Accent Spot Q4
Highlite International B.V. Vestastraat 2 6468 EX Kerkrade the Netherlands – – – –
Product code: 42541
USER MANUAL
ENGLISH
V1
1
A ccent Spot Q4
Product code: 42541
Preface
Thank you for purchasing this Showtec product.
The purpose of this user manual is to provide instructions for the correct and safe use of this product.
Keep the user manual for future reference as it is an integral part of the product. The user manual shall be
stored at an easily accessible location.
This user manual contains information concerning:
● Safety instructions
● Intended and non-intended use of the device
● Installation and operation of the device
● Maintenance procedures
● Troubleshooting
● Transport, storage and disposal of the device
Non-observance of the instructions in this user manual may result in serious injuries and damage of
property.
© 2 Showtec. All rights reserved. 202
No part of this document may be copied, published or otherwise reproduced without the prior written
consent of Highlite International.
Design and product specifications are subject to change without prior notice.
For the latest version of this document or other language versions please visit our website ,
www.highlite.com service@highlite.com or contact us at .
Highlite International and its authorized service providers are not liable for any injury, damage, direct or
indirect loss, consequential or economic loss or any other loss arising from the use of, or inability to use or
reliance on the information contained in this document.
2
A ccent Spot Q4
Product code: 42541
Table of contents
1. Introduction .......................................................................................................................................................... 4
Before Using the Product .................................................................................................................................. 4
Intended Use ....................................................................................................................................................... 4
Product Lifespan ................................................................................................................................................. 4
LEDs Lifespan ....................................................................................................................................................... 4
Text Conventions ................................................................................................................................................ 4
Symbols and Signal Words ................................................................................................................................ 5
Symbols on the Information Label .................................................................................................................. 5
2. Safety .................................................................................................................................................................... 6
Warnings and Safety Instructions .................................................................................................................... 6
Requirements for the User ................................................................................................................................. 8
3. Description of the Device ................................................................................................................................... 9
Front View ............................................................................................................................................................ 9
Back View ............................................................................................................................................................ 9
Product Specifications ....................................................................................................................................10
Optional Accessories .......................................................................................................................................11
Dimensions .........................................................................................................................................................11
4. Installation .......................................................................................................................................................... 11
Safety Instructions for Installation ..................................................................................................................11
Personal Protective Equipment .....................................................................................................................11
Installation Site Requirements ........................................................................................................................11
Rigging ...............................................................................................................................................................12
Angle Adjustment ............................................................................................................................................13
Beamshaper Installation ................................................................................................................................. 13
Connecting to Power Supply .........................................................................................................................14
Power Linking of Multiple Devices .................................................................................................................14
5. Setup ................................................................................................................................................................... 15
Warnings and Precautions .............................................................................................................................15
Stand-alone Setup ...........................................................................................................................................15
DMX Connection ..............................................................................................................................................15
DMX-512 Protocol .......................................................................................................................................15
DMX Cables .................................................................................................................................................16
Master/Slave Setup ....................................................................................................................................16
DMX Linking ..................................................................................................................................................17
DMX Addressing ..........................................................................................................................................17
6. Operation ........................................................................................................................................................... 18
Safety Instructions for Operation ...................................................................................................................18
Control Modes ..................................................................................................................................................18
Control Panel ....................................................................................................................................................19
Start- up...............................................................................................................................................................20
Menu Overview ................................................................................................................................................21
Main Menu Options .........................................................................................................................................23
DMX Settings ................................................................................................................................................23
DMX Address .......................................................................................................................................23
DMX Channel Mode ..........................................................................................................................24
Manual Mode .............................................................................................................................................24
Auto Mode ...................................................................................................................................................24
Program Mode ............................................................................................................................................25
Program 1 ............................................................................................................................................25
Program 2 –16 ......................................................................................................................................25
Correlated Color Temperature ................................................................................................................26
Slave Mode ..................................................................................................................................................26
Sound-controlled Mode ............................................................................................................................26
3
A ccent Spot Q4
Product code: 42541
Settings ..........................................................................................................................................................27
Selecting Dimming Curves ...............................................................................................................27
Setting Dimmer Speed ......................................................................................................................28
Setting PWM Frequency ....................................................................................................................28
DMX Failure Settings ...........................................................................................................................28
DMX Synchronization .........................................................................................................................29
Display Lock .........................................................................................................................................29
Restoring Factory Settings .................................................................................................................29
Device Information.....................................................................................................................................30
DMX Channels ..................................................................................................................................................30
RDM Information ...............................................................................................................................................32
RDM Details ..................................................................................................................................................32
Supported RDM PIDs for the Device .......................................................................................................32
7. Troubleshooting ................................................................................................................................................. 33
8. Maintenance ..................................................................................................................................................... 34
Safety Instructions for Maintenance .............................................................................................................34
Preventive Maintenance ................................................................................................................................34
Basic Cleaning Instructions .......................................................................................................................34
Corrective Maintenance ................................................................................................................................35
9. Deinstallation, Transportation and Storage .................................................................................................... 35
Instructions for Deinstallation ..........................................................................................................................35
Instructions for Transportation ........................................................................................................................35
Storage ...............................................................................................................................................................35
10. Disposal .............................................................................................................................................................. 36
11. Approval ............................................................................................................................................................. 36
4
A ccent Spot Q4
Product code: 42541
1. Introduction
Before Using the Product
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your
Highlite International dealer.
Your shipment includes:
● Showtec Accent Spot Q4
● Schuko to Power Pro cable (1,8 m)
● Beamshaper ° 10
● Beamshaper ° 40
● User manual
Fig. 01
Intended U se
This device is intended for professional use as an indoor spot effect It is suitable only for indoor .
installation. This device is not suitable for households and for general lighting.
Any other use, not mentioned under intended use, is regarded as non-intended and incorrect use.
Product Lifespan
This device is not designed for permanent operation. Disconnect the device from the electrical power
supply when the device is not in operation. This will reduce the wear and will improve the device’s
lifespan.
LED Lifespans
The light output of the LEDs gradually decreases over time (lumen depreciation) High operating .
temperatures contribute to this process. You can extend the lifespan of the LEDs by providing adequate
ventilation and operating the LEDs at the lowest possible brightness.
Text Conventions
Throughout the user manual the following text conventions are used:
● All buttons are in bold lettering, for example “Press t buttons” Buttons: he UP/DOWN
● References: References to chapters and parts of the device are in bold lettering, for example:
“Refer to ”, “turn the ”2. Safety adjustment handle (05)
● – 0 255: Defines a range of values
● Notes: (in bold lettering) is followed by useful information or tips Note:
5
A ccent Spot Q4
Product code: 42541
Symbols and Signal Words
Safety notes and warnings are indicated throughout the user manual by safety signs.
Always follow the instructions provided in this user manual.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
Attention
Indicates important information for the correct operation and use of the
product.
Important
Read and observe the instructions in this document.
Electric hazard al
Provides important information about the disposal of this product.
Symbols on the Information Label
This product is provided with an information label. The information label is located on the mounting
bracket.
The information label contains the following symbols:
This device is designed for indoor use.
This device falls under IEC protection class I.
This device shall not be treated as household waste.
Read and follow the instructions in the user manual before installing, operating or
servicing the device.
Minimum distance from lighted objects.
Caution: Risk of electric shock. Do not open.
Caution: To reduce the risk of electric shock, do not remove cover. No user-
serviceable parts inside. Refer servicing to qualified personnel.
6
A ccent Spot Q4
Product code: 42541
2. Safety
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
Warnings and Safety Instructions
DANGER
Danger for children
For adult use only. The device must be installed beyond the reach of children.
● Do not leave various parts of the packaging (plastic bags, polystyrene foam, nails, etc.) within
children’s reach. Packaging material is a potential source of danger for children.
DANGER
Electric shock caused by dangerous voltage inside
There are areas within the device where dangerous touch voltage (> 120 V DC) may be present.
● Do not open the device or remove any covers.
● Do not operate the device if the covers or the housing are open. Before operation, check if the
housing is firmly closed and all screws are tightly fastened.
● Disconnect the device from electrical power supply before service maintenance, and when the and
device is not in use.
DANGER
Electric shock caused by short-circuit
This device falls under IEC protection class I.
● Make sure that the device is electrically connected to ground (earth). Connect the device only to a
socket-outlet with ground (earth) connection.
● Do not cover the ground (earth) connection.
● Do not bypass the thermostatic switch or fuses.
● Do not let the power cable come into contact with other cables. Handle the power cable and all
connections with the mains with caution.
● Do not modify, bend, mechanically strain, put pressure on, pull or heat up the power cable.
● Make sure that the power cable is not crimped or damaged. Examine the power cable periodically
for any defects.
● Do not immerse the device in water or oth liquids. Do not install the device in a location where er
flooding may occur.
● Do not use the device during thunderstorms. Disconnect the device from the electrical power supply
immediately.
8
A ccent Spot Q4
Product code: 42541
Attention
Before each use, examine the device visually for any defects.
Make sure that:
● All screws used for installing the device or parts of the device are tightly fastened and are not
corroded.
● The safety devices are not damaged.
● There are no deformations on housings, fixations and installation points.
● The lens is not cracked or damaged.
● The power cables are not damaged and do not show any material fatigue.
Attention
Do not expose the device to conditions that exceed the rated IP class conditions.
This device is IP20 rated. IP (Ingress Protection) 20 class provides protection against solid objects greater
than 12 mm, such as finger and no protection against harmful ingress of water. s,
Requirements for the User
This product may be used by ordinary persons. Maintenance may be carried by ordinary persons.
Installation and service shall be carried out only by instructed or skilled persons. Contact your Highlite
International dealer for more information.
Instructed persons have been instructed and trained by a skilled person, or are supervised by a skilled
person, for specific tasks and work activities associated with the installation, service and maintenance of
this product, so that they can identify risks and take precautions to avoid them.
Skilled persons have training or experience, which enables them to recognize risks and to avoid hazards
associated with the installation, service and maintenance of this product.
Ordinary persons are all persons other than instructed persons and skilled persons. Ordinary persons
include not only users of the product but also any other persons that may have access to the device or
who may be in the vicinity of the device.
9
A ccent Spot Q4
Product code: 42541
3. Description of the Device
The Showtec Accent Spot Q4 is a compact indoor spot effect. It can be used for accent lighting.
T device is delivered with 2 beamshaper (10° and ). The device can be used in many applications, he s 40°
both in rental and fixed installations.
Front View
01) Lens
02) 2 x Adjustment screws
03) Mounting bracket
Fig. 02
Back View
04) 3-pin DMX signal connector IN
05) 3-pin DMX signal connector OUT
06) Control panel: OLED display and
control buttons
07) Safety eye
08) Power Pro connector OUT 100–
240 V, 50/60 Hz (Gray)
09) Power Pro connector IN 100 240 V, –
50/60 Hz (Blue)
Fig. 03
10
A ccent Spot Q4
Product code: 42541
Product Specifications
Model:
Accent Spot Q4
Electrical:
Input voltage:
100–240 V AC, 50/60 Hz
Power consumption:
21 W
Physical:
Dimensions:
2 mm (L x W x H) 45 x 160 x 105
Weight:
1 ,7 kg
Optics:
Light source:
1 x 25 W RGBW LED
Dimmer:
0 –100 %
Strobe:
0 20 Hz –
Beam angle (circular):
4,5°
Output:
15970 lx @ 2 m
7098 lx @ 3 m
2555 lx @ 5 m
Total lumen:
572 lm
Lumen Red:
233 lm
Lumen Green:
245 lm
Lumen Blue:
130 lm
Lumen White:
350 lm
CRI:
71
CCT:
1800–10000 K
Refresh rate:
10 00–12000 Hz
Operation and control:
Control:
Stand-alone (auto, manual, built-in programs, sound-controlled)
Master/Slave (auto, manual, built-in programs, sound-controlled)
DMX- , RDM 512
DMX channels:
4 6 12 channels , ,
Control panel:
OLED display and buttons
Connections:
Power connections:
Power Pro connectors IN/OUT
Data connections:
3-pin DMX connectors IN/OUT
Signal pin OUT:
Pin 1 (ground), pin 2 (-), pin 3 (+)
Construction:
Housing:
Aluminum die-cast
Color:
Black
IP rating:
IP20
Cooling:
Passive
Thermal:
Maximum ambient temperature ta:
From -20 °C to 45 °C
Minimum distance:
Minimum distance to lighted object:
0,5 m
11
A ccent Spot Q4
Product code: 42541
Optional Accessories
The device is delivered with the following accessories:
● Product code: 42545 (Beamshaper for Accent Spot Q4/SW (10°)
● Product code: 42547 (Beamshaper for Accent Spot Q4/SW (40°)
You can additionally purchase the following accessories:
● Product code: 42546 (Beamshaper for Accent Spot Q4/SW (20°)
● Product code: 42548 (Beamshaper for Accent Spot Q4/SW (10° x 60 °)
Dimensions
Fig. 04
4. Installation
Safety Instructions for Installation
WARNING
Incorrect installation can cause serious injuries and damage of property.
If trussing systems are used, installation must be carried out only by instructed or skilled persons.
Follow all applicable European, national and local safety regulations concerning rigging and trussing.
Personal Protective Equipment
During installation and rigging wear personal protective equipment in compliance with the national and
site-specific regulations.
Installation Site Requirements
● The device can be used only indoors.
● The device can be mounted to a truss or another rigging structure in any orientation.
● The minimum distance to other objects must be bigger than 0,5 m.
● The maximum ambient temperature ta = 45 °C must never be exceeded.
● The relative humidity must not exceed 50 % with an ambient temperature of 45 °C.
12
A ccent Spot Q4
Product code: 42541
Rigging
The device can be mounted to a truss or other rigging structure in any orientation. Make sure that all
loads are within the pre-determined limits of the supporting structure.
CAUTION
Restrict the access under the work area during rigging and/or derigging.
To mount the device, follow the steps below:
01) Use a clamp to attach the device to the supporting structure, as shown in Fig. 05. Make sure that the
device cannot move freely.
02) Secure the device with a secondary suspension, for example a safety cable. Make sure that the
secondary suspension can hold 10 times the weight of the device. If possible, the secondary
suspension should be attached to a supporting structure independent of the primary suspension. Put
the safety cable through the , as shown in Fig. 05. safety eye 7)(0
Fig. 05
13
A ccent Spot Q4
Product code: 42541
Angle Adjustment
You can adjust the angle of the device with the 2 . adjustment screws (02)
01) Turn the 2 counterclockwise to release them. adjustment screws (02)
02) Tilt the device the desired angle (see Fig. 06 to ).
03) Turn the 2 clockwise to tighten them. Make sure that the device cannot adjustment screws (02)
move freely after the 2 are tightened. adjustment screws (02)
Fig. 06
Beamshaper Installation
The device is delivered with 2 beamshapers (10° and 40°). To install the beamshapers, follow the steps
below:
01) P the beamshaper on the lens of the device. The magnets in the beamshaper will keep it in ut
position.
02) To remove the beamshaper, hold it by the edge and pull it off.
Fig. 07
14
A ccent Spot Q4
Product code: 42541
Connecti ng to Power Supply
DANGER
Electric shock caused by short-circuit
The device accepts AC mains power at 100 240 V and 50/60 Hz. Do not supply power at any other –
voltage or frequency to the device.
This device falls under IEC protection class I. Make sure that the device is always electrically connected
to the ground (earth).
Before connecting the device to the socket-outlet:
● Make sure that the power supply matches the input voltage specified on the information label on
the device.
● Make sure that the socket-outlet has ground (earth) connection.
Connect the device to the socket-outlet with the power plug. Do not connect the device to a dimmer
circuit, as this may damage the device.
Power Linking of Multiple Devices
This device supports power linking. Power can be relayed to another device via the power OUT
connector. Note that the input and the output connectors have different designs: one type cannot be
connected to the other.
Power linking of multiple devices must be carried out only by instructed or skilled persons.
WARNING
Incorrect power linking may lead to overload of the electrical circuit and result in serious
injuries and damage of property.
To prevent overload of the electrical circuit, when power linking multiple devices:
● Use cables with sufficient current-carrying capacity. The power cable supplied with the device is not
suitable for power linking of multiple devices.
● Make sure that the total current draw of the device and all connected devices does not exceed the
rated capacity of the power cables and the circuit breaker.
● Do not link more devices on one power link than the maximum recommended number.
Maximum recommended number of devices:
at 100 120 V: 50 devices –
at 200 240 V: 50 devices –
15
A ccent Spot Q4
Product code: 42541
5. Setup
Warnings and Precautions
Attention
Connect all data cables before supplying power.
Disconnect power supply before connecting or disconnecting data cables.
Stand-alone Setup
When the Accent Spot Q4 is not connected to a controller or to other devices, it functions as a stand-
alone device. It can be operated manually.
For more information about the control modes, refer to on page 18. 6.2. Control Modes
DMX Connection
DMX-512 Protocol
You need a DMX serial data link to run light shows of one or more devices using a DMX-512 controller or
to run synchronized shows of two or more devices set in a master/slave operating mode.
The Accent Spot Q4 has 3-pin DMX signal IN and OUT connectors.
The pin assignment is as follows: pin 1 (ground), pin 2 (-), pin 3 (+).
Devices on a serial data link must be daisy-chained in a single line. The number of devices that you can
control on one data link is limited by the combined number of the DMX channels of the connected
devices and the 512 channels available in one DMX universe.
To comply with the TIA-485 standard, no more than 32 devices should be connected on one data link.
In order to connect more than 32 devices on one data link, you must use a DMX optically isolated
splitter/booster, otherwise this may result in deterioration of the DMX signal.
Note:
● Maximum recommended DMX data link distance: 300 m
● Maximum recommended number of devices on a DMX data link: 32 devices
16
A ccent Spot Q4
Product code: 42541
DMX Cables
Shielded twisted-pair cables with 3-pin XLR connectors must be used for reliable DMX connection. You
can purchase DMX cables directly from your Highlite International dealer or make your own cables.
If you use XLR audio cables for DMX data transmission, this may lead to signal degradation and unreliable
operation of the DMX network.
When you make your own DMX cables, make sure that you connect the pins and wires correctly as
shown in Fig. . 08
Fig. 08
Master/Slave Setup
The Accent Spot Q4 supports master/slave control mode. To connect multiple devices in master/slave
setup, follow the steps below:
Connect the first device’s DMX OUT connector to the second device’s DMX IN connector.
Repeat step 1 to connect all devices as shown in Fig. 09. The first connected device will be
automatically recognized as the master device.
Set all subsequent devices as slave devices. See on page 26 for more information. 6. 6.6. Slave Mode
Connect a DMX terminator (120 Ω resistor) to the DMX OUT connector of the last device in the setup.
Fig. 09
17
A ccent Spot Q4
Product code: 42541
DMX Linking
To connect multiple devices on one DMX data link, follow the steps below:
Use a 3-pin DMX cable to connect the DMX OUT connector of the lighting controller to the DMX IN
connector of the first device.
02) Connect the first device’s DMX OUT connector to the second device’s DMX IN connector with a
3-pin DMX cable.
03) Repeat step 2 to connect all devices in a daisy-chain as shown in Fig. 10.
04) Connect a DMX terminator (120 Ω resistor) to the DMX OUT connector of the last device on the data
link.
Fig. 10
DMX Addressing
In a setup with multiple devices, make sure that you set the DMX starting address of each device
correctly. The Accent Spot Q4 has 3 personalities: 4 channels, 6 channels and 12 channels.
If you want to connect multiple devices on one data link and use them 12-channel mode, for in
example, follow the steps below:
Set the starting address of the 1st device on the data link to 1 (001).
02) Set the starting address of the 2nd device on the data link to 13 (013), as 1 + = 13. 12
03) Set the starting address of the 3rd device on the data link to 25 25) as + 12 = 25. (0 13
04) Continue assigning the starting addresses of the remaining devices by adding each time 12 to the
previous number.
Make sure that you do not have any overlapping channels in order to control each Accent Spot Q4
correctly. If two or more devices are addressed similarly, they will work similarly.
19
A ccent Spot Q4
Product code: 42541
To operate multiple devices in the master/slave mode:
01) Use the first device as a master and use the remaining devices as slaves. See on 6.6.6. Slave Mode
page for more information. 26
02) Operate the master device in the Auto mode, Manual mode, Built-in Programs mode or the Sound-
controlled mode. For more information, see on page 24, on 6.6.3. Auto Mode 6.6.2. Manual Mode
page 24, on page 25 and on page 26. 6.6.4. Program Mode 6.6.7. Sound-controlled Mode
To operate the device with a DMX controller:
01) Set the DMX starting address of the device in the Address menu. See on page 5.3.5. DMX Addressing
17 and on page 23. 6.6.1.1. DMX Address
02) Select the behavior of the device in case there is no DMX signal in the DMX Fail pop-up submenu.
See on page 28. 6.6.8.4. DMX Failure Settings
03) Select the DMX channel mode. See on page 24 for more information. 6.6.1.2. DMX Channel Mode
See on pages 30 31 for complete overview of all DMX channels. 6.7. DMX Channels –
Control Panel
A) OLED display
B) UP button
C) DOWN button
D) SETUP button
E) MODE button
Fig. 11
● Use the button to exit the current submenu and to return to the Main Menu. MODE
● Use the / buttons to navigate through the menus or to increase/decrease numeric values. UP DOWN
● Use the button to open the desired menu, to confirm your choice or to set the currently SETUP
selected value.
20
A ccent Spot Q4
Product code: 42541
Start- up
Upon start- , the display will show a splash screen with the software version and current temperature of up
the device.
Immediately afterwards, the display will show the start screen (if the device is locked) or the main menu
(if the device is unlocked). The start screen provides information about the operation modes of the
device, the software version, the DMX channel mode and the temperature of the LEDs.
Note:
● If no button is pressed after 30 seconds of inactivity, the display will show the start screen. Press any
button to return to the main menu.
● By default the display is locked. To access the main menu, you need to enter the . Press password
and hold down the and buttons for 3 seconds to unlock the display. See MODE SETUP 6.6.8.6. Display
Lock on page for more informatio 29 n.
21
A ccent Spot Q4
Product code: 42541
Menu Overview
22
A ccent Spot Q4
Product code: 42541
23
A ccent Spot Q4
Product code: 42541
Main Menu Options
01) Press the buttons to select one of the following options: UP/DOWN
● 1. DMX
● 2. Manual
● 3. Auto
● 4. Program
● 5. CCT
● 6. Slave
● 7. Sound
● 8. Settings
● 9. Information
02) Press the button to confirm the selection. SETUP
DMX Settings
In this menu you can configure the DMX settings of the device.
01) Press the buttons to select one of the following options: UP/DOWN
● Address: See 6.6.1.1. DMX Address
● Channels: See 6.6.1.2. DMX Channel Mode
02) Press the button to confirm the selection. SETUP
DMX Address
In this submenu you can set the DMX starting address of the device.
Press the buttons to select the DMX starting address of the device. The selection range is 001UP/DOWN –
512. Refer to on page for more information. 5.3.5. DMX Addressing 17
24
A ccent Spot Q4
Product code: 42541
DMX Channel Mode
In this submenu you can select the DMX channel mode.
01) Press the buttons to select the desired DMX channel mode. There are 3 options available: UP/DOWN
● 4-channel mode
● 6-channel mode
● 12-channel mode
02) Press the button to confirm the selection. SETUP
Manual Mode
In this menu you can manually adjust the color.
03) Press the buttons to scroll through following options: red, green, blue white.UP/DOWN and
04) Press the button to confirm your selection and open the respective submenu where you can SETUP
adjust the values.
05) 255 Press the buttons to adjust the values. The adjustment range is 0UP/DOWN –, from off to high
intensity.
06) Press the button to confirm your choice.SETUP
Auto Mode
In this menu you can run the built-in chase.
01) Press the buttons to choose between YES and NO. If you choose YES, the device will run UP/DOWN
the built-in chase.
02) Press the button to confirm your choice. SETUP
25
A ccent Spot Q4
Product code: 42541
Program Mode
In this menu you can run the built-in programs. 16
01) Press the buttons to select MODE: UP/DOWN
02) Press the button to confirm the selection. SETUP
03) Press the buttons to select one of the 16 available built-in programs: UP/DOWN
● Program 1: See 6.6.4.1. Program 1
● – Programs 2 16: See 6.6.4.2. Program 2–16
04) Press the button to confirm the selection. SETUP
Program 1
In this built-in program you can select one of the 33 color macros and add the strobe effect.
01) Press the buttons to select COLOR: UP/DOWN
02) Press the button to confirm the selection. SETUP
03) Press the buttons to select one of the 33 available color macros. UP/DOWN
04) Press the button to confirm the selection. SETUP
05) Press the buttons to select STROBE: UP/DOWN
06) Press the button to confirm the selection. SETUP
07) Press the buttons to set the strobe frequency. The adjustment range is 0 99, from off to UP/DOWN –
high frequency (0 20 Hz). –
08) Press the button to confirm the selection. SETUP
Program 2 –16
In these built-in programs you can set the program speed and add the strobe effect.
01) Press the buttons to select SPEED: UP/DOWN
02) Press the button to confirm the selection. SETUP
26
A ccent Spot Q4
Product code: 42541
03) Press the buttons to set the program speed. The adjustment range is 1 100, from slow to UP/DOWN –
fast.
04) Press the button to confirm the selection. SETUP
05) Press the buttons to select STROBE: UP/DOWN
06) Press the button to confirm the selection. SETUP
07) Press the buttons to set the strobe frequency. The adjustment range is 0 99, from off to UP/DOWN –
high frequency (0 20 Hz). –
08) Press the button to confirm the selection. SETUP
Correlated Color Temperature
In this menu you can set the color temperature.
01) Press the buttons to select one of the 14 color temperature presets: UP/DOWN
The available CCT presets are: 1800 K, 2200 K, 2700 K, 3000 K, 3200 K, 4000 K, 4500 K, 5000 K, 5600 K,
6000 K, 6500 K, 7000 K, 8000 K 10000 K. and
02) Press the button to confirm the selection. SETUP
Slave Mode
In this menu you can set the slave mode of the device.
01) Press the buttons to choose between YES and NO. If you choose YES, the device will UP/DOWN
operate as a slave in the master/slave mode.
02) Press the button to confirm the selection. SETUP
Sound-controlled Mode
In this menu you can set the sound sensitivity of the device.
01) Press the buttons to set the sound sensitivity. The adjustment range is 0 31, from off to high UP/DOWN –
sound sensitivity.
02) Press the button to confirm the selection. The device will now react to the beat of the SETUP
background music.
27
A ccent Spot Q4
Product code: 42541
Settings
In this menu you can adjust the settings of the device.
01) Press the buttons to select one of the 7 options. UP/DOWN
The available options are:
● 1. Curves Select: See 6.6.8.1. Selecting Dimming Curves
● 2. Dimmer Speed: See 6.6.8.2. Setting Dimmer Speed
● 3. PWM Frequency: See 6.6.8.3. Setting PWM Frequency
● 4. DMX Fail: See 6.6.8.4. DMX Failure Settings
● 5. DMX Sync: See 6.6.8.5. DMX Synchronization
● 6. Lock: See 6.6.8.6. Display Lock
● 7. Factory: See 6.6.8.7. Restoring Factory Settings
02) Press the button to confirm the selection. SETUP
Selecting Dimming Curves
In this submenu you can select dimming curves.
01) Press the buttons to select one of the following 4 options: Linear, Square Law, Inverse UP/DOWN
Square Law and S-Curve
02) Press the button to confirm the selection.SETUP
28
A ccent Spot Q4
Product code: 42541
Setting Dimmer Speed
In this submenu you can set the dimmer speed.
01) Press the buttons to choose one of the 2 options: UP/DOWN
● Fast: Light output will follow DMX dimmer value directly
● Smooth: Light output will follow DMX dimmer value with fade time to create smooth
transitions
02) Press the button to confirm the selection. SETUP
Setting PWM Frequency
In this submenu you can set the PWM frequency.
01) Press the buttons to select one of the following 4 options: UP/DOWN
02) Press the button to confirm the selection. SETUP
DMX Failure Settings
In this submenu you can determine the behavior of the device in case there is no DMX signal.
01) Press the buttons to select one of the following 4 options: UP/DOWN
● Off: The device will black out the light output
● Hold: The device will use the last correctly received DMX signal
● Manual: The device will use the manually selected values for color. See 6.6.2. Manual Mode
on page 24 for more information
● Program: The device will run the built-in programs
02) Press the button to confirm the selection. ENTER
31
A ccent Spot Q4
Product code: 42541
4 CH
6 CH
12 CH
Function
Value
Setting
0 090 84–
Color 12 (R000 G255 B050 W000)
0 0 91–97
Color 13 (R000 G255 B150 W000)
0 98–104
Color 14 (R000 G255 B255 W000)
105 111–
Color 15 (R000 G255 B255 W075)
112 118–
Color 16 (R000 G255 B255 W150)
119 125–
Color 17 (R000 G100 B255 W255)
126 132–
Color 18 (R000 G000 B255 W100)
133 139–
Color 19 (R000 G000 B255 W050)
14 1460–
Color 20 (R000 G000 B255 W000)
147 153–
Color 21 (R075 G000 B255 W000)
154 16–0
Color 22 (R160 G000 B255 W000)
161 167–
Color 23 (R255 G000 B255 W000)
168 174–
Color 24 (R255 G000 B175 W000)
175 181–
Color 25 (R255 G000 B100 W000)
182 188–
Color 26 (R255 G000 B100 W050)
189 195–
Color 27 (R255 G000 B025 W050)
196 202–
Color 28 (R255 G000 B025 W025)
203 209–
Color 29 (R255 G000 B025 W000)
210 216–
Color 30 (R000 G000 B000 W255)
217 223–
Color 31 (R075 G075 B000 W255)
224 230–
Color 32 (R000 G000 B100 W255)
231 255–
Color 33 (R255 G255 B255 W255)
6
Color Switch /
Color Flow
000 015–
No function
016 031–
Color switch 1
032 047–
Color switch 2
048 063–
Color switch 3
064 079–
Color switch 4
080 095–
Color switch 5
096 111–
Color switch 6
112 127–
Color switch 7
128 143–
Color switch 8
144 159–
Color flow 1
160 175–
Color flow 2
176 191–
Color flow 3
192 207–
Color flow 4
208 223–
Color flow 5
224 239–
Color flow 6
240 255–
Color flow 7
7
Color Switch /
Color Flow Speed
000 255–
Speed adjustment, from slow to fast
8
Sound-
controlled Mode
000 050–
No function
051 255–
Sound sensitivity, from low to high sensitivity
9
Red
000 255–
From low to high intensity (0 100 %) –
10
Green
000 255–
From low to high intensity (0 100 %) –
11
Blue
000 255–
From low to high intensity (0 100 %) –
12
White
000 255–
From low to high intensity (0 100 %) –
Note: Make sure that the Strobe channel and the Master Dimmer channel are open 6-CH and 12-CH in
mode to see the light output.
32
A ccent Spot Q4
Product code: 42541
RDM Information
This device supports RDM. Refer to for more information. 6.9.2. Supported RDM PIDs for the Device
RDM Details
● Responder ID: 29B4: 091XXXXX
● Manufacturer's ID: Showtec (Highlite International B.V.)
● Manufacturer Label: Showtec
● Model Description: Accent Spot Q4
● Model ID: 1 (091 hexadecimal) 45
● Device Label: Accent Spot Q4
Note:
An RDM responder ID consists of 3 parts:
● 1st part 4 digits – – Manufacturer’s ID
● 2nd part 3 digits Model ID – –
● 3rd part 5 digits Unique ID – –
The RDM responder IDs of all products of Highlite International start with the same 4 digits. The first 7 digits
of the RDM responder ID for each model are the same. The last 5 digits are different for each device.
Supported RDM PIDs for the Device
Parameter ID
Value
Required
GET
SET
DISC_UNIQUE_BRANCH
0x0001
*
DISC_MUTE
0x0002
*
DISC_UN_MUTE
0x0003
*
SUPPORTED_PARAMETERS
0x0050
*
*
DEVICE_INFO
0x0060
*
*
DEVICE_MODEL_DESCRIPTION
0x0080
*
MANUFACTURER_LABEL
0x0081
*
DEVICE_LABEL
0x0082
*
*
FACTORY_DEFAULTS
0x0090
*
*
SOFTWARE_VERSION_LABEL
0x00C0
*
*
DMX_PERSONALITY
0x00E0
*
*
DMX_PERSONALITY_DESCRIPTION
0x00E1
*
DMX_START_ADDRESS
0x00F0
*
*
*
SENSOR_DEFINITION
0x0200
*
SENSOR_VALUE
0x0201
*
*
IDENTIFY_DEVICE
0x1000
*
*
*
RESET_DEVICE
0x1001
*
33
A ccent Spot Q4
Product code: 42541
7. Troubleshooting
This troubleshooting guide contains solutions to problems which can be carried out by an ordinary
person. The device does not contain user-serviceable parts.
Unauthorized modifications to the device will render the warranty void. Such modifications may result in
injuries and material damage.
Refer servicing to instructed or skilled persons. Contact your Highlite International dealer in case the
solution is not described in the table.
Problem
Probable cause(s)
Solution
The device not does
function at all
No power to the device
● Check if power is switched on and
cables are plugged in
Internal fuse blown is
● Disconnect the device and contact
your Highlite International dealer
The device responds
erratically
The factory settings of the device
are changed
● Reset the device’s parameters to the
default factory settings. See 6.6 .7.8 .
Restoring Factory Settings on page 29
The device does not
respond to DMX
control
The controller is not connected
● Connect the controller
The signal is reversed. The 3-pin
DMX OUT of the controller does not
match the DMX of the device IN
● Install a phase-reversing cable
between the controller and the device
The controller is defective
● Try using another controller
The device responds
erratically to DMX
control
Bad data link connection
● Examine connections and cables.
Correct poor connections. Repair or
replace damaged cables
The data link is not terminated with
a termination plug 120 Ω
● Insert termination plug in the DMX a
OUT connector of the last device on
the link
Incorrect addressing
● Check address settings and correct, if
necessary
In case of a setup with multiple
devices, one of the devices is
defective and disturbs data
transmission on the link
● To find out the defective device,
bypass one device at a time until
normal operation is restored
No light or LEDs cut
out intermittently
LEDs are damaged
● Disconnect the device and contact
your Highlite International dealer
The power supply settings do not
match local AC voltage and
frequency
● Disconnect the device. Check the
settings and correct, if necessary
34
A ccent Spot Q4
Product code: 42541
8. Maintenance
Safety Instructions for Maintenance
DANGER
Electric shock caused by dangerous voltage inside
Disconnect power supply before servicing cleaning. or
Preventive Maintenance
Attention
Before each use, examine the device visually for any defects.
Make sure that:
● All screws used for installing the device or parts of the device are tightly fastened and are not
corroded.
● The safety devices are not damaged.
● There are no deformations on housings, fixations and installation points.
● The lens is not cracked or damaged.
● The power cables are not damaged and do not show any material fatigue.
Basic Cleaning Instructions
The external lens of the device must be cleaned periodically in order to optimize the light output. The
cleaning schedule depends on the conditions at the site where the device is installed. When smoke or
fog machines are used at the site, the device will need more frequent cleaning. On the other hand, if the
device is installed in well-ventilated area, it will need less frequent cleaning. To establish a cleaning
schedule, examine the device at regular intervals during the first 100 hours of operation.
To clean the device, follow the steps below:
01) Disconnect the device from the electrical power supply.
02) Allow the device to cool down for at least 15 minutes.
03) Remove the dust collected on the external surface with dry compressed air and a soft brush.
04) Clean the lens with a damp cloth. Use a mild detergent solution.
05) Dry the lens carefully with a lint-free cloth.
06) Clean the DMX and other connections with a damp cloth.
Attention
● Do not immerse the device in liquid.
● Do not use alcohol or solvents.
● Make sure that the connections are fully dry before connecting the device to the power supply and
to other devices.
