Thank you for purchasing SureCall’s Fusion5X cellular signal booster kit. Fusion5X was specically designed
to eliminate frustrations over dropped calls, limited range and slow data rates by amplifying incoming and
outgoing cellular signals in buildings up to 20,000 square feet.
The Fusion5X provides enhanced cellular signals for multi-carrier voice and 4G LTE data.
If you have any questions during setup, please reach out to our US-based experienced support technicians:
Call: 1-888-365-6283
Email: support@surecall.com
Or, chat: www.surecall.com, 7:00 am – 5:00 pm PST, Monday – Friday
Watch installation,
optimization and
troubleshooting
techniques in
our SureCall Uni-
versity YouTube
channel
@SureCall
Stay up to date
with all things
SureCall
Table of Contents
How It Works .......................................................................................................................................................4
Package Contents ...............................................................................................................................................5
Before Installation ................................................................................................................................................7
Installation Overview ...........................................................................................................................................7
Step 1. Find the area with the Strongest Signal .................................................................................................8
Step 2. Install the Outdoor Antenna ....................................................................................................................8
Step 3. Install the Indoor Antennas ..................................................................................................................10
Option A: Install Indoor Dome Antennas ...........................................................................................................10
Option B: Install Indoor Panel Antennas ...........................................................................................................11
Step 4. Install the Signal Booster ......................................................................................................................13
Booster Hardware .............................................................................................................................................14
LED Indicators ...................................................................................................................................................14
If you Want to Improve Coverage ......................................................................................................................15
Troubleshooting .................................................................................................................................................15
Specications ....................................................................................................................................................16
Kitting Information .............................................................................................................................................17
Three-Year Product Warranty ............................................................................................................................18
FCC, IC and Safety Information ........................................................................................................................18
