1/8NHA87388-03

03 - 2021

DANGER

HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH

• Only appropriately trained persons who are familiar with and understand the contents of this manual and all other

pertinent product documentation and who have received safety training to recognize and avoid hazards involved are

authorized to work on and with this drive system. Installation, adjustment, repair, and maintenance must be

performed by qualified personnel.

• The system integrator is responsible for compliance with all local and national electrical code requirements as well

as all other applicable regulations with respect to grounding of all equipment.

• Many components of the product, including the printed circuit boards, operate with mains voltage. Do not touch. Use

only electrically insulated tools.

• Do not touch unshielded components or terminals with voltage present.

• Motors can generate voltage when the shaft is rotated. Prior to performing any type of work on the drive system, block

the motor shaft to prevent rotation.

• AC voltage can couple voltage to unused conductors in the motor cable. Insulate both ends of unused conductors of

the motor cable.

• Do not short across the DC bus terminals or the DC bus capacitors or the braking resistor terminals.

• Before performing work on the drive system:

- Disconnect all power, including external control power that may be present.

- Place a "Do Not Turn On" label on all power switches.

- Lock all power switches in the open position.

- Wait 15 minutes to allow the DC bus capacitors to discharge. The DC bus LED is not an indicator of the

absence of DC bus voltage that can exceed 800 Vdc.

- Measure the voltage on the DC bus between the DC bus terminals (PA/+ and PC/-) using a properly rated

voltmeter to verify that the voltage is <42 Vdc.

- If the DC bus capacitors do not discharge properly, contact your local Schneider Electric representative. Do

not repair or operate the product.

• Install and close all covers before applying voltage.

Failure to follow these instructions will result in death or serious injury.

Altivar - Lexium

Braking resistors: VW3A7730...757

VW3A7733

VW3A7736

VW3A7730

VW3A7731

VW3A7732

VW3A7734

VW3A7735

VW3A7737

VW3A7738

100

2.5

1.4

50°C

(122°F)

0.96

1.9

0.1

0.16

0.3

0.96

3.2

1.5

100

2.5

1.4

VW3A7743

VW3A7746

VW3A7740

VW3A7741

VW3A7742

VW3A7744

VW3A7745

VW3A7747

VW3A7748

50°C

(122°F)

1.9

6.9

0.26

0.5

0.96

2.9

3.8

5.1

100

1.4

VW3A7753

VW3A7756

VW3A7750

VW3A7751

VW3A7752

VW3A7754

VW3A7755

VW3A7757

50°C

(122°F)

1.4

2.9

5.1

Electrical equipment should be installed, operated, serviced, and maintained only by qualified personnel. No responsibility

is assumed by Schneider Electric for any consequences arising out of the use of this product.

NHA8738803

The metal surfaces of the product may reach 150°C (302°F) during operation.

WARNING

HOT SURFACES

Ensure that any contact with hot surfaces is avoided.

Do not allow flammable or heat-sensitive parts in the immediate vicinity of hot surfaces.

Verify that the heat dissipation is sufficient by performing a test run under maximum load

conditions.

F u th e in ctions c re in d se us injury, or equip nt ail re to follow es stru an sult eath, rio me

damage.

CAUTION

SHARP EDGES

Use all necessary personal protective equipment (PPE) such as gloves when performing

any type of work whatsoever on or with the braking resistor.

Ensure that no other persons can perform any type of work whatsoever on or with

the braking resistor unless such persons use all necessary personal protective equipment

(PPE) such as gloves.

The cut resistance of the gloves must be at least level C as per ISO 23388 or

level A2 as per ANSI/ISEA 105.

F u th e in ctions c re in jury r equip nail re to follow es stru an sult in o me t damage

2/8NHA87388-03 www.schneider-electric.com

www.schneider-electric.com

brP-

RISK OF FIRE

Before installing the product, verify that all cardboard and other packaging material has been

completely removed from the product.

Failure to follow these instructions will result in death or serious injury.

DANGER
