Side 1/15
DUMMY STARTER
INCLUDED
STARTER
FOR LED TUBES
TECHNICAL DATA:
Model
Was
Color 3000K 4000K; 6500K 3000K 4000K; 6500K 3000K 4000K; 6500K
Lumens 1085 1120 1750 1920 2150 2400
CRI
PF
BeamAngle
Body Type
Holder
Long Life
On/O Cycles
Dimension
Input Power
G13
25,000 Hours
>15000
1500x28mm
AC:220-240V, 50Hz
VT-1615
15
>80
>0.9
160°
Plas cPlas c
G13
25,000 Hours
>15000
1200x28mm
AC:220-240V, 50Hz
G13
25,000 Hours
>15000
600x28mm
AC:220-240V,50Hz
VT-1612
12
>80
>0.9
160°
7
VT-1607
>80
>0.9
160°
Plas c
5
YEARS
WARRANTY
*
WEEE Number: 80133970
INSTALLATION INSTRUCTION
T8 LED Tubes
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU FOR MORE PRODUCTS RANGE,
INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
EL
LED replacement starter
(Included in the packaging)
LED Tubes not suitable for
emergency operations
LED Tubes are NOT suitable for
dimming
LED Lamps suitable for 50Hz
operation
LED Lamps to be used in dry conditions
or in a luminaire that provides protection
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
22
PAP
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these
instructions carefully before starting the installing and keep this manual handy for future reference. If you
have any another query, please contact our dealer or local vendor from whom you have purchased the
product. They are trained and ready to serve you at the best. The warranty is valid for 5 years from the date
of purchase. The warranty does not apply to damage caused by incorrect installation or abnormal wear and
tear. The company gives no warranty against damage to any surface due to incorrect removal and installation
of the product. The products are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a
day would void the warranty. This product is warranted for manufacturing defects only. The LED tube can be
used in hotels, offices, factories, conference rooms, meeting rooms, commercial complexes, residential
buildings, schools, colleges, universities, hospitals, etc.
WARNINGS!
• Installation should only be done by a certified electrician
• Operation environment temperature: from -20°C to +45°C
• Do not use DC electricity
• Do not modify the fitting to be used with the LED Tube.
• V-TAC LED Tubes are NOT designed to be used in emergency operations.
• For Indoor use only.
• Do NOT use with electronic ballasts. V-TAC LED tubes are not compatible with electronic
ballast circuit. In order to use the electronic ballast fitting you must ensure to remove the
electronic ballast from the fitting and rewire the circuit as per new fitting installation as shown
below. Ensure the installation and wiring is carried out by certified electrician.
• Switch Off the power.
• Installation should only be done by a certified electrician
• Installation should only be done by a
certified electrician.
• Ensure the wiring diagram is followed as
highlighted.
• Insert V-TAC LED Tube.
• Switch On the power to test the light.
• Please refer to the wiring diagram for replacing
fluorescent tube on a single magnetic ballast circuit
with V-TAC LED Tube.
Installation & Replacement of Fluorescent Lamp(Single Magnetic Ballast Ciruit)
New Fitting Installation
Single Side Power Only
Wiring Diagram
Wiring Diagram
PACKING:
• LED Tube (1PC)
• Instruction Manual (1PC)
• Dummy Starer (1PC)
1. off the power Switch 2. Remove the existing
fluorescent lamp
3. Remove the existing
fluorescent starter
4. Insert LED T8 starter 6. Switch ON the power
5. Insert V-TAC LED Tube
LED
Left RightLED TUBE
Inductance Ballast
LED Starter
Left Right
(L)
(N)
V-TAC
INPUT
V-TAC
INPUT
LED TUBE
INSTALLATION INSTRUCTION
EN
INSTALLATION INSTRUCTION
EN
AC:220-240V
50Hz
AC:220-240V
50Hz
