Side 1/4
M AG06V3
OUTD O O R SPE A KE R
I N S T R U C T I O N M A N UA L
Scan QR Code
for product
installation video
INTRODUCTION
Thank you for purchasing Sonance MAGO6V3
weather-resistant speakers.
When properly installed, these speakers will give you
many years of outdoor entertainment pleasure. To get the
most out of your new speakers, please read this manual
thoroughly before you begin installation.
SONANCE OUTDOOR SPEAKER
MAGO6V3 INSTRUCTION MANUAL
BOX & CONTENTS
(2) Sonance MAGO6V3 speakers
(2) Speaker grilles
(2) Mounting brackets
(2) Wire terminal covers
(1) Set of mounting hardware
CONNECTING & ASSEMBLING
WARNING: TURN THE AMPLIFIER’S POWER OFF UNTIL YOU
HAVE COMPLETED ALL OF THE CONNECTIONS AND HAVE
DETERMINED THAT THEY ARE CORRECT. (IF THE AMP’S AC
PLUG IS ACCESSIBLE WE RECOMMEND THAT YOU UNPLUG
IT FROM THE WALL OUTLET TO AVOID ACCIDENTAL
TURN-ON AND POSSIBLE DAMAGE TO THE AMPLIFIER.)
SPEAKER PLACEMENT
Sonance MAGO6V3 Speakers are highly weather-resistant,
and when mounted outdoors will perform exceptionally well
for years even under adverse weather conditions.
The Sonance FastMount® bracket system makes it easy to
mount the speakers in a variety of positions and locations:
(see figure 1).
The best performance is obtained by placing the speakers at
ear level, facing the listeners.
• If you are mounting the speakers above or below ear level,
pivot them up or down to direct the sound towards the listeners.
Under an eave
Against a wall
(flush)
In a corner
Pole mount
(hardware sold separately)
FIGURE 1:
SPEAKER PLACEMENT
FIGURE 2:
PASS WIRE
THROUGH HOLE
1. In most cases you will be able to attach the
FastMount brackets directly to the mounting
surface. Run the speaker wires from the
amplifier to the speaker locations and through
the holes in the brackets (see figure 2).
2. Attach the FastMount brackets to the
mounting surface using the included
hardware that is appropriate for the type
of surface (see figure 3).
If the installation requires that the speaker
be mounted in a corner, attach the bracket
with hardware through the slots in the
angled corners (see figure 4).
3. If the installation requires that the speaker
be mounted on a pole you can attach the
FastMount brackets to the pole using 2.5”
U-bolts (not included) (see figure 5).
4. Feed the speaker wires from the bracket
into the wire entry grommet on the back
of the speaker, through the wire tunnel
and out the opening on the speaker’s
front panel (see figure 6).
5. Slide the speaker onto the bracket until
the locks snap into place. Pull enough
wire through the front of the speaker to
allow connection to the terminals
(see figure 7).
NOTE: TO INCREASE WATER RESISTANCE AND
MAKE INSTALLATION EASIER, THE SPEAKER
WIRE TERMINALS ARE LOCATED ON THE
MAGO6 SPEAKERS’ FRONT PANEL. BE SURE
TO LEAVE ENOUGH WIRE AT THE SPEAKER
LOCATION TO FEED THROUGH THE TUNNEL
IN THE SPEAKER ENCLOSURE AND CONNECT
TO THE TERMINALS ON THE FRONT.
FIGURE 3:
ATTACH BRACKET
FIGURE 4:
CORNER MOUNTING
• The grommet forms a water-resistant
seal around the speaker wire.
• Make sure there is enough slack in
the wire to allow the speaker to
pivot on the bracket.
FIGURE 5:
ATTACHING THE
BRACKET TO A POLE
FIGURE 6:
WIRE ENTRY
GROMMET
FIGURE 7:
ATTACH SPEAKERS
TO BRACKETS
