm x 62mm
Ti600.4
Dynamic Power 14.4Vdc >1% THD 100 x 4 @ 4 ohm Stereo
150 x 4 @ 2 ohm Stereo
300 x 2 @ 4 ohm Bridged
RMS Power 14.4Vdc ≤1% THD 90 x 4 @ 4 ohm Stereo
120 x 4 @ 2 ohm Stereo
240 x 2 @ 4 ohm Bridged
Recommended Fuse Size: 80A
Minimum Power/Ground Wire Size: 4 Gauge
Dimensions: 16.85” L x 9.8” W x 2.5” H
428mm x 252mm x 62mm
Ti800.4
Dynamic Power 14.4Vdc >1% THD 125 x 4 @ 4 ohm Stereo
200 x 4 @ 2 ohm Stereo
400 x 2 @ 4 ohm Bridged
RMS Power 14.4Vdc ≤1% THD 115 x 4 @ 4 ohm Stereo
150 x 4 @ 2 ohm Stereo
300 x 2 @ 4 ohm Bridged
Recommended Fuse Size: 100A
Minimum Power/Ground Wire Size: 4 Gauge
Dimensions: 20.4” L x 9.8” W x 2.5” H
518mm x 252mm x 62mm
Specifications
