Instruction Manual
THREE-CD CHANGER
MINI-COMPACT SYSTEM
MP3-CD/CD-R/RW PLAYBACK
MAX-ZS720
GB
2
Safety Warnings
Use of controls, adjustments or performance of procedures other
than those specified herein may result in hazardous radiation
exposure.
CAUTION-INVISIBLE LASER RADIATION WHEN OPEN
AND INTERLOCKS DEFEATED, AVOID EXPO-
SURE TO BEAM.
This symbol indicates that dangerous voltage which
can cause electric shock is present inside this unit.
This symbol alerts you to important operating and
maintenance instructions accompanying the unit.
WARNING: To reduce the risk of fire or electric shock, do not
expose this appliance to rain or moisture.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
PRODUCTO LASER CLASE 1
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE REAR COVER. NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CLASS 1 LASER PRODUCT
This Compact Disc player is classified
as a CLASS 1 LASER product.
CAUTION
GB
Press Push Important Note
Symbols
3
Contents Thank you for buying this
SAMSUNG mini-compact system.
Please take time to read these instructions.
They will allow you to operate your
system with ease and take full advantage
of its features.
S
AFETY
W
ARNINGS
.................................................................................................................................................................................. 2
I
NSTALLING
Y
OUR
M
INI
-C
OMPACT
S
YSTEM
Front Panel View...................................................................................................................................................................................... 4
Display Window ...................................................................................................................................................................................... 5
Rear Panel View ...................................................................................................................................................................................... 6
Remote Control ........................................................................................................................................................................................ 6
Where to Install Your Mini-Compact System............................................................................................................................................ 7
Connecting your System to the Power Supply ........................................................................................................................................ 7
Inserting Remote Control Batteries .......................................................................................................................................................... 7
Connecting to an External Source .......................................................................................................................................................... 8
Connecting the Loudspeakers ................................................................................................................................................................ 8
Connecting the AM (MW/LW)Aeria .................................................................................................. l .............................................................. 9
Connecting the FM Aerial ........................................................................................................................................................................ 9
Connecting the SW Aerial(option)............................................................................................................................................................ 9
Demo/Dimmer function ............................................................................................................................................................................ 10
Setting the Clock ...................................................................................................................................................................................... 10
CD/MP3-CD-P
LAYER
Loading and Changing Compact Discs.................................................................................................................................................... 11
To reply the CD/MP3-CD ........................................................................................................................................................................ 11
Selecting a CD in the Disc changer ........................................................................................................................................................ 12
Selecting a CD Track .............................................................................................................................................................................. 12
To select the MP3-CD title and track ...................................................................................................................................................... 12
Searching for a Specific Music Passage on a CD .................................................................................................................................. 13
Shuffle Play Function .............................................................................................................................................................................. 13
Function to skip through 10 track at a time ............................................................................................................................................ 14
Last Memory Function ............................................................................................................................................................................ 14
Repeating One or All Tracks on the Compact Discs................................................................................................................................ 15
Programming the Order of CD Playback ................................................................................................................................................ 15
Checking or Changing Programmed CD Tracks...................................................................................................................................... 16
T
UNER
Searching for and Storing the Radio Stations ........................................................................................................................................ 16
Selecting a Stored Station........................................................................................................................................................................ 17
Improving Radio Reception...................................................................................................................................................................... 17
T
APE
D
ECK
Listening to a Cassette ............................................................................................................................................................................ 18
CD Synchro Record Feature.................................................................................................................................................................... 18
Recording a Compact Disc ...................................................................................................................................................................... 18
Recording a Radio Program .................................................................................................................................................................... 19
Copying a Cassette (Dubbing) ................................................................................................................................................................ 19
Selecting the Cassette Playback Mode (Deck 2 Only) ............................................................................................................................ 19
Tape Counter............................................................................................................................................................................................ 19
O
THER
F
UNCTIONS
Timer Function ........................................................................................................................................................................................ 20
Cancelling the Timer ................................................................................................................................................................................ 20
Mute Function .......................................................................................................................................................................................... 21
Selecting Sound Mode............................................................................................................................................................................ 21
Power Surround Function ........................................................................................................................................................................ 21
Setting the System to Switch off Automatically ........................................................................................................................................ 22
Super Bass Level .................................................................................................................................................................................... 22
Connecting Headphones.......................................................................................................................................................................... 22
Microphone Function(option).................................................................................................................................................................... 22
R
ECOMMENDATIONS FOR
U
SE
Safety Precautions .................................................................................................................................................................................. 23
Cleaning Your Mini-Compact System ...................................................................................................................................................... 23
Precautions When Using Compact Discs ................................................................................................................................................ 24
Precautions When Using Audio Cassettes .............................................................................................................................................. 24
Before Contacting the After-Sales Service .............................................................................................................................................. 24
Technical Specifications .......................................................................................................................................................................... 25
GB
4
Front Panel View
3233
2
1
3
4
5
6
7
13
12 1514 16
18
20
19
21
22
23
25
24
26
27282931 30
17
8
9
10
11
1. Program
2. FM Mono/Stereo
3. Timer/Clock
4. Timer On/Off
5. AI Sleep
6. Standby/On
7. MIC Level(option)
8. Counter Reset
9. MIC (option)
10. Reverse Mode
11. Cassette Deck 1
12. Record/Pause
13. TAPE Normal Speed Dubbing
14. Deck 1/2
15. CD Synchro Recording
16. Search Function buttons
Tuning Mode or Stop button
17. Demo/Dimmer
18. Cassette Deck 2
19. Multi Jog /MP3-CD Album Skip
20. Enter
21. Headphone Jack Connector
22. Super Bass Level
23. Sound Mode
24. Volume
25. Power Surround
26. Compact Disc Compartment
27. Open/Close
28. Disc Change
29. Disc Selection buttons
30. Window Display
31. Function Selection buttons
32. CD Repeat
33. Memory
GB
5
Display Window
1. Power Surround
2. Sound Mode
3. Volume and EQ Level
4. CD Program and Tuner Preset Number
5. Title
6. Main Display (Function, Frequency, Time, etc.)
7. FM Mode (STEREO)
8. EQ
9. D.S.P
10. CD-RW
11. Tape Reverse Mode
12. CD Synchro Recording
13. Tuner Frequency unit
14. AI SLEEP or SLEEP
15. CD Playing Disc Mode or CD Repeat Mode
16. MP3-CD
17. Clock
18. Playing Disc Number
19. Recording
20. Tape 1/2
21. Tuning Mode (Auto)
22. CD Program or Tuner Memory to Program
23. Tuner Preset
24. Super BASS
GB
6
Rear Panel View
1
2
3
4
5
6
7
8
9
10
11
Remote Control
1. Standby / On
2. Sound Mode
3. TAPE Fast-Forward/ Rewind
4. Deck 1/2
5. Reverse Mode
6. CD Repeat
7. CD Stop
8. Program/Set/MP3-CD last memory
9. CD Track or Radio Station Search
10. Tuning Mode/ /MP3-CD Album
Track Mode
11. FM Mono/Stereo
12. Volume Decrease
13. Tuner Band
14. Volume Increase
15. Disc Skip
16. CD Play/Pause
17. CD Shuffle PLAY/MP3-CD Random Play
18. +10 Button
19. AI Sleep
20. TAPE Stop
21. TAPE Play
22. Super Bass Level
23. AUX
24. Timer On/Off
25. Mute
12
13
14
15
16
18
17
19
20
22
21
23
25
24
1
2
3
4
5
6
1. SW Aerial Connector Terminal(option)
2. FM Aerial Connector Terminal
3. AM Aerial Connector Terminal
4. Voltage Selector(option)
5. AUX-Input
6. Loudspeaker Connector Terminals
GB
8
The auxiliary input can be used to take advantage of the
sound quality of your mini-compact system when listening to
other sources.
Examples: A television
A video disc player
A Hi-Fi stereo video cassette recorder
To connect the external source, the source must have an audio
output. In addition, you need an RCA connection cable.
Set the system to standby mode and disconnect it and the external
source from the main.
Connect the audio cable to the rear of the mini-compact system.
Connect the... To the connector marked...
Red jack R (right)
White jack L (left)
For optimum sound quality, do not invert the right and left
channels.
Plug the system back into the main socket and press Standby/On to
switch it on.
Select the AUX source by pressing AUX.
Result: AUX is displayed.
Switch the external source on.
Adjust the volume and balance as required:
Volume Equalizer
Example: You can watch a film and take advantage of stereo sound
provided that the original sound track is in stereo (as if you
were in a cinema).
Connecting to an External Source
1
2
3
4
5
6
The loudspeaker connector terminals are located on the rear
of the system.
There are four terminals on the system:
Two for the left speaker (marked L)
Two for the right speaker (marked R)
To achieve the correct sound quality, connect the:
Red wire to the + terminals
Black wire to the – terminals
Press and hold the terminal tab.
Insert the speaker cord.
Release the finger.
Connecting the Loudspeakers
1
2
3
Directions in Installing Speaker
Installation in a place near heating apparatus, under direct lay of
light or with high humidity may cause performance degradation
of the speaker.
Do not install on the wall or on a high place of pole or other
unstable place to prevent any safety accident caused by falling
of the speaker.
Do not take the speaker apart from TV or computer monitor.
The speaker near the TV or computer monitor may influence the
quality of the screen display.
L
R
34
GB
10
All functions available on the system can be viewed on the
display and the display's brightness can be switched between
"on" and "off".
Press the Demo/Dimmer button.
Result: All functions available on the system appear on the front
panel display.
Each of these are explained in detail in this guide. Please refer to
the relevant section.
Press the Demo/Dimmer button again.
Result: The Dimmer function is selected and the display darkens.
Press the Demo/Dimmer button once again to brighten the front
panel display.
A display brightness control can only be performed while the
system power is on.
Your system is equipped with a clock which allows you to
turn your system on and off automatically. You should set the
clock:
When you first purchase the mini-compact system
After a power failure
After unplugging the unit
For each step, you have a few seconds to set the required
options. If you exceed this time, you must start again.
Switch the system on by pressing Standby/On.
Press twice.Timer/Clock
Result: CLOCK is displayed.
Press Enter.
Result: The hour flashes.
To... Turn the Multi Jog knob to the...
Increase the hours Right
Decrease the hours Left
When the correct hour is displayed, press Enter.
Result: The minutes flash.
To... Turn the Multi Jog knob to the...
Increase the minutes Right
Decrease the minutes Left
When the correct time is displayed, press Enter.
Result: The clock starts and is displayed, even when the system is in
standby mode.
You can display the time, even when you are using another
function, by pressing Timer/Clock once.
You can also use Program/Set button on the remote control
to instead button in step Enter 3 5 7, , .
You can also use / buttons to instead Multi Jog
knob in step 4 6, .
Setting the Clock
2
1
1
2
3
4
5
6
7
Demo/Dimmer function
3
1
2
4,6
3,5,7
GB
14
Function to skip through 10
tracks at a time
Press the +10 button briefly while playing back a
CD. The track 10 tracks after the current one will then
be played back.
Example:
If you want to select track 43 during playback of track
15, press the button three times, and then press+10
the
button three times.
15
➝
20
➝
30
➝
40
➝
41
➝
42
➝
43
Last Memory Function
*This function is only available during playback of an MP3-CD.
When MP3-CD playback is selected again after your CD player has
been stopped or turned off, this function allows playback from the
start of the track that you last listened to.
Press the Program button on the main set or Program/Set button
on the remote control while your MP3-CD is being played back.
The and LAST ON OFF may be repeatedly selected.
Produkt Specifikationer
| Mærke: | Samsung |
| Kategori: | Hi-Fi system |
| Model: | MAX-ZS720 |
Har du brug for hjælp?
Hvis du har brug for hjælp til Samsung MAX-ZS720 stil et spørgsmål nedenfor, og andre brugere vil svare dig
Hi-Fi system Samsung Manualer
28 Februar 2025
15 Januar 2025
10 Januar 2025
10 Januar 2025
2 Januar 2025
2 Januar 2025
30 December 2025
10 November 2024
10 November 2024
10 November 2024
Hi-Fi system Manualer
- Hi-Fi system Sonance
- Hi-Fi system Scott
- Hi-Fi system Sunstech
- Hi-Fi system Pioneer
- Hi-Fi system SVS
- Hi-Fi system Zoom
- Hi-Fi system JBL
- Hi-Fi system DBX
- Hi-Fi system AVer
- Hi-Fi system Motu
- Hi-Fi system Nuheara
- Hi-Fi system DataVideo
- Hi-Fi system Beatfoxx
- Hi-Fi system 2N
- Hi-Fi system Juke Audio
Nyeste Hi-Fi system Manualer
4 Juni 2025
4 Juni 2025
3 Juni 2025
2 Juni 2025
2 Juni 2025
2 Juni 2025
30 Maj 2025
30 Maj 2025
8 April 2025
1 April 2025
