Side 1/20

Network Surveillance Products

Quick Reference Guide

HD image quality with high sensitivity and wide dynamic range.

W Series with IPELA ENGINE PRO System

The W Series cameras are the most advanced rapid dome cameras in the security industry and adopt the top-end

signal processing system – IPELA ENGINE™ PRO. This series consists of four models – two indoor and two outdoor unitized

models – all of which provide advanced features such as a 130dB dynamic range in FHD with View-DR technology, 60p

high frame rate, 30x optical zoom, pan speed of 700°/s, Gyroscopic Image Stabilizer, Defog Image Processing, and Focal

Plane Distortion Correction. The SNC-WR630 and SNC-WR600 are 1080p and 720p models, while the SNC-WR632 and

SNC-WR602 are 1080p and 720p unitized models.

V and E Series with IPELA ENGINE EX System

The V Series cameras are the top of the line in the EX series with value-added features, while the E Series cameras are

more cost-effective compared to the V Series, and are best suited for entry-to-mid level applications. Both series provide

a variety of features, such as View-DR®, picture mode, H.264 CBR/VBR with high/main profiles, Image Stabilizer, easy

installation (Easy Zoom, Easy Focus), and DEPA™ Advanced Intelligent Video Analytics. The value-added features for the

V Series include a 60p high frame rate and Edge Storage (onboard recording with SD cards). Both series offer a range

of models with various form factors including vandal-resistant, IR ruggedized mini dome, and box-type models.

IR Ruggedized Cameras

Sony’s IR ruggedized mini dome cameras are designed for use in harsh outdoor environments, where lighting conditions during the night

are poor, and dust/water ingress as well as vandalism may pose challenges. This type of camera features a minimum illumination of 0 lx in

B/W mode using built-in IR illuminators, an operating temperature range from -40°F (-40°C) to +122°F (+50°C), and IK10-rated vandal resistant

and IP66-rated water-resistant/dust-tight features. There are four models in the product range: The V Series offers the SNC-VM632R 1080p and

SNC-VM602 720p models, while the E Series offers the SNC-EM632R 1080p and SNC-EM602 720p models.

Half-inch Full HD CMOS Sensor Camera

The SNC-VB635 camera is designed for use in highly demanding conditions such as transportation, municipality, and energy applications.

Thanks to the high sensitivity of its 1/1.9-type 1080p Exmor

® CMOS sensor, this camera can provide high picture quality even in very low-light

conditions. Other key features include a 90 dB dynamic range with View-DR technology, True Day/Night, and RS-485 external control.

C Series with IPELA ENGINE EX System

The C Series offers 720/30p compact cameras that adopt an all-in-one design, incorporating a passive IR sensor,

white-light LED illuminators, a speaker, and a microphone. Another convenient feature is Edge Storage (onboard

recording with micro SD cards). These cameras provide high picture quality with a wide horizontal viewing angle of 120°.

There are two models in the C Series: The SNC-CX600W is a wireless network model that offers easy, reliable, and stable

network operation thanks to the WPS (Wi-Fi Protected Setup) standard, Wi-Fi certification, and the WMM (Wi-Fi Multimedia)

standard, while the SNC-CX600 is a PoE (Power over Ethernet) model that requires just a single network cable for data

transmission and power supply.

X Series with IPELA ENGINE EX System

X Series cameras are 1080/30p mini dome models that are primarily designed for use in vehicles and for outdoor

applications such as retail, banking, and education. Key features include a 90 dB dynamic range with View-DR

technology, IK10 vandal resistance, IP66 ingress protection, and Image Stabilization. There are three models in the X

Series: The SNC-XM632 is a perfect choice for for general outdoor applications, while the SNC-XM636 and SNC-XM637 are

ideal for train surveillance, providing high picture quality with a wide horizontal viewing angle of approximately 83° and

113°, respectively.

360° Hemispheric-view Camera (H Series)

The SNC-HM662 is a 360° hemispheric-view dome camera with a 5 megapixel CMOS sensor. It can be used for activity monitoring and

situational awareness in various environments such as retail outlets, education, and office buildings. The SNC-HM662 provides a variety of 11

view modes that include a 360° hemispheric view, 180° panoramic view, and multiple view. Other key features include IP66 ingress protection,

IK10 vandal resistance, two-way audio, and Edge Storage (onboard recording with micro SD cards).

* The SNC-HM662 is not equipped with an IPELA ENGINE processor.

All other V, E, X and Z series do not include IPELA ENGINE signal processing system.

New Lineup of IPELA ENGINE Network Cameras 2

Network Fixed Cameras 3, 4

Network Mini Dome Cameras 5, 6, 7, 8

Network Rapid Dome and PTZ Cameras 9, 10, 11, 12

Hybrid Camera Solutions 13, 14

Surveillance Video Encoders 15, 16

Network Surveillance Recording Servers 17

Intelligent Monitoring Software 18

New Lineup of IPELA ENGINE Network Cameras

Table of Contents

Produkt Specifikationer

Mærke:	Sony
Kategori:	Overvågningskamera
Model:	SNC-WR600
Type:	IP-sikkerhedskamera
Vekselstrømsindgangsspænding:	12-24 V
Bredde:	146.3 mm
Dybde:	146.3 mm
Højde:	204.5 mm
Vægt:	1700 g
Produktfarve:	Black, White
Wi-Fi:	Ingen
Formfaktor:	Konveter
Understøttede videotilstande:	720p
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved opbevaring (H-H):	20 - 95 %
Ethernet LAN-porte (RJ-45):	1
Udgange til hovedtelefoner:	1
Ethernet LAN:	Ja
Understøttede videoformater:	H.264
Driftstemperatur (T-T):	-5 - 50 °C
Maksimal opløsning:	1280 x 720 pixel
Understøttede grafikopløsninger:	1280 x 720 (HD 720)
Forbindelsesteknologi:	Ledningsført
Kabelteknologi:	10/100Base-T(X)
IP-adresse filtrering:	Ja
Monteringstype:	Loft
Diameter:	146.3 mm
Understøttet placering:	Indendørs
Mikrofonindgang:	Ja
Hvidbalance:	ATW
Sensortype:	CMOS
Samlet antal megapixels:	1.3 MP
Optisk zoom:	30 x
Digital zoom:	12 x
Grænseflade:	RJ-45
Hældningsvinkelområde:	0 - 220 °
Strøm over Ethernet (PoE):	Ingen
Dag/nat funktion:	Ja
Minimumsbelysning:	0.03 Lux
Panoreringsområde:	0 - 360 °
Rotationsvinkel:	360 °
Optisk sensorstørrelse:	1/2.8 "
Zoom kapacitet:	Ja
Nattesyn:	Ja
Billedhastighed:	60 fps
Bevægelsessensor (video):	Ja
Synsfelt vinkel (FOV):	360 °
Brændviddeområde:	4.3 - 129 mm
PTZ-kontrol:	Ja
Hældningshastighed:	700 grader i sekundet
Panoreringshastighed:	700 grader i sekundet
Effektiv sensoropløsning:	1.37 pixel
Objektivets synsvinkel, vandret:	180 °
Objektivets synsvinkel, lodret:	180 °
