DSP management: RAM OCS and amplifier display:

Two general working modes: User and Advanced (manufacturer)

· User functionalities:

- Input Routing matrix Analog/Dante/AES3

- Input EQ section with 8 filters and 20 memories

- Input EQ Use section, predefined by the manufacturer

- System Preset selection predefined by the manufacturer

(Locked/Unlocked)

- Snapshot library management up to 20 pre-sets

- Master Control Groups

· Advanced functionalities (manufacturer):

- Input EQ “Use” section creation, up to 20 pre-sets

- Ways routing section (Locked/Unlocked)

- IIR EQ section: XOver, Gain, Delay, and 7 EQ filters

- FIR EQ section: linear phase XOver and EQ filters, or

custom up to 1000 taps

- RMS and Peak Dynamic control

- Snapshot library management up to 20 pre-sets (Locked/Unlocked)

- System Preset library management up to 100 pre-sets

- 5 Security levels definition to limit final user functionality

■ Extra-large TFT display, capacitive touch panel user inter-

face

■ 64 bit double-precision 96kHz DSP process

■ High performance 96kHz/24 bits AD/DA converters

■ Available versions with DanteTM Networking (AES67) and

AES3 Digital inputs

■ Two ports Ethernet switch for daisy chain connection

■ USB port for firmware update and DSP control

■ High voltage output for high headroom performances

■ Similar power per channel in any impedance

■ Advanced power management to squeeze until the last

watt of your speakers

■ Exceptional power sharing in asymmetrical loads

■ Powerful and fast response cooling system

Series

OUTPUT POWER Pi2- 3K Pi2-5K Pi4-6K Pi4-10K

2 ohms 2x 1450 W 2x 2500 W 4x 1450 W 4x 2500 W

4 ohms 2x 1500 W 2x 2500 W 4x 1500 W 4x 2500 W

8 ohms 2x 1100 W 2x 1600 W 4x 1100 W 4x 1600 W

Hi-Z 70V 2x 1500 W 2x 2500 W 4x 1500 W 4x 2500 W

Hi-Z 100V 2x 800 W 2x 2500 W 4x 800W 4x 2500 W

Phone:+34 96 127 30 54 - ramaudio.com - e-mail: info@ramaudio.com

RAM Audio®, PMS™, SSP™, ICL™ and QuantaPulse™ are registered trademarks of C.E. Studio-2 s.l.. All other names are trademarks of their respective companies.

Amplifier Specifications

DSP Specifications - RAM_OCS Control

Overall:

• High performance 96kHz/24 bits AD/DA converters

• 64 bit double-precision 96kHz DSP process

• 0.85 ms minimum process latency time

• Custom FIR process up to 1000 taps

• Dante and AES3 input versions

Input Section (x4):

• Gain, Mute and Phase inversion

• Input Delay: Up to 114 meters (333ms)

• Input EQ: 16 filters (Param., Shelving, LP, HP, BP, SB, AP)

Output Section (x4):

• Crossover Filters: FIR and IIR (up to 48dB/oct,

Butterw./LR/Bessel)

• Output Delay: 0 to 31 meters (90ms) per channel

• Output IIR EQ: 12 filters per channel (Param., Shel, LP, HP,

BP, SB, AP)

• Output FIR EQ: 20 filters per channel (Parametric,

Shelving, LP, HP, BP, SB, AP), or Custom. Up to 1000 taps

• RMS and Peak limiter per channel

Communications:

• Two ports Ethernet switch for daisy chain connection

• USB 2.0 Type B port

Miscellaneous:

• 100 Manufacturer system preset memories library

• 20 User preset memories library

• 20 User snapshot memories library

• Manufacturer/User passwords

• User control groups for virtual Equalization, Gain and

Delay

• Zones definition for library management and alerts infor-

mation

• Smaart® analysis software integration

Pi2-3K Pi2-5K Pi4-6K Pi4-10K

Number of channels 2 2 4 4

Total output power 3000 W 5000 W 6000 W 10000 W

Output Power* (All ch.’s driven/single channel)

2 ohms 2x 1450 W 22x 2500 W 24x 1450 W 24x 2500 W 2

1x 1450 W 21x 2500 W 21x 1450 W 21x 2500 W 2

4 ohms 2x 1500 W 2x 2500 W 4x 1500 W 4x 2500 W 1

1x 1750 W 1x 2800 W 1x 1900 W 1x 3000 W

8 ohms 2x 1100 W 2x 1600 W 4x 1100 W 4x 1600 W

1x 1150 W 1x 1700 W 1x 1200 W 1x 1800 W

4 ohms Bridged 2900 W 25000 W 22x 2900 W 22x 5000 W 2

8 ohms Bridged 3000 W 5000 W 2x 3000 W 2x 5000 W 1

Hi-Z 70V 2x 1500 W 2x 2500 W 2 4x 1500 W 4x 2500 W 2

Hi-Z 100V 2x 800 W 2x 2500 W 4x 800 W 4x 2500 W 1

Max output voltage 144 V 176 V 144 V 176 Vpeak peak peak peak

Max output current 38 A 50 A 38 A 50 Apeak peak peak peak

Total Harmonic Distortion <0.05%

Voltage Gain 26dB to 44dB (1dB step)

SNR 106 dBA 107.5 dBA 106 dBA 107.5 dBA

Required AC Mains

Operating Voltage (50Hz-60Hz) 170V-265V AC / 90V-140V AC

1/8 Rated Power (@230V, 4 ohms) 7 A 8 A 15 A 16 A

Dimensions W x H x D (mm) 483x89x320

Weight Net (kg-Lbs) 6-13.2 8.5-18.7 8.5-18.7 8.5-18.7

Protections: Soft-start, Turn-on Turn-off transients, Muting at turn-on, Over-heating, DC, RF, Short-circuit, Open or mismatched loads,

Overloaded power supply, ICL™, PMS™, and SSP™

* IEC filtered pink noise signal (40Hz-5kHz, 12dB crest factor). 230V AC mains.

1 PMS can limit output to prevent excessive current draw tripping the mains breaker.

2 SSP can limit output to prevent excessive heating.
