INSTALLATION MANUAL

IP REMOTE MICROPHONE STATION

Thank you for purchasing TOA's IP Remote Microphone Station.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

TABLE OF CONTENTS

1. SAFETY PRECAUTIONS ............................. 1

2. GENERAL DESCRIPTION ........................... 1

3. FEATURES ................................................... 1

4. INSTALLATION ............................................ 2

4.1. Desk-Top Installation ............................... 2

4.2. Wall Hanging .......................................... 3

4.3. Creating Remote Microphone

Name Labels .......................................... 5

5. ACCESSORIES AND OPTIONAL

PRODUCTS .................................................. 8

5.1. Accessories ............................................ 8

5.2. Optional Products ................................... 8

1. SAFETY PRECAUTIONS

• Beforeinstallationoruse,besuretocarefullyreadalltheinstructions in thissection forcorrectandsafe

operation.

• Besuretofollowalltheprecautionaryinstructionsinthissection,whichcontainimportantwarningsand/or

cautions regarding safety.

• Afterreading,keepthismanualhandyforfuturereference.

• UsethespeciedACadapterfortheunit.Notethattheuseofotheradaptermaycauseare.

2. GENERAL DESCRIPTION

The N-8610RM IP Remote Microphone Station is designed for use with TOA's packet intercom system (IP

network compatible intercom system) that employs the packet audio technology*.

ConnectingtheN-8610RMtoaLANorWANpermitsconversationsbetweenIPstationsandpaging.Usingthe

N-8610RM in combination with the SX-200IP IP Interface Module permits announcements to be made to the

SX-2000 Matrix System.

* Technology related to audio transmission over a network.

3. FEATURES

• Canbeconnectedtoanexistinglocalareanetwork(LAN)orwide-areanetwork(WAN).Thesystemcanalso

beeasilyconnectedtober-opticnetworkswithoutrestrictionsonoperatingdistance.

• ThededicatedN-8000softwareprogramenablescentralizedcontrolwithapersonalcomputer.

• Systemmaintenance (verifying operationlogand line supervision)canalso be performed with a PC and

Internet browser.

• ConnectingthestationtoaPoE(PoweroverEthernet)switchinghubeliminatestheneedforanACadapter.

• ConnectinganoptionalRM-210RemoteMicrophoneExtensionexpandsthenumberoffunctionkeysand

indicatorsin10units.Upto4RM-210scanbeconnectedwhenanACadapterisused,andupto2RM-210s

inthecaseofPoEpowersupply.

• UsinganoptionalWB-RM200Wall-MountingBracket,thestationcanbemountedonawall.

N-8610RM

Indicatesapotentiallyhazardoussituationwhich,ifmishandled,could

resultinmoderateorminorpersonalinjury,and/orpropertydamage.

CAUTION

133-21-00001-00

4. INSTALLATION

4.1. Desk-Top Installation

4.1.1. N-8610RM expansion with the addition of the RM-210

WhenaddinganRM-210RemoteMicrophoneExtensiontoexpandtheN-8610M,usetheRM-210'sExtension

cableandincludedLinkageBrackettolinkthe2units.

Follow the procedures below.

Step 1. Turn over both the N-8610RM and the RM-210, and keep them in close contact with each other.

Step 2. ConnectbetweentheRM-210connectionterminal(EXTENSION)ontheN-8610RMsideandtheRM

connectionterminal(EXTENSION)ontheRM-210sideusingtheextensioncablesuppliedwiththe

RM-210.

In this case, install the ferrite clamp

supplied with the N-8610RM on the

extension cable as shown below.

Step 3. Link both the N-8610RM and the RM-

210togetherusingtheLinkageBracketB

supplied with the RM-210.

Secure the bracket with the 4 supplied

screws indicated by arrows.

Step 4. Fix both units securely using the Linkage

Bracket A (2 pieces) supplied with the

RM-210.

Secure them with the 8 supplied screws

indicated by arrows.

Tip

Follow the same procedures when linking

additional RM-210. But you need not install the

ferrite clamp on the extension cable used to

connect between RM-210s.

Notes

• Because the Linkage BracketA is provided with 2 spare screw holes, use them tolink the 2 units if the

designated screw threaded holes are damaged.

• Ifincorrectorlooseconnectionisfoundbetweenbothunits,loosenallthebracketxingscrewstodisassemble

the units and then link them again with the screws.

RM-210 N-8610RM

Linkage bracket B

RM-210 N-8610RM

Ferrite clamp

(white, supplied with N-8610RM)

Linkage bracket A

Extension cable

(supplied with RM-210)

[Bottom]

Extension cable

(supplied with RM-210)

Ferrite clamp

(white, supplied with N-8610RM)

Produkt Specifikationer

Mærke:	TOA
Kategori:	Samtaleanlæg
Model:	N-8610RM
Bredde:	190 mm
Dybde:	215 mm
Højde:	76.5 mm
Vægt:	700 g
Produktfarve:	Black, White
Produkttype:	Lydterminal
Driftstemperatur (T-T):	0 - 40 °C
Materiale:	ABS
Mærke kompatibilitet:	TOA
