Introduction

Thank you for purchasing a StarTech.com HD/VGA

with Audio to HDMI Format Converter. This product

allows you to transfer audio and video to output on

one HDMI cable, converting your analog signal to

digital without having to pay for costly upgrades.

Features

• 1 x 5v Power Adapter

• 1 x PC/YPbPr input socket

• 1 x HDMI Output socket

Before You Begin

System Requirements

• A VGA/YPbPr source (NOTE: when using

YPbPr source, a VGA to 3 RCA adapter is

required)

• An HDMI cable

• A display with at least 1 HDMI input

Basic Setup

Connecting the video source to the converter

Connect the VGA/YPbPr output cable from the signal

source to the located on the con-PC/YPbPr INPUT

verter. Using the Input format switch located to the left

of the input, select the appropriate type of source sig-

nal (HD/YPbPr or PC/RGBHV). Note: An RCA 3 to

VGA adapter may be required to make this connec-

tion.

Connecting the audio source to the converter

Connect the audio source to the red and white

sockets labelled on the back of theAUDIO INPUT

converter.

Connecting the converter to the display

Using a standard HDMI cable (see accessories), con-

nect the converter to your video display.

Powering the converter

Connect the tip on the power adapter (provided) to

the port marked on the video converter.DC/5V

Connect the opposite end to a wall outlet or other

suitable power source.

The red light located above the power input will illumi-

nate, indicating that your HD/VGA to HDMI converter

is functioning.

Accessories

ZENHDMI2

6.6 ft (2m) HDMI Digital Audio/Video Cable

ZENHDMI1

3.3 ft (1m) HDMI Digital Audio/Video Cable

ZENHDMI4

13.1 ft (4m) HDMI Digital Audio/Video Cable

Specifications

HD/VGA with Audio to HDMI Format

Converter

VGAHD2HDMI

Revised: 26 June 2006 (B)

Support, Warranty Information, and Regulatory Compliance Statement

If you ever need help with your product, visit and access our com-www.startech.com/support

prehensive selection of online tools, documentation, and downloads. This product is backed by a

one-year warranty. In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase. During this period,

the products may be returned for repair, or replacement with equivalent products at our discre-

tion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products

from defects or damages arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability: In no event shall the liability of StarTech.com Ltd. and StarTech.com USA

LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any

pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for

the product. Some states do not allow the exclusion or limitation of incidental or consequential

damages. If such laws apply, the limitations or exclusions contained in this statement may not

apply to you.

FCC Compliance Statement: This equipment has been tested and found to comply with the lim-

its for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and used

in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which can be deter-

mined by turning the equipment off and on, the user is encouraged to try to correct the interfer-

ence by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is con-

nected.

• Consult the dealer or an experienced radio/TV technician for help.

Video Input 1 x HD-15 VGA Male

Video Output HDMI 1.0

Dimensions (LxWxH) 105 x 76 x 30mm

Weight 1.35 lbs

Power DC 5V, 2.6A

Certification

(Regulatory)

FCC, CE

Resolution/Refresh

Rates:

PC: 640x480

@60Hz

@72Hz

@75Hz

@85Hz

800x600

@60Hz

@72Hz

@75Hz

@85Hz

1024x768

@60Hz

@72Hz

@75Hz

@85HZ

1280x1024

@60Hz

@75Hz

@85Hz

1600x1200

@60Hz

HD: 480i

@60Hz

576p

@50Hz

720p

@60Hz

@50Hz

1080i

@60Hz

@50Hz

@30Hz

@25Hz

@24Hz
