Quick Start Guide

Mac® Compatibility

•

Mac (Intel

or M1) with Thunderbolt 3 ports

• macOS

10.13.6+

• macOS Big Sur compatible

Windows® Compatibility

• PC with Thunderbolt 3 or Thunderbolt 4 ports

• Windows 10 (64-bit Edition Version 2004 or greater)

Important Note: Windows computers require the latest BIOS and

Thunderbolt drivers to support this product. Check with your

computer manufacturer for update information.

Linux® Compatibility

• PC with Thunderbolt 3 ports

• Linux Kernel 5.0 or later

Thunderbolt 3 Connector—Plug this connector into one of your

computer’s Thunderbolt 3 ports (often indicated by a

logo), or at the

end of a Thunderbolt device chain. Ports marked with the USB icon

(

) are NOT compatible.

Driver Information

For Mac users, the drivers required to support this product are

installed as part of macOS 10.13.6 and later; the Sonnet adapter is

ready for use when you power on your computer.

For Windows users, please go to www.sonnettech.com/support/

kb/kb.php. Navigate to and click the Solo10G SFP+ Thunderbolt 3

Edition link, and then click the Driver link. Locate, download, and

install the Windows drivers.

For Linux users, the drivers required to support this product are

installed as part of Linux Kernel 5.0 and later, though more current

drivers may be available: Go to www.sonnettech.com/support/

kb/kb.php, navigate to and click the Solo10G SFP+ Thunderbolt 3

Edition link, and then click the Driver link. If the listed Linux driver

version is later than the one installed in your system, download and

install the drivers.

Solo

™

SFP+ Thunderbolt

™

Edition

10 Gigabit Ethernet to Thunderbolt 3 Adapter

with 10GBASE-SR (Short-range) SFP+ Transceiver

Support Note: This document was up to date at the time of

printing. However, changes to the

hardware or software may have occurred since then. Please check the

Sonnet website for the latest documentation.

1. Go to https://www.sonnettech.com/support/kb/kb.php

2. Navigate to and click the Solo10G SFP+ Thunderbolt 3 Edition link.

3. Click the Manual link.

4. Click the Solo10G SFP+ Thunderbolt 3 Edition Quick Start Guide

[English] link and then check the Document Version information. If

the version listed is later than this document (revision D), click the

Download Now button for the latest version.

Solo10G SFP+ Thunderbolt 3 Edition (T3E) Description

1 – SFP+ Socket

Insert the included short-range SFP+ optical transceiver into the

socket, making sure it is ﬁrmly seated and secured. Alternatively,

you can install a long-range SFP+ transceiver or an RJ45 SFP+

copper transceiver (both sold separately). You may even use a

direct-attached SFP+ terminated copper cable up to 10 meters

long (sold separately) to connect to a switch or storage system.

2 – Link/Activity Indicator

This LED lights up green to indicate a link is established between

the adapter and the switch, and ﬂashes yellow when the link is

training.

3 – Link Speed Indicator

When a link is established between the adapter and the switch,

this LED lights to indicate the link speed to the switch: green =

10Gb, yellow = lower speeds.

trademarks of Sonnet Technologies, Inc. Mac, the Mac logo, and macOS are trademarks of Apple Inc., registered in the United

States and other countries. Thunderbolt and the Thunderbolt logo are trademarks of Intel Corporation in the U.S. and/or other

countries. Other product names are trademarks of their respective owners. Product specifications subject to change without notice.

QS-SOLO10G-SFP-TB3-E-D-061821

Basic Configuration Information—Windows

Conﬁgure the Solo10G adapter’s settings using Windows Device

Manager. You may locate the device in the Network adapters

category, listed as Sonnet Solo 10G SFP+ Thunderbolt 3 Edition.

First Time Use—Windows

The ﬁrst time you connect the Solo10G SFP+ Thunderbolt 3 Edition

adapter to your computer, an Approve New Thunderbolt

™

Devices

window will appear. From the drop-down menu select Always

Connect, and then click OK.

Basic Confiruration Information—Linux

The steps necessary to conﬁgure the Sonnet adapter with your

computer may vary based on the version of Linux running. Sonnet

recommends using whatever method or tools you would normally

use for conﬁguring any onboard ports.

Basic Configuration Information—macOS

With the Solo10G adapter connected to your computer and network

infrastructure, conﬁgure the adapter’s settings in the System

Preferences’ Network preferences panel. The adapter will be identiﬁed

as Thunderbolt Ethernet Slot x.

Performance Tuning Steps—macOS

Listed below are steps required to conﬁgure the Solo10G SFP+ T3E

adapter for maximum performance.

1. Open System Preferences, and then click Network. In

the Network preferences panel, click the Solo10G adapter

(Thunderbolt Ethernet, Slot x) in the left panel, and then click

Advanced; a new panel appears.

2. In the Advanced panel, click Hardware. From the Conﬁgure

drop-down menu, select “Manually”. In the Speed drop-down

menu, leave the setting at 10G… In the Duplex drop-down

menu, select “full-duplex” ( “full duplex, ﬂow-control”). In not

the MTU drop-down menu, select “Custom,” and then enter

“9000” in the box below.

3. When you’ve ﬁnished changing the settings, click OK.

4. Back in the main Network window, click Apply after you’ve

completed changing the settings.

Additional Advice—Use in macOS Server Environmnet

If you’re in a macOS server environment, you may need to take

additional steps to maximize performance.

• If your server is running 10.13.6+ enable SMB protocol, and disable

AFP protocol.

• If your server is running 10.12.6- enable AFP protocol, and disable

SMB protocol.

Contacting Customer Service

The Sonnet Web site located at https://www.sonnettech.com has

the most current support information and technical updates. Before

contacting Customer Service, please check our Web site for the latest

updates and online support ﬁles, and check this Quick Start Guide

for helpful information.

Email support requests generally receive the fastest responses, and are

usually processed within a 24-hour period during normal business

hours, excluding holidays. When you contact Customer Service,

have the following information available so the customer service

staff can better assist you:

• Product name

• Computer model

• A System Report (macOS), or a Microsoft System Information

MSINFO32 (Windows) report (Windows), along with a description

of the issue(s) you are encountering with your device

If further assistance is needed, please contact Sonnet Customer

Service at:

E-mail: support@sonnettech.com

Tel: 1-949-472-2772

(Monday–Friday, 9 a.m.–5 p.m. Paciﬁc Time, excluding holidays)

Japan Customers

Contact Sonnet Customer Service Japan at:

E-mail: jp.support@sonnettech.com

Support Note: In order to realize maximum performance,

the adapter’s duplex setting must be set to full-duplex, and the

MTU (frames) setting set to Jumbo (9000). For a large frame to be

transmitted intact from end to end, every component in the path

must support that frame size. The switches, routers, and NICs from

one end to the other must all support the same size of jumbo frame

transmission for a successful jumbo frame communication session.

Produkt Specifikationer

Mærke:	Sonnet
Kategori:	Netværkskort/adapter
Model:	Solo10G SFP+
Bredde:	79.5 mm
Dybde:	124.5 mm
Højde:	27.2 mm
Vægt:	260 g
Antal pr. pakke:	1 stk
Ethernet LAN:	Ja
Driftstemperatur (T-T):	0 - 35 °C
Ethernet LAN-datahastigheder:	1000,10000 Mbit/s
Forbindelsesteknologi:	Ledningsført
Kabelteknologi:	10GBase-T
Netværksstandarder:	IEEE 802.3az
Understøttede netværksprotokoller:	TCP, UDP
Understøttede Windows-operativsystemer:	Ja
Understøttede Mac-operativsystemer:	Ja
Understøttede Linux-operativsystemer:	Ja
Værtsgrænseflade:	Thunderbolt 3
Grænseflade:	Fiber
Intern:	Ingen
Maksimal dataoverførselshastighed:	10000 Mbit/s
Fiber optisk strømstik:	SFP+
Fuld duplex:	Ja
Ethernet-grænsefladetype:	10 Gigabit Ethernet
Komponent til:	PC
Flowkontrol support:	Ja
Fiberkanal porte:	1
LAN Kontroller:	Aquantia AQC100S
