TOA N-8010EX Manual

TOA Samtaleanlæg N-8010EX

Læs gratis den danske manual til TOA N-8010EX (20 sider) i kategorien Samtaleanlæg. Denne vejledning er vurderet som hjælpsom af 2 personer og har en gennemsnitlig bedømmelse på 4.4 stjerner ud af 1.5 anmeldelser. Har du et spørgsmål om TOA N-8010EX, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/20

INSTALLATION MANUAL

IP INTERCOM EXCHANGES N-8000EX

N-8010EX

Thank you for purchasing TOA's IP Intercom Exchanges.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

TABLE OF CONTENTS

1. SAFETY PRECAUTIONS

............................................................................. 3

2. GENERAL DESCRIPTION .......................................................................... 6

3. FEATURES ............................................................................................................ 7

4. SPECIFICATIONS ............................................................................................. 8

5. SYSTEM CONFIGURATION EXAMPLE ............................................. 8

6. NOMENCLATURE AND FUNCTIONS ................................................. 9

Front ............................................................................................................................. 9

Rear ............................................................................................................................. 9

7. INSTALLATION ................................................................................................. 10

7.1. Rack Mounting ..................................................................................................... 10

7.1.1. Settin g space ............................................................................................. 10

7.1.2. Caution when installing the unit ................................................................. 11

7.1.3. Mounting on the rack ................................................................................. 11

7.2. Desk-Top Installation ........................................................................................... 12

7.3. Wall Mounting ...................................................................................................... 12

8. WIRING .................................................................................................................. 14

8.1. Connection Diagram ............................................................................................ 14

8.2. Type of Cable ...................................................................................................... 16

8.3. Relations Between Core Diameter of Cable and Maximum Cable Length ......... 16

8.4. Connector Connection ........................................................................................ 17

8.4.1. Mini-clamp connector connection ............................................................ 17

8.4.2. Removable terminal plug connection ...................................................... 18

8.5. E-7000TB Terminal Board Wiring ....................................................................... 19

9. ACCESSORIES ................................................................................................ 20

9.1. N-8000EX ............................................................................................................ 20

9.2. N-8010EX ........................................................................................................... 20

Produkt Specifikationer

Mærke:	TOA
Kategori:	Samtaleanlæg
Model:	N-8010EX
Bredde:	420 mm
Dybde:	356 mm
Højde:	44.3 mm
Vægt:	4200 g
Antal pr. pakke:	1 stk
Produktfarve:	Sort
Wi-Fi:	Ingen
Indbyggede højttaler(e):	Ingen
Driftstemperatur (T-T):	0 - 40 °C
Ethernet LAN-datahastigheder:	10, 100 Mbit/s
Kabler inkluderet:	Vekselstrøm
Materiale:	Stål
Bæredygtighedscertifikater:	CE
Indbygget mikrofon:	Ingen
Oprindelsesland:	Taiwan
Strøm over Ethernet (PoE):	Ingen
Overholdelse af bæredygtighed:	Ja
Kapabilitet:	N-8050DS, N-8031MS, N-8000MS, N-8010MS, N-8011MS, N-8033MS, N-8065MS Q-TEE, N-8020MS, N-8050SB, N-8050SB
Monteringssæt:	Ja
Mærke kompatibilitet:	TOA
Antal RJ-45-porte:	1
