Technical Instructions

SAT attenuator units

SDE 4415/5 F and SDE 4420/5 F

The SAT attenuator units reduce the RF levels of one SAT system.

In conjunction with a multiswitch for more than one SAT position,

you can adjust different receiving levels of several SAT positions.

Each one of the four SAT IF is attenuated with 5 dB.

SDE 4415/5 F : for multiswitches with 15mm connector distance

(e.g. SMS 9989 U)

SDE 4420/5 F : for multiswitches with 20mm connector distance

(e.g. SMS 9949 NF, SMS 92009 NF)

INSTALLATION:

The input cables need f-male connectors. The unit can directly be

plugged on the IF input of the multiswitch.

Additional Features:

The permissible ambient temperature

range is: -20° C ... +50° C.

SPAUN electronic confirms the keeping of the EMC

requirements in accordance to the EU product norm

EN 50083-2 and the keeping of the safety requirements

in accordance to the EU product norm EN 50083-1

by the CE sign.

The attenuator units meet the more stringent screening

requirements according to EN 50083-2, quality grade A.

Technical data:

Type SDE 4415/5 F SDE 4420/5 F

Frequency range 950 ... 2200 MHz 950 ... 2200 MHz

Through loss 5 dB 5 dB

Isolation of trunklines > 35 dB > 40 dB

DC through path 2 A 2 A

Dimensions 63 x 66 x 21 mm 78 x 66 x 21 mm

Produkt Specifikationer

Mærke:	Spaun
Kategori:	TV signal forstærker
Model:	SDE 4420/5 F
Produktfarve:	Børstet stål
Driftstemperatur (T-T):	-20 - 50 °C
Dimensioner (BxDxH):	78 x 66 x 21 mm
Frekvensområde:	950 - 2200 MHz
Stik:	F
Porte, antal:	4
