ForwardScan | User Guide
Installation
Connecting the transducer
The ForwardScan™ transducer can be connected to the
StructureScan port on the SonarHub or the NSS evo2, leaving the
sonar port open for a CHIRP transducer. Refer to the ForwardScan
installation manual for transducer installation instructions.
Sonar performance
The accuracy of the sonar depth display can be aected by many
factors, including the type and location of the transducer and
water conditions. Never use this equipment to gauge depth or
other conditions for swimming or diving.
The choice, location, and installation of transducers and other
components of the system are critical to the performance of the
system as intended. If in doubt, consult your dealer.
To reduce the risk of misusing this equipment, you must read and
understand all aspects of the supplied documentation.
Sharing ForwardScan data
ForwardScan data can be shared with NSO evo2, NSS evo2 or
Zeus2 displays by connecting the forward-looking transducer to a
SonarHub on your Ethernet network.
You can also connect the transducer to a NSS evo2 to share
ForwardScan data with multi-function displays on your Ethernet
network.
¼Note: We do not recommend operating dierent brands of multi-
function displays on the same network.
Do not rely on this equipment as your principle
Warning:
source of navigation or hazard detection.
ForwardScan™ Sonar
User guide
It is the owner’s sole responsibility to install and Warning:
use the equipment in a manner that will not cause accidents,
personal injury or property damage. The user of this product is
solely responsible for observing safe boating practices.
2 | ForwardScan | User Guide
Operation
ForwardScan™ forward-looking sonar is a navigational aid that
helps you monitor the depth in front of your vessel.
ForwardScan features are available in the latest software update
for your multi-function display. Refer to your display’s brand
website to download the latest update.
¼Note: Screen captures in this document are from a NSS evo 2 unit.
The look of your unit may dier slightly, but it will operate in a
similar manner.
Key Description
1Transducer location shown as the origin on the screen
2Depth range scale/Boat position
3Point data
4Depth history
5Bottom
6Forward range scale
1
2
3
4
5
6
