USER MANUAL
18300 MT. BALDY CIRCLE
FOUNTAIN VALLEY, CA 92708-6122
WWW.SUREFIRE.COM
Patent: 8,222,138
Revision A 2-2022
71-01-1142
P1RZ-IB-DF
P1RZ-B-DFT
P1RZ-B-DFT
P1RZ-IB-DF
THE SUREFIRE NO-HASSLE GUARANTEE
We’ll do what it takes to keep your SureFire gear running smoothly. SureFire
warrants that if you — our customer — purchase one of our products, and we
determine that it is defective in material and/or workmanship during your lifetime,
we will repair or replace it — no hassle!
Our warranty does not cover consumables or normal wear-and-tear — things like
batteries draining, headbands and headpads wearing out, ink cartridges running
out, and switches wearing out — or damage resulting from abuse, alterations,
unauthorized repairs, or use contrary to SureFire’s user manuals.
Should you need a replacement product, SureFire reserves the right to replace an
obsolete product with a current production, like model. In the event that any issue
with a SureFire product is not covered under this warranty SureFire can arrange to
have the product repaired for a reasonable fee.
STANDARD DISCLAIMER
Except as specified above or prohibited by applicable law: all express or implied
conditions and warranties, including, without limitation, any implied warranty
or condition of merchantability or fitness for a particular purpose, or accuracy of
any informational content, are hereby excluded and disclaimed by SureFire; and
in no event will SureFire be liable for any special, direct, indirect, consequential,
incidental or punitive damages howsoever arising and regardless of the theory
of liability, even if advised of the possibility of such damages. Products, prices,
availability, specifications, and offers are subject to change or cancellation at any
time without notice.
WARRANTY CLAIMS
For claims, contact Customer Service at 714-545-9444 to obtain a Return
Merchandise Authorization number (RMA#). Then package the unit carefully and
send to (no CODs):
SureFire, LLC.
Repairs Department, RMA#____
17680 Newhope Street, Suite B
Fountain Valley, CA 92708
SureFire will pay any reasonable shipping costs to return the unit to you.
P1RZ-IB-DF P1RZ-B-DFT
OUTPUT SF18650B: 15-1,500
123A: 15-1,100 lumens
SF18650B: 1,500
123A: 1,100 lumens
RUNTIME Up to 40 hours* SF18650B: 1.5
123A: 1.25 hours
PEAK BEAM INTENSITY SF18650B: 25,200
123A: 16,700 candela
BEAM DISTANCE SF18650B: 315
123A: 255 meters
CONSTRUCTION Aluminum
FINISH Hard Anodized (MIL-A-8625 Type III, Class 2)
WEIGHT (w/batteries) 6.5 oz (184 g)
LENGTH 5.6 in (14.2cm)
BEZEL DIAMETER 1.39 in (3.5cm)
BATTERIES One SF18650B lithium-ion rechargeable (incl)
or Two 123A lithium (not incl)
SWITCHING Click tailcap
All performance claims tested to ANSI/NEMA FL1-2019 Standard.
*SF18650B battery required
P1RZ SERiES
LOCKOUT TAILCAP (US PAT. RE40125)
To enable, rotate tailcap clockwise until tight.
To lock out tailcap, rotate counterclockwise until light will not
activate when pushbutton is pressed.
LIGHT OPERATION
P1RZ-B-DFT: Press or click tailcap switch to activate.
P1RZ-IB-DF: Press or click tailcap switch for Intellibeam mode,
return to off and press or click within two seconds for high-output only.
LIGHT OPERATION
P1RZ-IB-DF: Press or click for Intellibeam mode, return to off and press
or click within two seconds for high-output only.
NOTE: In order for the Intellibeam sensor to work properly, keep then lens clean of finger
prints and other debris
BATTERY REPLACEMENT
1. Unscrew tailcap counterclockwise and remove.
2. Remove old batteries and dispose of properly.
3. Insert two new 123A lithium batteries or one 18650 battery with the
positive (+) terminal(s) oriented forward.
4. Replace tailcap by screwing on clockwise. Press pushbutton
(with tailcap enabled) to test.
BATTERY INFORMATION & WARNINGS
For complete battery information and warnings, reference the enclosed
BATTERY INFORMATION / WARNING insert in your illumination tool’s
original packaging or visit www.surefire.com/batteries.
SAFETY
The internal protection circuit integrated within the battery
assembly provides protection against over-charge, over-discharge, short
circuit, under-voltage, over-voltage.
GET THE BEST FROM THE BEST
The SF18650B is a Lithium Ion protected 18650 battery with micro USB
charge capability. This allows the user to conveniently charge the battery
using any USB power source such as a USB wall charger, computer/laptop,
power bank, or automotive USB port. Additionally, an external 18650
compatible CC-CV cradle charger can be used to charge the battery; possibly
at a faster rate if so equipped.
OPERATION
The SF18650B can be used as a standard protected 18650 in many applica-
tions with one advantage; the battery can be charged directly through the
micro USB port, requiring no external charge cradle. The SF18650B comes
with a 6 inch USB type A plug to micro USB type B plug, with the micro USB
plug being the end inserted into the battery. The battery side includes a
micro USB type B receptacle. Once the cable is plugged into the battery and
a power source, the 2 LED indicators display the current charge state: RED
for charging and GREEN for fully charged. The battery can be left connected
to the charge source indefinitely as the internal charge algorithm will restart
the charge cycle once the cell voltage drops below 4-5% of the float voltage.
The typical charge time for charging via the micro USB port for fully depleted
battery can be over 5 hours. The user has an option of charging the battery
with an external charger to shorten the total charge time.
The quiescent drain on the battery from the protection circuit is 40uA, which
in addition to the cell self-discharge, allows a fully charged battery to be
stored for 2-3 years and still maintain usable capacity
ENVIRONMENTAL
Charging: 0°C-45°C, 65%±25%RH
Discharging: -20°C-+60°C, 65%±25%RH
Storage Temperature Range: 0-35°C. 60±25% RH
Note: The battery’s metal button top also functions as a heatsink during
USB charging, which may result in it being very warm to the touch during
the high charge rate period.
SF18650B
VOLTAGE 3.6 V
CAPACITY 3.5 Ahr
CHARGE END VOLTAGE 4.20 V
DISCHARGE END VOLTAGE 2.50 V
STANDARD CHARGE RATE 0.5C at 2.5-3 hours
RAPID CHARGE RATE 1.0C at 1.5-2 hours
DISCHARGE RATE 8-10 A
USB CHARGE VOLTAGE 5.0 V ± 0.2 V
USB CHARGE CURRENT 600 mA ± 100 mA
SPECIFICATIONS
ENABLE
DISABLE
P1RZ SERiES
