Side 1/28

www.rikontools.com

23-400HM2

16” Thickness Planer

with Helical Cutterhead

Operator’s Manual

Record the serial number and date of purchase in your manual for future reference.

Serial Number: _________________________ Date of purchase: _________________________

For technical support or parts questions, email techsupport@rikontools.com or call toll free at (877)884-5167

4001824

23-400H

TABLE OF CONTENTS

SPECIFICATIONS

NOTE: The specications, photographs, drawings and information in this manual represent the current

model when the manual was prepared. Changes and improvements may be made at any time, with no

obligation on the part of Rikon Power Tools, Inc. to modify previously delivered units. Reasonable care

has been taken to ensure that the information in this manual is correct, to provide you with the guidelines

for the proper safety, assembly and operation of this machine.

This owner’s manual is not a teaching aid and is intended to show

assembly, adjustments, and general use.

Motor ....................................................................................................3 HP, TEFC

Motor Speed (no load).......................................................................... 3,400 RPM

Volts ............................................................................................................. 220 V

Amps, Hertz .........................................................................................12 A, 60 Hz

Cutterhead Diameter .................................................................... 2-3/4" (70 mm)

Cutterhead Speed (RPM / CPM)....................................5,100 RPM / 20,400 CPM

Number of Carbide Inserts, 4-sided.................................................................... 72

Maximum Depth of Cut ....................................................................... 1/8" (3 mm)

Maximum Cutting Width ....................................................................16" (406 mm)

Maximum Cutting Depth (Height) ............................................ 8-13/16” (225 mm)

Feed Speed SF/min ........................................................ 16 to 23 (5 to 7 SM/min)

Dust Port ...................................................................... 4-3/4” Diameter (120 mm)

Dust Collection Minimum CFM ........................................................................ 650

Noise Level (no load) .................................................................................. ≤85dB

Overall Size (LxWxH)...................55” x 24-1/4” x 42-1/2” (1400 x 616 x 1080 mm)

Base Size ...........................................................24-5/8” x 22-1/4” (627 x 565 mm)

Net Weight ....................................................................................375 lbs (170 kg)

Specifications.....................................................................................................................2

Safety Instructions ........................................................................................................3 - 6

Getting To Know Your Machine .........................................................................................7

Contents of Package ....................................................................................................7 - 8

Assembly .....................................................................................................................8 - 9

Operation ...................................................................................................................10 - 11

Adjustments ...............................................................................................................12 - 16

Maintenance ....................................................................................................................17

Wiring Diagram ................................................................................................................17

Troubleshooting ............................................................................................................18

Parts Diagrams & Parts Lists .................................................................................. 19 - 25

Warranty ..........................................................................................................................26

Accessories ................................................................................................................ 27

Notes ...............................................................................................................................27
