Side 1/26
This Traulsen unit is built to our highest quality standards. We build our refrigerators, freezers and heat-
ed cabinets this way as a matter of pride. This philosophy has made Traulsen the leader in commercial
refrigeration since 1938. We thank you for your choice and condence in Traulsen equipment and we know
you will receive many years of utility from this equipment.
All Traulsen units are placed on a permanent record le with the service department. In the event of any future
questions you may have, please refer to the model and serial number found on the name tag afxed to the unit.
Should you need service, however, call us on our toll free number, 800-825-8220 between 7:30 am and 4:30 pm
CST, Monday-Friday. It is our pleasure to help and assist you in every possible way.
OWNER’S MANUAL
Instructions for the installation, operation
and maintenance of all Traulsen:
R & A Series Reach-In & Roll-In Refrigerators*
R & A Series Pass-Thru & Roll-Thru Refrigerators*
R & A Series Reach-In & Roll-In Freezers*
R & A Series Reach-In Refrigerator/Freezers*
R & A Series Reach-In & Roll-In Hot Food Cabinets*
R & A Series Pass-Thru & Roll-Thru Hot Food Cabinets*
INSTALLER
COMPLETE THE FOLLOWING INFORMATION PRIOR TO UNIT INSTALLATION
INITIAL START DATE: SERIAL NO.
MODEL TYPE:
COMPANY/INDIVIDUAL NAME:
INSTALLER:
FORM NUMBER TR35743 (REV. 09-03-15) P/N 375-60176-00
Quality Refrigeration
* Please Note: This manual is intended for use with the above referenced equipment manufactured
after January 01, 2013. To obtain a copy of the correct Owner’s Manual to support the same
products manufactured prior to this date, please contact Traulsen Service at (800) 825-8220.
TABLE OF CONTENTS
The serial tag is a permanently afxed sticker on which is re-
corded vital electrical and refrigeration data about your Traulsen
product, as well as the model and serial number. This tag is
located in the upper right interior compartment on all reach-in/
pass-thru and roll-in/roll-thru refrigerator, freezer and dual-temp
models. For hot food models, this tag is located on the top of
the unit behind the louvers to protect it from the heat.
I. THE SERIAL TAG
-1-
VII. INTELA-TRAUL
®
a-Control Features Page 8
b-Alarm Explanations Page 9
c-Control Panel Page 10
d-Notes To The User Page 10
e-Enter The Customer Access Code Page 10
f-Customer Service Parameters Page 11
g-Adjusting Thermostat Set Point Page 11
h-Adjusting Thermostat Set Point Low Page 12
i-Changing The Temperature Scale Page 12
j-Setting The 24-Hour Clock Page 13
k-Setting The Date Page 14
l-Setting Daylight Savings Time Page 14
m-Starting A Manual Defrost Page 15
n-Setting Defrost Lockouts Page 16
o-Adjusting The Room Temperature Offset Page 17
p-Setting The Audible Alarm Style Page 17
q-Viewing Sensor Temperatures Page 18
r-Door Open Icon Page 18
s-Hot Food Units - Adjusting The Thermostat Page 18
t-Hot Food Units - Turning The Unit OFF & ON Page 19
u-Hot Food Units - Temperature Adjustment Page 19
VIII. TROUBLE SHOOTING GUIDE Page 20
XI. SPARE PARTS LIST Page 21
XII. STAINLESS STEEL OVERVIEW Page 22
XIII. CARE OF STAINLESS STEEL Page 23
XIV. CORROSION REMEDIES Page 23
XV. WARRANTY INFORMATION Page 24
I. THE SERIAL TAG Page 1
II. RECEIPT INSPECTION Page 2
III. INSTALLATION
a-Location Page 2
b-Packaging Page 2
c-Installing Legs or Casters Page 2
d-Shelf Pins Page 3
e-Roll-In Model Installation Page 3
f-Attaching Double Depth Units Together Page 3
g-Installing The Condensate Evaporator Page 3
h-Remote Installation Page 4
i-Cord & Plug Page 4
j-Power Supply Page 4
k-Wiring Diagram Page 4
l-Clearance Page 4
IV. OPERATION
a-Refrigerators Page 5
b-Freezers Page 5
c-Hot Food Cabinets Page 5
V. CARE & MAINTENANCE
a-Cleaning The Condenser Page 5
b-Hinge Replacement Page 6
c-Replacing The Gaskets Page 6
d-Cleaning The Exterior Page 6
e-Cleaning The Interior Page 6
f-Adjusting The Shelves Page 6
g-Replacing The Light Bulb Page 7
VI. OTHER
a-Service Information Page 7
b-Spare Parts Page 7
c-Warranty Registration Page 7
