AMPLIFIER

OWNER’S MANUAL

ELITE

Elite Amplier Owner’s Manual

ELITE.1

• Class D Topology

• Overbuilt Quad Unregulated Power Supplies

• Handwound Power Supply Transformers

• Isolated Pre-Amp Section

• Crossovers have 41 Detents for Exact Frequency Selection

• Aluminum Shaft Potentiometers

• Panel Mounted RCAs

• Clip Indicators

• Extruded Aluminum Heatsink with Evenow Technology

• Integrated Cooling via Endcap Vents

• Each Amp is Shipped in its Own Soft Felt Protective Cover

• High Temperature Plexiglass Cover

• RMD - Remote Voltage Display Ready

• Remote Level Control with Clip Indicator Included

• Linkable or strappable to an additional Elite.1

• Audio Precision Quality Control Verication

• Power Output Birth Certicate

ELITE.2/4

• Class A/B Topology

• Burr Brown Operational Ampliers

• Monolithic Signal Capacitors

• Massive Dual Package Sanken Output Devices

• Overbuilt Dual Unregulated Power Supplies

• Handwound Power Supply Transformers

• Triple Darlington Output Stage

• Isolated Pre-Amp Section

• Crossovers have 41 Detents for Exact Frequency Selection

• Aluminum Shaft Potentiometers

• Panel Mounted RCAs

• Clip Indicators

• Extruded Aluminum Heatsink with Evenow Technology

• User Adjustable Temperature Controlled Fan Cooling System

• Integrated Cooling via Endcap Vents

• Each Amp is Shipped in its Own Soft Felt Protective Cover

• High Temperature Plexiglass Cover

• RMD - Remote Voltage Display Ready

• Remote Level Control with Clip Indicator Included

• Audio Precision Quality Control Verication

• Power Output Birth Certicate

FEATURES

ELITE.1

Frequency Response: ± 1dB from 20Hz to 300Hz

Signal to Noise Ratio: >100dB

Low Pass Crossover: 24dB per Octave

Subsonic Filter: 24dB per Octave

Low Pass Crossover Range: 30Hz to 300Hz

Subsonic Crossover Range: 10Hz to 55Hz

Bass Boost @ 45Hz: 0 to +18dB

Low Level Input Range: 200 millivolts to 8 volts

Lowest Recommend Load: 1 ohm

Typical Eciency: 85%

Damping Factor: Greater than 200

ELITE.2

Frequency Response: ± 1dB from 10Hz to 50kHz

Signal to Noise Ratio: >110dB

High and Low Pass Crossovers: 18dB per Octave

High Pass Crossover Range: 20Hz to 4kHz

Low Pass Crossover Range: 40Hz to 4kHz

Low Level Input Range: 200 millivolts to 8 volts

Lowest Recommend Load: 2 ohms Bridged or 1 ohm Stereo

Typical Eciency: 55%

Damping Factor Greater than 200

RMS Power 14.4Vdc ≤ 1% THD 2400 x 1 @ 2 ohms

3200 x 1 @ 1 ohm

Note: A power birth certicate is included for each amplier. Elite

ampliers are VERY CONSERVATIVELY rated and will exceed the

RMS power rating by up to 30%.

Recommended Fuse Size: 300 amp

Power/Ground Wire Size: 1/0 Gauge

Dimensions: 23.3” L x 10.5” W x 2.6” H

592mm L x 267mm W x 66mm H

RMS Power 14.4Vdc ≤1% THD 250 x 2 @ 4 ohms Stereo

400 x 2 @ 2 ohms Stereo

500 x 2 @ 1 ohm Stereo*

800 x 1 @ 4 ohms Bridged

1000 x 1 @ 2 ohms Bridged*

Note: A power birth certicate is included for each amplier. Elite

ampliers are VERY CONSERVATIVELY rated and will exceed the

RMS power rating by up to 30%.

*Reactive Load Measurement

Recommended Fuse Size: 100 amp

Power/Ground Wire Size: 1/0 Gauge

Dimensions: 23.3” L x 10.5” W x 2.6” H

592mm L x 267mm W x 66mm H

SPECIFICATIONS

ELITE.4

Frequency Response: ± 1dB from 10Hz to 50kHz

Signal to Noise Ratio: >110dB

High and Low Pass Crossovers: 18dB per Octave

High Pass Crossover Range: 20Hz to 4kHz

Low Pass Crossover Range: 40Hz to 4kHz

Low Level Input Range: 200 millivolts to 8 volts

Lowest Recommend Load: 2 ohms Bridged or 1 ohm Stereo

Typical Eciency: 55%

Damping Factor Greater than 200

RMS Power 14.4Vdc ≤1% THD 150 x 4 @ 4 ohms Stereo

250 x 4 @ 2 ohms Stereo

300 x 4 @ 1 ohm Stereo*

500 x 2 @ 4 ohms Bridged

600 x 2 @ 2 ohms Bridged*

Note: A power birth certicate is included for each amplier. Elite

ampliers are VERY CONSERVATIVELY rated and will exceed the

RMS power rating above by up to 30%.

*Reactive Load Measurement

Recommended Fuse Size: 100 amp

Power/Ground Wire Size: 1/0 Gauge

Dimensions: 23.3” L x 10.5” W x 2.6” H

592mm L x 267mm W x 66mm H

A NOTE ABOUT SPECIFICATIONS....

Elite ampliers were engineered to be the best sounding mobile ampliers on the

planet. Numbers on this sheet of paper can not truly convey the dynamics and

realism these ampliers can deliver. Enjoy

INTRODUCTION:

Thank you for purchasing a Phoenix Gold Elite amplier, we are condent it will be the nest amplier you have

ever owned.

The Elite ampliers feature only the highest grade of audio components such as Burr Brown op-amps,

Monolithic signal capacitors, and dual-package Sanken output transistors. The result is unparalleled sonic

performance in a mobile audio amplier. With proper installation this amplier is overbuilt to last a lifetime,

thank you for choosing Phoenix Gold.
