Side 1/2

Tips

For initial registration of the ONT, you can configure the quick registration function according to the page

prompts. In INTERNET Settings module, you can set the parameters to set up a WAN connection

according to your ISP and your own needs, and click . If not, refer to the following to set up Apply Changes

a WAN connection.

➊ Choose > .WAN PON WAN

➋ Tick .Enable VLAN

➌ Enter the VLAN ID provided by your ISP.

➍ Set Channel Mode to .PPPoE

➎ Set Connection Type to INTERNET.

➏ Enter the PPPoE UserName and Password provided by your ISP.

➐ Set other parameters according to your ISP and your own needs.

➑ Click .Apply Changes

➒ Click when OK Change setting successfully is shown on the page.

Step 2: Set up a WAN connection

UserName:

Password:

PON WAN

Apply Changes Delete

This page is used to configure the parameters for PONWAN

Enable VLAN:

VLAN ID:

Channel Mode:

Connection Type:

ppp0_nas0_0

test

PPPoE

INTERNET

LED indicator Color Status Description

Solid on

PWR

INET

PON

LOS

LAN

WPS

TEL

Green

USB Green

Red

The ONT is powered on.

The internet access is available through the ONT.

Data is being transmitted through the ONT.

No internet access is available through the ONT.

Solid on The ONT is registered successfully.

Blinking

Solid on

Off

Green

WLAN/

2.4G/5G Green

The received optical power is at a proper value.

Off

The ONT is registering.

Off The ONT is powered off.

The received optical power is lower than the optical receiver sensitivity.

The LAN port is connected. No data is being transmitted.

The ONT is unregistered.

The LAN port is transmitting data.

The LAN port is disconnected.

Blinking

Solid on

Off

The ONT is registered with IMS. No data is being transmitted.

The ONT is registered with IMS and is transmitting data.

The ONT is not registered with IMS.

Blinking

Solid on

Off

The USB port is connected. No data is being transmitted.

The USB port is transmitting data.

The USB port is disconnected.

Blinking

Solid on for

2 minutes

Off

A WPS connection is established.

The WPS negotiation is ongoing.

The WPS function is not activated.

Blinking

Solid on

Off

The Wi-Fi network is enabled.

Data is being transmitted wirelessly.

For the device without the LED indicator: If the WPS function is WPS

activated on the device, the WLAN/2.4G/5G LED indicator blinking

means that the device is performing WPS negotiation.

The Wi-Fi network is disabled.

Port/Button Description

ON/OFF

PON

WLAN

WPS/RST

LED

Press the button to turn on or turn off the ONT.

Optical fiber port. Used to connect to optical network through a fiber cord.

PWR Used to connect the ONT to a power source using the included power adapter.

USB USB 2.0 port. Used to connect to a USB storage for resource sharing.

Wi-Fi on/off button. Press the button to enable or disable the Wi-Fi function of the ONT.

TEL

LAN1-4

Telephone port. Used to connect to a telephone for voice service using a telephone cable.

Gigabit LAN ports. Used to connect to such devices as routers, switches, computers or IPTV

set-top boxes.

LED indicator on/off button. Press the button to turn on or off the LED indicators of the ONT.

WPS/Reset button.

• : WPS-supported devices can connect to the Wi-Fi networks of the ONT without entering WPS

the password through WPS negotiation.

Press the button for about 1-3 seconds to start the WPS negotiation process of the ONT. The

WPS (marked ) LED indicator blinks quickly. Within 2 minutes, enable the WLAN/2.4G/5G/WPS

WPS function to establish a WPS connection on a WPS-supported device.

• : Restore the ONT to the configurations preset by the ISP or restore the ONT to factory Reset

settings.

- To restore the ONT to the configurations preset by the ISP: After the ONT completes

startup, press the button for 10 to 60 seconds and release it. All LED indicators will light

off in a few seconds. When the LED indicator lights solid on again, the ONT is PWR

restored to the configurations preset by the ISP.

- To restore the ONT to factory settings: After the ONT completes startup, press the button

for more than 1 minute and release it. All LED indicators will light off in a few seconds.

When the LED indicator lights solid on again, the ONT is restored to the factory PWR

settings.

Tips

This ONT supports wall mounting (two mounting holes on the bottom). The recommended parts are as follows:

- Expansion bolt: Thread diameter: 6.0 mm; Length: 26.4 mm; Inner diameter: 2.4

- Screw: Quantity: 2; Diameter: 3.0-4.0 mm; Head diameter: 5.0-6.5 mm.

Tips

• HG15 is used for illustration here unless otherwise specified. The actual product prevails

• Press button (if any) to turn on the ONT.ON/OFF

• If ISP provides any parameters for registration, you can use them to manually register the ONT with the quick

registration function. The quick registration function is available only when the ONT is registered for the first time.

Method:

Refer to Step 1 Router mode 2. Configure the internet access in the of the .

➊ Log in to the web UI of the ONT.

➋ In (or ) module, register with the parameters provided by your ISP and click GPON Settings EPON Settings

Apply Changes.

➋

Get to know the ONT

1. Connect and register the ONT

Caution, laser

DO NOT look directly at the port when the device is powered on, as well as the terminal of the indoor fiber PON

cord, to prevent any harm to your eyes.

Connect the ONT as shown in the figure. Wait until the LED indicator lights solid on, then the ONT is PON

registered successfully.

(Example: HG15)

Tips

HG15 is used for illustration here unless otherwise specified. The actual product prevails.

(Example: HG15)

Power adapter

Rear panel

PON TEL LAN2 LAN1PWR

WPS / RST

Bottom panel

Fiber cord

PON port

Tips

If the above page does not appear, refer to in . Q1 FAQ

Tips

- PPPoE is used for illustration here. Change the parameters as required by your ISP.

- Choose a desired mode to configure your internet access:

Router mode: Configure the internet on the ONT.

Bridge mode: Dial-up on the router or terminal connected to the ONT.

Tips

You can log in to the web UI of the ONT with user permissions or administrator permissions. Administrator

permissions are for the installation and maintenance personnel only.

• : Able to view and modify partial configurations of the ONT. The default login user User Permissions

name is . You can get the password from the bottom label on the ONT.admin

• Administrator Permissions: Able to view and modify all configurations of the ONT. Some

configurations changed by the installation and maintenance personnel will affect the normal operation

of the ONT. Therefore, use the administrator permissions with caution. The default login user name and

password are both admin (or root).

2. Configure the internet access

➊ Connect to the ONT.

• Wired device: Connect a LAN port of the ONT to a wired device, such as a computer, using an Ethernet

cable.

• Wireless device: Connect your wireless device, such as a smartphone, to the Wi-Fi network of the ONT

using the (Wi-Fi name) and (Wi-Fi password) on the bottom label.SSID Key

➋ Start a web browser and visit .192.168.1.1

➌ Enter the and User Name Password according to the actual permissions.

➍ Click .Login

Step 1: Log in to the web UI

Router mode

192.168.1.1

User Name:

Password:

ResetLogin

Ports/Buttons

Quick Installation Guide

HG Series xPON ONT

Package contents

• xPON ONT x 1

• Power adapter x 1

• Ethernet cable x 1

• Telephone cable x 1 (if any)

• Optical fiber cable x 1 (if any)

• Quick installation guide x 1

LED indicators

The LED indicators may vary with models. The actual product prevails. The ports and buttons may vary with models. The actual product prevails.

➊

Tips

When the ONT is set to bridge mode, configure internet settings based on ISP requirements.

➊ Connect a LAN port of the ONT to the WAN port of the router using an Ethernet cable.

➋ Connect your computer to a LAN port of the router using an Ethernet cable.

➌ Set up a PPPoE connection on the router as required.

After the settings, you can access the internet through the router.

Done.

To access the internet:

• Connect your wired device, such as a computer, to a LAN port of the ONT.

• Connect your wireless device, such as a smartphone, to the Wi-Fi networks of the ONT, using the SSID

(Wi-Fi name) and (Wi-Fi password) on the bottom label. Key

Access internet over PPPoE

Bridge mode

PON TEL LAN2PWR LAN1

WPS / RST

WPSReset WAN 1 2 IPTV/3 POWER

Power source

Computer

LAN LAN

ONT Router

Optical fiber

Ethernet cable

FAQ

• Ensure that the ONT is powered on properly (the LED indicator is solid green).PWR

• If you use a wireless device, such as a smartphone, to configure the ONT:

- Ensure that your smartphone has disabled mobile data and is connected to the Wi-Fi network of the

ONT.

- Clear the cache of the web browser or change a web browser and try again.

- Use another smartphone and try again.

• If you use a wired device, such as a computer, to configure the ONT:

- Ensure that your computer is connected to the ONT properly (the LED indicator of the connected LAN

port lights up).

- Ensure that your computer is set to and Obtain an IP address automatically Obtain DNS server

address automatically.

- Use another computer and try again.

• Refer to to reset the ONT and try again.Q3

Q1: I cannot log in to the web UI by visiting 192.168.1.1. What should I do?

A1: Try the following solutions:

• Check the LED indicator status of ONT:

- If the LED indicator is off, ensure that the ONT is powered on properly.PWR

- If the LED indicator blinks, ensure that the port is clean and connected properly, the LOS PON

fiber cord is not bent excessively and the input optical power is within the normal range (Rx Power

between -28 dBm to -8 dBm in GPON mode (or -27 dBm to -3 dBm in EPON mode) on the Status

> PON page).

- If the LED indicator blinks, the ONT is not registered. Contact your ISP or verify the parameters PON

for registration are correct.

• Ensure that your ISP supports self-purchased PON device for internet access.

• If you set the ONT to the router mode:

-Ensure that the ONT obtains a valid IP address and gateway on the Status > Device > WAN

Configuration page. If not, the WAN connection is not set up successfully. Verify the parameters are

correct.

-Ensure that the wired device is connected to a LAN port of the ONT or downstream router (if any)

properly and set to Obtain an IP address automatically Obtain DNS server address and

automatically.

- Ensure that the wireless device is connected to the Wi-Fi network of the ONT or downstream router

(if any).

• If you set the ONT to bridge mode, ensure that the router or terminal used for dial-up is connected

and configured properly.

If the problem persists, consult your ISP.

Q2: I cannot access the internet after the configuration. What should I do?

A2: Try the following solutions:

Get support and services

For technical specifications, user guides and more information, please visit the product page or service

page on www.tendacn.com. Multiple languages are available.

You can see the product name and model on the product label.

https://www.tendacn.com/service/default.html

Safety Precautions

Before operating, read the operation instructions and precautions to be taken, and follow them to

prevent accidents. The warning and danger items in other documents do not cover all the safety

precautions that must be followed. They are only supplementary information, and the installation and

maintenance personnel need to understand the basic safety precautions to be taken.

- The device is for indoor usage only.

-For wall mounting, the device is only suitable for mounting at heights ≤ 2m.

- For desktop mounting, the device must be horizontally mounted for safe use.

- Do not use the device in a place where wireless devices are not allowed.

- Please use the included power adapter.

- If the device does not have the power button, the mains plug is used as the disconnect device and

shall remain readily operable. The power socket shall be installed near the device and easily

accessible.

- Operating environment: Temperature: 0℃ ℃ to 45 ; Humidity: (10% - 90%) RH, non-condensing;

Storage environment: Temperature: -40 ; Humidity: (5% - 90%) RH, non-condensing.℃ to +70℃

- Keep the device away from water, fire, high electric field, high magnetic field, and inflammable and

explosive items.

- Unplug this device and disconnect all cables during lightning storms or when the device is unused

for long periods.

- Do not use the power adapter if its plug or cord is damaged.

- If such phenomena as smoke, abnormal sound or smell appear when you use the device,

immediately stop using it and disconnect its power supply, unplug all connected cables, and contact

the after-sales service personnel.

- Disassembling or modifying the device or its accessories without authorization voids the warranty,

and might cause safety hazards.

For the latest safety precautions, see Safety and Regulatory Information on www.tendacn.com.

This is a Class B product. In a domestic environment, this product may cause radio interference, in

which case the user may be required to take adequate measures.

This equipment should be installed and operated with minimum distance 20cm between the device

and your body.

NOTE: (1) The manufacturer is not responsible for any radio or TV interference caused by

unauthorized modifications to this equipment. (2) To avoid unnecessary radiation interference, it is

recommended to use a shielded RJ45 cable.

CE Mark Warning

Hereby, SHENZHEN TENDA TECHNOLOGY CO., LTD. declares that the device is in compliance with

Directive 2014/53/EU.

The full text of the EU declaration of conformity is available at the following internet address:

https://www.tendacn.com/download/list-9.html

This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE).

This means that this product must be handled pursuant to European directive 2012/19/EU in order to be

recycled or dismantled to minimize its impact on the environment.

User has the choice to give his product to a competent recycling organization or to the retailer when he

buys a new electrical or electronic equipment.

Attention: In EU member states, EFTA countries, Northern Ireland and Great Britain, the operation in

the frequency range 5150MHz - 5250MHz is only permitted indoors.

Declaration of Conformity

Shenzhen Tenda Technology Co., Ltd.

Floor 6-8, Tower E3, No.1001, Zhongshanyuan Road, Nanshan District, Shenzhen, China. 518052

Website: www.tendacn.com

E-mail: support@tenda.com.cn

Technical Support

Tenda is a registered trademark legally held by Shenzhen Tenda Technology Co., Ltd. Other brand and

product names mentioned herein are trademarks or registered trademarks of their respective holders.

Specifications are subject to change without notice.

V1.0 Keep for future reference.

Operating Frequency/

Max Output Power

2412MHz-2472MHz/20dBm

5150MHz-5250MHz (indoor use only)/23dBm

Tips

• If you cannot access the internet after the configuration, refer to in . Q2 FAQ

• If you want to change the Wi-Fi name and Wi-Fi password, refer to in . Q4 FAQ

RECYCLING

• To restore the ONT to the configurations preset by the ISP: After the ONT completes startup, press

the button for 10 to 60 seconds and release it. All LED indicators will light off in a few WPS/RST

seconds. When the LED indicator lights solid on again, the ONT is restored to the PWR

configurations preset by the ISP.

• To restore the ONT to factory settings: After the ONT completes startup, press the WPS/RST

button for more than 1 minute and release it. All LED indicators will light off in a few seconds. When

the PWR LED indicator lights solid on again, the ONT is restored to the factory settings.

Method 2: Log in to the web UI of the ONT, navigate to Admin > Backup/Restore Reset and click

on the page. You can restore the ONT to the configurations preset by the ISP.

Q3: How to reset the ONT?

A3: Method 1:

Method 2: Log in to the web UI of the ONT, choose and repeat the following steps in WLAN wlan0

(5GHz) wlan1 (2.4GHz) and .

• Wi-Fi name: Choose and change the (Wi-Fi name). Click Basic Settings SSID Apply Changes,

and click when is shown.OK Change setting successfully

• Wi-Fi password: Choose , set Security Encryption to WPA/WPA2-PSK (recommended) and

change the Pre-Shared Key (Wi-Fi password). Click , and click when Apply Changes OK Change

setting successfully is shown.

Method 1: Log in to the web UI of the ONT, change the (Wi-Fi name) and the SSID Pre-Shared Key

(Wi-Fi password) in module with the quick registration function (initial WIFI Settings

registration of the ONT supported), and click Apply Changes.

Q4: How to change the Wi-Fi name and Wi-Fi password?

A4:

UK(NI)

AT BE BG CH CZ DE DK EE EL ES FI FR HR HUCY

IS IT LI MT NL NO PL PT RO SE SI SKLT LU LV

WAN

Tips

HG15 is used for illustration here unless otherwise specified. The actual product prevails.

(Exemplo: HG15)

Produkt Specifikationer

Mærke:	Tenda
Kategori:	Adgangspunkt
Model:	HG10

Har du brug for hjælp?

Hvis du har brug for hjælp til Tenda HG10 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Adgangspunkt Tenda Manualer

Tenda HG10C Manual

31 August 2024

Tenda HG10 Manual

31 August 2024

Tenda W12 V2.0 Manual

16 August 2024

6 August 2024

8 Februar 2024

2 December 2023

25 Oktober 2023

9 Oktober 2023

25 Juli 2023

7 Marts 2023

Adgangspunkt Manualer

Nyeste Adgangspunkt Manualer

Cudy AP11000 Manual

3 Juni 2025

Planet WDAP-C5100BE Manual

5 April 2025

Peplink AP One AX Manual

20 Marts 2025

Cisco Aironet 3600i Manual

15 Januar 2025

Cisco Aironet 3600e Manual

13 Januar 2025

Luxul P40 Manual

13 Januar 2025

Luxul XAP-1440 Manual

13 Januar 2025

Ubiquiti Networks UniFi AP Flex HD Manual

12 Januar 2025

TP-Link Omada EAP115-Wall Manual

30 December 2025

D-Link DBT-900AP Manual

26 December 2024
