Side 1/2
211 mm (8.29")
197 mm (7.77")
185 mm (7.27") 60 mm
(2.36")
180 mm
(7.08")
80 mm
(3.15")
48 mm
(1.88")
Dimensions
Mounting
AC70 COMPUTER
INSTALLATION GUIDE
*988-10472-001*
1
Micro-C CAN bus backbone
SimNet to Micro-C (male) Drop cable
Micro-C Drop cable (female to male)
Micro-C Power cable with 120 Ohm
terminator, female
Micro-C Drop cable, male
Micro-C T-Joiners
Micro-C Terminator, 120 Ohm, male
1
System wiring
T T
AD80/
SD80
OPTION OPTION
12/24V DC
12/24V DC
12 V DC
AC70 SI80
1*
NMEA 0183
IN/OUT
COMPASS
GPS
SENSOR
4*
NMEA 0183
IN/OUT
THRUSTER
CONTROL
DRIVE UNIT
5
7
6
4
2
3
4
5
6
7
12/24V DC
AP70/80
AUTOPILOT
CONTROL
HEAD
32
AP60
1 * AC70 Computer
1 * Cable retainer
6 * Fixing screws, 3.5 * 19 mm (DIN7981B)
10 * Strips
6 * Connectors
1 * Receptacle
2 * 30 Amp Fuse
1* Micro-C Drop cable (male)
1* Micro-C T-Joiner
1*
Micro-C Power cable with 120 Ohm terminator, female
1* Micro-C Terminator, 120 Ohm (male)
1
2
3
4
5
6
7
8
9
10
11
Parts included
1
5 6 7
8
9
10
11
2
4
3
pro.simrad-yachng.com
For technical specificaons,
cerficates and declaraons,
refer to the product web site on:
www.simrad-yachng.com
AC70 Terminal layout
CAN Bus backbone
Rudder Feedback
Steering Levers External I/O External alarm
External system selector NotesNMEA 0183 devices
Drive units
Power supply
DRIVE
30 A FUSE
DRIVE
ENGAGE
SUPPLY NMEA0183
ALARM MODE
REMOTE
SIMNET
RUDDER
POLARITY
LEDS
REMOTE
NMEA0183
RUDDER
SIMNET
GND
PORT
STBD
LAMP
R35/R3000X
*
*
SIMRAD
S35
SIMRAD R3000X
STBY AUTO
S9
S9
R3000X S9
S35 JS10
IEC61162-1/2
(NMEA0183)
DEVICES
ENGAGE SIGNAL
RX1
Rx_A
Rx_B
Tx _A
Tx_B
REVERSIBLE PUMP
BACKBONE
CONNECT WIRES
CHECK POLARITY INSTALL FUSE POWER ON
MOTOR
ROTARY DRIVE SOLENOID VALVE *
NOTE 2
NOTE 2
NOTE 1
CLUTCH
MOTOR
SOL GND
SOL-1
SOL-1
RF300
RF45X
D
G
Supply
S
CMD
RET
* Solenoid valves, 12 V DC or 24 V DC,
powered from AC70.
L’AC70 ne peut pas commander des électrovannes sans
utiliser un relais isolé. Se référer à FAQ:
AC70 kann keine extern gespeisten Magnetventile ansteuern
sofern keine isolierten Relais installiert sind. S. auch FAQ:
AC70 kan ikke kobles mot magnetventiler med eksternt tilført
spenning uten at man benytter eksterne releer. Se FAQ:
AC70 cannot operate externally powered solenoids unless installing isolating relays.
Refer to FAQ: www.simrad-yachting.com and
pro.simrad-yachting.com
NOTE 1 Pour augmenter le nombre de ports NMEAO183, utilisez SI80
ou AT10.
Um weitere NMEA0183 Ports zu erhalten, verwenden Sie
bitte ein SI80 oder AT10
For å få tilgang til ere NMEA porter kan man benytte SI80
eller AT10.
For further expan-
sion of NMEA 0183
ports, use SI80 or
AT10.
www.simrad-yachting.com
pro.simrad-yachting.com
MOTOR
SOL-1
MOTOR
SOL-2
MOTOR
SOL-1
MOTOR
SOL-2
SOL
GND
CMD
RET
CMD
RET
DRIVE DRIVE DRIVE
DRIVE
ENGAGE
DRIVE
ENGAGE
MOTOR
SOL-1
MOTOR
SOL-2
RED
BLK
WHT
BLU
NET-S
NET-C
NET-H
NET-L
FRQ +
FRQ -
MODE
MANUAL
AUTOPILOT
SYSSEL
RET
SYSSEL
RET
ALARM
+
RET
+ -
POWER SWITCH
OFF
POWER SWITCH
OFF
POWER SWITCH
ON
POWER SWITCH
ON
1
2 3 4
12/24 V DC 12/24 V DC
FUSE NOT
INSTALLED
FUSE
INSTALLED
FUSE NOT
INSTALLED
AP70/80AP60 AP70/80AP60
AP70/80AP60
AP70/80AP60AP70/80AP60
AP70/80AP60AP70/80AP60
AP70/80AP60
+_
+_
+_
OPTION OPTION OPTION
OPTION
Grounding
TO SHIP’S
MAIN
GROUND
