Side 1/2
Bayco Products, Inc. • 640 South Sanden Blvd. • Wylie, TX 75098 • USA • 1-800-233-2155 • 1-469-326-9400 • www.nightstick.com
INS-XPP-5465-LG-21 11-11-2021
the desired brightness level is reached, release the ashlight switch, and the light will remain
in that mode. Press and hold from any mode to start the cycle again. Press and release to
turn the light off.
Rear Green Safety LED
The rear green safety LED will remain lit while  ashlight is on in any mode.
WARRANTY
LIMITED LIFETIME WARRANTY
Bayco Products, Inc. warrants this product to be free from defects in workmanship and
materials for the original purchaser’s lifetime. The Limited Lifetime Warranty includes the LEDs,
housing and lenses. Rechargeable batteries, chargers, switches, electronics and included
accessories are warranted for a period of two years with proof of purchase. Normal wear
and failures which are caused by accidents, misuse, abuse, faulty installation and lightning
damage are excluded.
We will repair or replace this product should we determine it to be defective. This is the
only warranty, expressed or implied, including any warranty of merchantability or  tness for
a particular purpose.
For a complete copy of the warranty, go to www.baycoproducts.com/nightstick-product-
support/warranties. Retain your receipt for proof of purchase.
Mode d’emploi
Forge™ XPP-5465
LE XPP-5465 EST APPROUVÉE POUR UTILISATION
AVERTISSEMENTS: SÉCURITÉ INTRINSÈQUE
y Avertissement : Utiliser seulement les piles non rechargeables approuvées et énumérées
ci-dessous.
y Avertissement : Pour éviter l’in ammation d’atmosphère dangereuse, ne pas ouvrir
le compartiment de pile dans un endroit dangereux. Cette tâche doit être effectuée
UNIQUEMENT dans une zone non dangereuse.
y Avertissement : Lorsque vous remplacer les piles, utiliser uniquement les PILES
ENERGIZER CR123
y Avertissement : Pour éviter l’in ammation d’atmosphère dangereuse, les piles doivent
être remplacées dans une zone non dangereuse.
y Avertissement : Pour réduire les risques d’explosion, ne pas mélanger les piles neuves
non rechargeables avec des piles non rechargeables utilisées, ou mélanger les piles non
rechargeables de différents fabricants.
y Avertissement : la substitution de composants peut compromettre la sécurité intrinsèque.
Instruction Manual
FORGE™ XPP-5465
US PATENT 9,713,217 AND 11,019,868
THE XPP-5465 IS APPROVED FOR USE
CLASS I DIV 2 GRPS A-D T3
CLASS II DIV 2 GRPS F-G T135°C
CLASS I ZONE 2 Group IIC T3
-20ºC ≤ Tamb ≤ +40ºC
(2) CR-123 3.0V/Cell
INTRINSICALLY SAFE
SECURITE INTRINSEQUE
Bayco Products, Inc. XPP-5465
ID 5012927
640 S. Sanden Blvd., Wylie, TX 75098
WARNING: Risk of ignition - Do not open in a hazardous area.
AVERTISSEMENT: Ne pas ouvrir dans une zone dangereuse.
WARNING: Risk of ignition - Do not change batteries in a hazardous area.
AVERTISSEMENT: Danger d’inflammation - Ne changez pas les piles dans une zone dangereuse.
Conforms to:
UL Standard 783
Certified to:
CAN/CSA STD C22.2 No 157
WARNINGS - INTRINSICALLY SAFE
y Warning: Use only the approved non-rechargeable batteries listed below.
y Warning: Do NOT attempt to use rechargeable batteries with this light.
y Warning: To prevent ignition of a hazardous atmosphere, do not open the battery
compartment in the hazardous environment. This task must ONLY be performed in an
area known to be non-hazardous.
y Warning: When exchanging batteries, use only ENERGIZER CR123 lithium batteries.
y Warning: To reduce the risk of explosion, do not mix new non-rechargeable batteries
with used non-rechargeable batteries, or mix non-rechargeable batteries from different
manufacturers.
y Warning: Substitution of components may impair intrinsic safety.
SPECIAL INSTRUCTIONS FOR INTRINSIC SAFETY
For personal safety, always con rm the rating of any known hazardous or potentially
hazardous location where the light is to be used.
INSTALLING BATTERIES
y Loosen the screw on the battery compartment door. (Image 1)
y Insert batteries using the orientation markings on the back of the battery compartment
door. (Image 2)
y Close the battery door fully, then tightening the screw until it is hand tight. CAUTION: Do
not cross-thread or strip the screw threads.
y Test the operation of the light (see OPERATION below).
INSTALLING ON TO A HELMET
y Choose the side of the helmet you wish to mount the light on.
y Rotate the mount to orient the clamp with thumbscrew on top.
y Open the clamp completely and fully seat over helmet brim, ensuring the clamp clears
any rubber helmet trim. (Image 3)
y Tighten the clamp  rmly with included Allen wrench. (Image 4)
SETTING THE ANGLE OF THE LIGHT
y Twist the light left or right on the vertical pivot until beam pattern is in an ideal position.
y The tension on the mount is meant to be  rm to maintain the aim.
y Once aimed, the mount allows the user to position light above or below the brim by
rotating up or down as needed.
OPERATION
The 5465 has a  ashlight push button tail switch with the following lighting modes:
CONSTANT-ON FLASHLIGHT
Press the ashlight switch until it clicks and then release for constant-on in high-
brightness mode. Press and release to turn the light off.
SELECT FLASHLIGHT BRIGHTNESS LEVEL
Press and hold down the  ashlight switch. The  ashlight will cycle from high to medium
to low and then back up again at a rate of approximately one mode per second. The light
will continue to cycle through the modes as long as the ashlight switch is held down. When
Image 1
Image 2
Image 3
Image 4
SCAN FOR MOUNTING
INSTRUCTION VIDEO
https://youtu.be/Ta0i7U-92hM
