Tripp Lite IBAR4ULTRAUSBB Manual

Tripp Lite stikdase IBAR4ULTRAUSBB

Læs gratis den danske manual til Tripp Lite IBAR4ULTRAUSBB (17 sider) i kategorien stikdase. Denne vejledning er vurderet som hjælpsom af 2 personer og har en gennemsnitlig bedømmelse på 4.3 stjerner ud af 1.5 anmeldelser. Har du et spørgsmål om Tripp Lite IBAR4ULTRAUSBB, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/17

Owner’s Manual

isobar

Surge Protectors with

Dedicated USB Charging Ports

Models: IBAR4ULTRAUSBB and IBAR6ULTRAUSBB

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an

ISOBAR6ULTRA surge protector—

a $100 value!

www.tripplite.com/warranty

Español 8 • Français 13

18-07-041-933839.indb 1 7/5/2018 5:10:15 PM

Important Safety Instructions

SAVE THESE INSTRUCTIONS

This manual contains important instructions that should be

followed during the installation, operation and storage of this

product. Failure to heed these warnings may affect the warranty.

• DO NOT connect to an ungrounded outlet.

• DO NOT use with 2-wire extension cords or adapters.

• Install your surge protector indoors, away from excessive moisture, heat and dust.

• Install the surge protector away from heat-emitting appliances such as radiators or

heat registers.

• Do not use with aquariums.

• Do not plug extension cords into the surge protector.

• Never install electrical, telephone, network or coaxial wiring during a lightning

storm.

• Do not drill into any part of the housing or open the housing for any reason. There

are no user-serviceable parts inside.

• Use of this equipment in life support applications where failure of this equipment

can reasonably be expected to cause the failure of the life support equipment or to

signiﬁcantly affect its safety or effectiveness is not recommended.

Installation

Mount Your Surge Protector (Optional Installation): If desired, mount your surge

protector on a wall or other sturdy, vertical surface. However, you must mount the

surge protector prior to connecting your equipment. Place a sheet of paper over the

surge protector’s mounting holes and mark their centers with a push pin. Next, place

this template over the desired area and mark with the push pins. Install screws (user

supplied) into the marks until ¼ in. (0.5 cm) of the screw heads are exposed. Mount

the surge protector over the screw heads and slide into place.

Connect Your Surge Protector to the AC Power Line: Plug the surge protector’s

power cord into a standard, 3-wire grounded 120V AC, 60 Hz. outlet.

Turn Your Surge Protector ON: Press the surge protector’s power switch until it

illuminates, indicating the unit is connected to AC input power.

Check Your Surge Protector’s Diagnostic Indicator Lights: Check the LEDs prior

to connecting your equipment. They will indicate various operating conditions when

the surge protector is plugged into a live 120V AC outlet and the surge protector’s

power switch is on.

“PROTECTION PRESENT” LED:

Indicates the unit is connected to AC input

power and the surge suppression components are intact and providing complete

protection against surges. If this LED does not illuminate, see Troubleshooting

section.

18-07-041-933839.indb 2 7/5/2018 5:10:15 PM

Produkt Specifikationer

Mærke:	Tripp Lite
Kategori:	stikdase
Model:	IBAR4ULTRAUSBB
Tænd-/slukkontakt:	Ja
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	90.4 mm
Dybde:	185.7 mm
Højde:	62.2 mm
Vægt:	1180 g
Produktfarve:	Sort
Pakkevægt:	1340 g
Pakkedybde:	178.1 mm
Pakkebredde:	73.2 mm
Pakkehøjde:	290.3 mm
Materiale:	Metal, Plastic
Certificering:	Tested to UL1449 3rd Edition requirements by ETL, Approved for Canada by ETL, Exceeds IEEE 587 category A&B specifications
LED-indikatorer:	Ja
Kan monteres på væggen:	Ja
Kabellængde:	2.44 m
Antal USB-porte:	2
Bæredygtighedscertifikater:	RoHS
Hovedkassen højde (udvendigt):	314.2 mm
Hovedkassens længde (udvendigt):	552.4 mm
Hovedkassens bruttovægt (udvendigt):	14140 g
Hovedkassens bredde (udvendigt):	309.1 mm
Oprindelsesland:	Kina
Produkter pr. hovedkasse (udvendigt):	10 stk
Antal produkter inkluderet:	1 stk
Hovedkasse (udvendig) GTIN (EAN/UPC):	10037332224993
Maksimal strøm:	1440 W
Strømstik:	NEMA 5–15P
Nominel indgangsspænding:	120 V
AC udgange, antal:	4 AC stikkontakt(er)
AC stikkontakt typer:	NEMA 1–15R
Overspænding energivurdering:	3330 J
EMI/RFI støjfiltrering:	80 dB
Nominel udgangsstrøm:	3.1 A
