Amplifier Manual

Manuel de l’amplificateur

Features: Caractéristiques:

Model: SD1300.1, SD1300.5

• High Eciency Class D Topology

• Compact Size for Easy Installation

• High and Low Pass Crossovers

• Robust Unregulated Power Supply

• Surface Mount Component Technology

• Panel Mounted RCAs

• Direct Insert Power and Speaker Terminals

• Audio Precision Quality Control Verication

• High Temperature Plexiglass cover

• Remote subwoofer level control included

• Topologie de classe D de gamme complète

• Petit format pour faciliter l’installation

• Filtres croisés passe-haut et passe-bas

• Alimentation électrique robuste non réglementée

• Technologie de composant monté en surface

• Amplicateurs à couplage RC montés sur des panneaux

• Terminaux d’alimentation et de haut-parleurs à insertion directe

• Vérication du contrôle de la qualité de la précision audio

• Couvercle de plexiglas résistant aux températures élevées

• Niveau de contrôle de passe-bas inclus

Amplier Owner’s Manual

Specifications

SD1300.5 SPECIFICATIONS

Frequency Response: ± 1dB from 20Hz to 20kHz

Signal to Noise Ratio: >100dB

High Pass Crossovers: 12dB per Octave

Low Pass Crossover: 18dB per Octave

High Pass Crossover Range: 15Hz to 250Hz

Low Pass Crossover Range: 30Hz to 300Hz

Bass Boost @ 45Hz: 0 to +18dB

Low Level Input Range: 200 millivolts to 8 volts

Front and Rear Channels Lowest Load: 4 ohms Bridged or 2 ohms Stereo

Subwoofer Channel Lowest Load: 2 ohm

Typical Eciency: 70%

Damping Factor Greater than 200

Note: All SD ampliers operate correctly up to 14.4 volts. Do not

operate the amplier above 14.4 volts. The amplier will engage its

overvoltage protection, the result is no audio output on one or

more channels.

RMS Power 14.4Vdc ≤1% THD 80 x 4 @ 4 ohms Stereo

125 x 4 @ 2 ohms Stereo

250 x 2 @ 4 ohms Bridged

plus

500 x 1 @ 4 ohms

800 x 1 @ 2 ohms

Dynamic Power 14.4Vdc >1% THD 95 x 4 @ 4 ohms Stereo

150 x 4 @ 2 ohms Stereo

300 x 2 @ 4 ohms Bridged

plus

700 x 1 @ 4 ohms

1000 x 1 @ 2 ohms

Recommended Fuse Size: 100 amp

Power/Ground Wire Size: 4 Gauge

Dimensions (Includes Mounting Feet): 14.33” L x 6.93” W x 2.0” H

364mm L x 176mm W x 51mm H

Dimensions (Includes Terminals): 14.96” L x 6.93” W x 2.0” H

380mm L x 176mm W x 51mm H

SD1300.1 SPECIFICATIONS

Frequency Response: ± 1dB from 20Hz to 300Hz

Signal to Noise Ratio: >90dB

Low Pass Crossover: 18dB per Octave

Subsonic Filter: 12dB per Octave

Low Pass Crossover Range: 30Hz to 300Hz

Subsonic Crossover Range: 10Hz to 55Hz

Bass Boost @ 45Hz: 0 to +18dB

Low Level Input Range: 200 millivolts to 8 volts

Lowest Recommend Load: 1 ohm

Typical Eciency: 70%

Damping Factor: Greater than 200

RMS Power 14.4Vdc ≤ 1% THD 900 x 1 @ 2 ohms

1300 x 1 @ 1 ohm

Dynamic Power 14.4Vdc >1% THD 1200 x 1 @ 2 ohms

1600 x 1 @ 1 ohm

Recommended Fuse Size: 120 amp

Power/Ground Wire Size: 4 Gauge

Dimensions (Includes Mounting Feet): 14.33” L x 6.93” W x 2.0” H

364mm L x 176mm W x 51mm H

Dimensions (Includes Terminals): 14.96” L x 6.93” W x 2.0” H

380mm L x 176mm W x 51mm H
