Side 1/2

Features

USB Type-C - Female

Introduction

This premium Rocstor is a traveling charger with PD3.0(5V3A/9V3A/15V3A/20V5A). Use

travel charger connect to the devices (mobile phone,Note book,MP3, etc) that can rely

on USB-C cable for power! This adapter plugs into electric outlet to become a powered

USB-C port. It is helpful in long time journey and convenient for business!

Usage method

1. Plug the travel charger into socket.

2. Plug one port of USB-C cable into the interface of travel charger and plug the other

port of USB cable into the electrical equipment (mobile phone,Note book,MP3,etc)

3. After the completion of the charging device, please remove the charger from plug.

Advantages Description：

•Internal chip allows the 100V-240V input voltage range, not easy to damage

•Output accurate current limit and overload protection, can eectively protect user's

mobile phone or high-end electronic equipments from damaging.

•This product shell is made of reproof material, accident won’t happen even at

complex situations.

Matters needing attention

1. Please pull out the charge after using.

2. Do not use the travel charger in the electronic product which owns over-charging

specications, so as to avoid any problems aren't up to specication.

Note: Our products have the protection functions, the above tips are suggestions,

because it is benecial and harmless.

3. It’s normal that power adapter will be a little overheated in the use process.

4. When the travel charger is over-current, over-temperature, short-circuit protection

and stop working (unplug the device before the travel charger automatically return to

work), then you need to check whether the device is compatible with this travel

charger.

Output:

Specication

Operation Procedures

Package Contents

Before attempting to use this unit, please check the packaging and make sure

the following items are contained in the Packaging:

• Main unit x1

• User Manual x1

Input/Output

Input 100-240VAC 50/60Hz

Output 5V/3A, 9V/3A,15V/3A, 20V/5

Protection

Over current Protection Yes

Short circuit Protection Yes

Over temperature protection Yes

Over Load Protection Yes

Performance

Ripple And Noise Output voltage 2%

Eciency ≥86%@5V-15V，≥88%@20V

Mechanical

Color White

Size (70 x 67.6 x 29.5) mm - (2.7 x 2.6 x 1.1) in

Weight 222 g - 0.48 lbs

Environmental

Operating Temperature Range 0~25°C

Storage Temperature Range -20 ~ 80°C

Operating Relative Humidity 90 ~ 95% RH

Accessory User Manual

Congratulations

Thank you for purchasing this premium Rocstor product. For optimum performance and

safety, please read these instructions carefully before connecting, operating or using this

product. Please keep this manual for future reference.

Rocstor Premium 100W Smart USB-C®

Power Adapter

User Manual

Y10A247-W1

• Over current &voltage protection

• Short circuit protection

• Internal temperature protection.

• Small size

• Smart and convenient to use.

• Great for Charging Phones, Notebook, Cameras, MP3 Players

Technical Support / RMA

Hours: 9:00 am - 5:00 pm PST

Monday to Friday (except holidays)

Tell: +1 (818) 727-7000

( )National and international

Fax: +1 (818) 875-0002

Email: support@Rocstor.com

Support

Warranty Information

Technical support is available to all the registered users of Rocstor products.

Safety Information:

Connection Diagram

MacBook®, MacBook Pro®, MacBook Air®, iPad®, iPad Air®, iPad mini®, iPad Air®, iPhone®, MacOS® are

registered trademarks of Apple, Inc. Google® and Chromebook™ are registered trademarks of Google,

LLC. Microsoft® and Surface® are registered trademarks of Microsoft corporation. USB Type-C® and

USB-C® are registered trademark of USB Implementers Forum.

WARNING: Please follow these safety instructions. Failure to do so may result damages or injury.

It is normal that the Rocstor adapter becomes very warm during use.

Please note that:

continuous contact with warm surfaces for extended time may cause discomfort or injury. In order to

reduce the possibility of overheating or heat-related injuries, always allow needed ventilation around

the Rocstor adapter and use care when handling it. Avoid instances where your skin is in extended

contact with the hub when plugged into the host computer. It is not recommended to sleep with the

adapter when plugged into a host computer. Avoid placing the hub adapter under a pillow, blanket,

or your body when connected to a host computer. If you have a medical condition that aects your

ability to detect heat against the body, extra care should be used. Never use the adapter in locations

with water, such as a sink, bathtub, or shower stall. Never connect or disconnect the adapter with wet

hands.

Limitation of Liability

In no event shall the liability of Rocstorage, Inc. and Rocstor (or their ocers, directors, employees or

agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or

otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of

the product exceed the actual price paid for the product. Some states do not allow the exclusion or

limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Warranty Information

This product is backed by a (1) one-year warranty. Rocstor warrants its products against defects in

materials and workmanship for the periods noted, following the initial date of purchase. During this

period, the products may be returned for repair, or replacement with equivalent products at our

discretion. The warranty covers parts and labor costs only. Rocstor does not warrant its products from

defects or damages arising from misuse, abuse, alteration, or normal wear and tear.

USB Type-C Cable

Produkt Specifikationer

Mærke:	Rocstor
Kategori:	Batterioplader
Model:	Y10A247-W1
Bredde:	27.9 mm
Dybde:	48.3 mm
Højde:	68.6 mm
Vægt:	218 g
Antal pr. pakke:	1 stk
Produktfarve:	Hvid
LED-indikatorer:	Ja
Strømkilde type:	Vekselstrøm
Oplader, kompabilitet:	Laptop
Antal USB type-C-porte:	1
Maksimal ydeevne:	100 W
Kapabilitet:	MacBook, MacBook Air, MacBook Pro 13", MacBook Pro 15", MacBook Pro 16", Chromebook
Oplader type:	Indendørs
USB strømforsyning:	Ja
USB strømforsyning op til:	100 W
Galliumnitrid (GaN) transistorer:	Ja
