Side 1/12

Amplifier Manual

Manuel de l’amplificateur

Features: Caractéristiques:

Models: SD300.1, SD600.1, SD500.4, SD800.5

• High Eciency Class D Topology

• Compact Size for Easy Installation

• High and Low Pass Crossovers

• Robust Unregulated Power Supply

• Surface Mount Component Technology

• Power Supply Filtering eliminates AM/FM interference

• Panel Mounted RCAs

• Direct Insert Power and Speaker Terminals

• Audio Precision Quality Control Verication

• High Temperature Plexiglass cover

• Remote subwoofer level control included (SD300.1/SD600.1/SD800.5 Only)

• Topologie de classe D de gamme complète

• Petit format pour faciliter l’installation

• Filtres croisés passe-haut et passe-bas

• Alimentation électrique robuste non réglementée

• Technologie de composant monté en surface

• Filtrage de l’alimentation électrique qui élimine l’interférence AM/FM

• Amplicateurs à couplage RC montés sur des panneaux

• Terminaux d’alimentation et de haut-parleurs à insertion directe

• Vérication du contrôle de la qualité de la précision audio

• Couvercle de plexiglas résistant aux températures élevées

• Niveau de contrôle de passe-bas inclus (SD300.1/SD600.1/SD800.5)

Amplier Owner’s Manual

SD300.1 SPECIFICATIONS

Frequency Response: ± 1dB from 20Hz to 300Hz

Signal to Noise Ratio: >90dB

Low Pass Crossover: 18dB per Octave

Subsonic Filter: 12dB per Octave

Low Pass Crossover Range: 30Hz to 300Hz

Subsonic Crossover Range: 10Hz to 55Hz

Bass Boost @ 45Hz: 0 to +18dB

Low Level Input Range: 200 millivolts to 8 volts

Lowest Recommend Load: 2 ohm

Typical Eciency: 70%

Damping Factor: Greater than 200

SD500.4 SPECIFICATIONS

Frequency Response: ± 1dB from 20Hz to 20kHz

Signal to Noise Ratio: >100dB

High and Low Pass Crossovers: 12dB per Octave

Crossover Range: 40Hz to 400Hz

Bass Boost @ 45Hz: 0 to +18dB

Low Level Input Range: 200 millivolts to 8 volts

Lowest Recommend Load: 4 ohm Bridged or 2 ohm Stereo

Typical Eciency: 70%

Damping Factor Greater than 200

RMS Power 14.4Vdc ≤ 1% THD 200 x 1 @ 4 ohm

300 x 1 @ 2 ohm

Dynamic Power 14.4Vdc >1% THD 300 x 1 @ 4 ohm

400 x 1 @ 2 ohm

Recommended Fuse Size: 30 amp

Power/Ground Wire Size: 8 Gauge

Dimensions (Includes Mounting Feet): 7.24” L x 6.93” W x 2.0” H

184mm L x 176mm W x 51mm H

Dimensions (Includes Terminals): 7.36” L x 6.93” W x 2.0” H

187mm L x 176mm W x 51mm H

RMS Power 14.4Vdc ≤1% THD 75 x 4 @ 4 ohm Stereo

125 x 4 @ 2 ohm Stereo

250 x 2 @ 4 ohm Bridged

Dynamic Power 14.4Vdc >1% THD 90 x 4 @ 4 ohm Stereo

150 x 4 @ 2 ohm Stereo

300 x 2 @ 4 ohm Bridged

Recommended Fuse Size: 50 amp

Power/Ground Wire Size: 8 Gauge

Dimensions (Includes Mounting Feet): 10.0” L x 6.93” W x 2.0” H

254mm L x 176mm W x 51mm H

Dimensions (Includes Terminals): 10.63” L x 6.93” W x 2.0” H

270mm L x 176mm W x 51mm H

Specifications

SD800.5 SPECIFICATIONS

Frequency Response: ± 1dB from 20Hz to 20kHz

Signal to Noise Ratio: >100dB

High Pass Crossovers: 12dB per Octave

Low Pass Crossover: 18dB per Octave

High Pass Crossover Range: 15Hz to 250Hz

Low Pass Crossover Range: 30Hz to 300Hz

Bass Boost @ 45Hz: 0 to +18dB

Low Level Input Range: 200 millivolts to 8 volts

Front and Rear Channels Lowest Load: 4 ohm Bridged or 2 ohm Stereo

Subwoofer Channel Lowest Load: 2 ohm

Typical Eciency: 70%

Damping Factor Greater than 200

Note: All SD ampliers operate correctly up to 14.4 volts. Do not

operate the amplier above 14.4 volts. The amplier will engage its

overvoltage protection, the result is no audio output on one or

more channels.

RMS Power 14.4Vdc ≤1% THD 75 x 4 @ 4 ohm Stereo

125 x 4 @ 2 ohm Stereo

250 x 2 @ 4 ohm Bridged

plus

200 x 1 @ 4 ohm

300 x 1 @ 2 ohm

Dynamic Power 14.4Vdc >1% THD 90 x 4 @ 4 ohm Stereo

150 x 4 @ 2 ohm Stereo

300 x 2 @ 4 ohm Bridged

plus

300 x 1 @ 4 ohm

400 x 1 @ 2 ohm

Recommended Fuse Size: 60 amp

Power/Ground Wire Size: 4 Gauge

Dimensions (Includes Mounting Feet): 11.57” L x 6.93” W x 2.0” H

294mm L x 176mm W x 51mm H

Dimensions (Includes Terminals): 12.2” L x 6.93” W x 2.0” H

310mm L x 176mm W x 51mm H

SD600.1 SPECIFICATIONS

Frequency Response: ± 1dB from 20Hz to 300Hz

Signal to Noise Ratio: >90dB

Low Pass Crossover: 18dB per Octave

Subsonic Filter: 12dB per Octave

Low Pass Crossover Range: 30Hz to 300Hz

Subsonic Crossover Range: 10Hz to 55Hz

Bass Boost @ 45Hz: 0 to +18dB

Low Level Input Range: 200 millivolts to 8 volts

Lowest Recommend Load: 1 ohm

Typical Eciency: 70%

Damping Factor: Greater than 200

RMS Power 14.4Vdc ≤ 1% THD 400 x 1 @ 2 ohm

600 x 1 @ 1 ohm

Dynamic Power 14.4Vdc >1% THD 600 x 1 @ 2 ohm

800 x 1 @ 1 ohm

Recommended Fuse Size: 60 amp

Power/Ground Wire Size: 4 Gauge

Dimensions (Includes Mounting Feet): 10.0” L x 6.93” W x 2.0” H

254mm L x 176mm W x 51mm H

Dimensions (Includes Terminals): 10.12” L x 6.93” W x 2.0” H

257mm L x 176mm W x 51mm H
