Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: March 7, 2019 3:58 PM

Product Diagram (ST121HD20V)

Transmitter

Port Function

Front

1Service Port • Used for rmware updates.

2EDID Switch • Used to copy EDID settings from the Video

Sink Device HDMI Receiver connected to the .

3IR Out Port • Used to connect the to the IR Blaster HDMI

Transmitter.

4RJ45 Port

• Used to connect the to the Transmitter

Receiver.

• Illuminates Green when the Power Indicator:

Transmitter is receiving power.

• Illuminates Amber Connection Indicator:

when the is sending a HDMI Transmitter

signal to the . HDMI Receiver

Back

5HDMI In Port • Used to connect a to the Video Source Device

HDMI Transmitter.

6HDMI Out Port • Used to connect a to the Display Device HDMI

Transmitter.

7DC 12V Port

• Used to power the and HDMI Transmitter

HDMI Receiver (using POE Power Over

Ethernet).

HDMI over CAT6 Extender | 4K 60Hz

Receiver

Port Function

Front

1Service Port • Used for rmware updates.

2IR In Port • Used to connect the to the IR Receiver HDMI

Receiver.

3RJ45 Port

• Used to connect the to the HDMI Receiver

HDMI Transmitter.

• Illuminates Green when the Power Indicator:

Receiver is receiving power.

• Illuminates Amber Connection Indicator:

when the is sending a HDMI Transmitter

signal to the . HDMI Receiver

Back

4HDMI Out Port • Used to connect a to the Display Device HDMI

Receiver.

Requirements

For the latest requirements and full manual, please visit www.startech.com/

ST121HD20V

2 3 4 5 6 7 1 2 3 4

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void

the user’s authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:

(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may

cause undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation

est autorisée aux deux conditions suivantes:

(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d’en compromettre le fonctionnement.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-

party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the

property of their respective holders.

Warranty Information

This product is backed by a two-year warranty.

For further information on product warranty terms and conditions, please refer to .www.startech.com/warranty

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of

business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

Safety Measures

• If product has an exposed circuit board, do not touch the product under power.

Mesures de sécurité

• Si l’un des circuits imprimés du produit est visible, ne pas touchez le produit lorsqu’il est sous tension.

安全対策

• 製品に露出した状態の回路基盤が含まれる場合、電源が入っている状態で製品に触らないでください。

Misure di sicurezza

• Se il prodotto p2-ha un circuito stampato visibile, non toccare il prodotto quando è acceso.

Säkerhetsåtgärder

• Rör aldrig vid enheter med oskyddade kretskort när strömmen är påslagen.

FR: fr.startech.com

DE: de.startech.com

ES: es.startech.com

NL: nl.startech.com

IT: it.startech.com

JP: jp.startech.com

StarTech.com Ltd.

45 Artisans Cres

London, Ontario

N5V 5E9

Canada

StarTech.com Ltd.

Unit B, Pinnacle 15

Gowerton Rd,

Brackmills

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

2500 Creekside

Parkwy

Lockbourne, Ohio

43137

U.S.A.

HDMI Transmitter:

1. Connect the to the on the .IR Blaster IR Out Port HDMI Transmitter

2. Position the directly in front of the (if IR Sensor Video Source Device’s IR Sensor

you’re unsure, check the manual of your video source to determine the IR sensor

location).

HDMI Receiver:

1. Connect the to the on the .IR Receiver IR In Port HDMI Receiver

2. Position the where you’ll point your .IR Sensor IR Remote Control

Installation

Installing the HDMI Transmitter or Receiver

1. Set up the (e.g. computer) and the (place/mount Video Sink Device Display Device

the display appropriately).

2. Position the near the you set up in step 1.HDMI Transmitter Video Sink Device

3. Connect an from the to the on the HDMI Cable Video Sink Device HDMI In Port

back of the .HDMI Transmitter

4. Position the near the you set up in step 1.HDMI Receiver Display Device

5. Connect a (cables sold separately) to the on the back of the CAT6 Cable RJ45 Port

HDMI Transmitter RJ45 Port HDMI Receiver and to the on the back of the .

Note: The cabling should not go through any networking equipment (e.g. router,

switch, etc.).

6. Connect an to the on the back of the HDMI Cable HDMI Out Port HDMI Receiver

and to the .Display Device

7. Connect the to the on the Universal Power Adapter DC 12V Port HDMI

Transmitter AC Electrical Outlet HDMI Transmitter and to an to power both the

and (using Power Over Ethernet).HDMI Receiver

Installing the IR Blaster and IR Receiver

The and can be connected to either the or IR Receiver IR Blaster HDMI Transmitter

HDMI Receiver.
