Side 1/2

www.PyleUSA.com

Lightweight and Portable Bullhorn Megaphone

Aux (3.5mm) Input for MP3/Music, Automatic Siren,

50-Watt, MIC/TALK (White)

PMPRA515WHI

This user manual contains important information for safe operation and optimal megaphone performance.

Please carefully read and follow safety notes and instructions. Save this manual for future reference.

Ensure it is available to all persons using this device.

SAFETY

This megaphone is intended to be used only as

described in this user manual. Any other use or use

under dierent operating conditions is considered

improper and may result in personal injury or device

damage. Please use the megaphone as described and

supervise its use when used by children or minors.

• Ensure that plastic bags, packaging, etc., are removed.

• Never let children use electrical devices unattended.

• Observe proper polarity when inserting batteries.

Incorrectly inserted batteries may cause damage &

the risk of re.

• Leaking batteries can cause permanent damage to

the device.

• Remove batteries if the megaphone will not be used

for long periods.

PRECAUTIONS

• Ensure correct polarity of cells used. Insert the batteries

in the correct direction by aligning the (-) marks on the

batteries with the spring in the back cover.

• Use new batteries/cells whenever possible.

• When the megaphone is not in use for a long period,

remove the dry cells and replace them.

Drained cells or rechargeable batteries will not provide

sucient sound volume.

BATTERY INSERTION

• Unfasten the clip located near the top, back side of

the unit.

• The clip will release the lid to reveal the battery

compartment.

• Please observe the correct battery direction placement

on the top side of the opening battery compartment

lid. Insert batteries, close the cover, and fasten the clip

until locked.

NOTE:

Make sure the batteries are inserted correctly, observing

correct polarity.

TO REPLACE BATTERIES

1. Loosen the locking screw of the battery compartment

cover on the back of the body.

The battery compartment cover comes o.

2. Insert 8 x type-C (UM-2) batteries into the battery case,

observing correct polarity.

3. Insert the battery case with batteries into the battery

compartment of the megaphone, paying attention to

polarity.

Handhrld Microphone

Shoulder Strap

Clip-on Brackets

Press-to-talk

Button

PA Talk Trigger

Switch

PA Mode

Selector

Battery

Compartment

Cover

www.PyleUSA.com

OPERATING INSTRUCTIONS

1. When carrying the megaphone on the shoulder, press the (1) press-to-talk power on-o switch on the left side of

the microphone.

2. When holding the megaphone at the grip, x the microphone hanger inlet in the microphone xing hanger, then

press the (2) press-to-talk power on-o switch back with your index nger.

3. Position the speaker opening mouth towards the object and speak through the microphone mouthpiece.

Bring the microphone mouthpiece close to your lips and speak normally.

4. Turn the sound volume control on the right-hand side of the microphone and adjust the sound level to the

maximum without causing howling.

5. Adjust the volume control to the min. before recording.

6. To record, press the RECORD button. Now your megaphone is ready for recording.

The longest record time is about 60 seconds. Press the RECORD button again after recording is done.

7. Press the button to activate the recorded materials circularly.PLAY

• Slide the 'PA Mode Selector Switch' on the side of the megaphone to choose the desired PA mode and to power

on/o the unit. Choose between 'Siren,' 'Talk,' and 'O' modes.

• Talk: While in 'Talk' mode, speak through the microphone mouthpiece while holding the 'Press-to-Talk' button on

the detachable handheld dierential mic. Users also have the ability to use the 'PA Talk Trigger Switch' on the

megaphone's handheld pistol grip. NOTE: An adjustable volume control slider is also located on the handheld mic.

• Siren: Selecting this mode activates an automatic, continuous alarm siren. Switch to another mode to discontinue

the alarm siren play.

• O: Powers the unit o.

Features:

•

Audio Modes: Talk, Siren, Music, Whistle, Record 60 seconds

• Aux (3.5mm) Input Connector Jack

• Stream MP3 & Digital Audio Files

• Includes Plug-in Handheld Microphone

• Button Activated Automatic Siren Alarm

• Adjustable Volume Control and Shoulder Strap

• Ergonomic Pistol Grip and Lightweight Chassis For Indoor/

Outdoor Use

• Built-in Automatic Siren Function

• Talk, Music, and Siren Switch

• Ability to Connect External Devices

(iPhone, Android, Smartphone, iPad, Tablet, etc.)

Technical Specs:

•

Constructional Materials: ABS

• Power Output: 50-Watt MAX

• Bell Width: 13.8’’ -inches

• Projection Range: Up to 1200 Square Yards

• Battery Powered: Requires 8 x 'C' Batteries,

Not Included

• Item Weight: 4.40 lbs.

• Product Dimensions (L x W x H):

9.0" x 9.0" x 13.8" –inches

Questions? Comments?

We are here to help!

Phone: (1) 718-535-1800

Email: support@pyleusa.com

Talk

OFF

Volume

Siren

REC Play

Adjust the sound level

High

Low
