INSTRUCTION MANUAL

LED SOLAR STREET LIGHT WITH SOLAR PANEL

TECHNICAL DATA

MODEL VT-ST63W VT-ST120W VT-ST180W

SKU 95532, 98241

95533, 98240,

98417

95534

SOLAR PANEL

WATTS

6W 8W 12W

LUMENS 800 lm 1000 lm 1200 lm

BEAM ANGLE 120° 120° 120°

LED CHIP TYPE 2835 2835 2835

NUMBER OF LEDs 60 120 180

CRI 70 70 70

LIFE SPAN 20000 Hours 20000 Hours 20000 Hours

ON/OFF CYCLE 50000 Times 50000 Times 50000 Times

MAXIMUM

MOUNTING

HEIGHT

3 Meter 4 Meter 5 Meter

OPERATIONAL

TEMPERATURE

-20°C to +60°C -20°C to +60°C -20°C to +60°C

BATTERY

CAPACITY

5000 mAh 9000mAh 10000mAh

BATTERY TYPE

LiFePO4 LiFePO4 LiFePO4

DC VOLTAGE DC 3.2V DC 3.2V DC 3.2V

CHARGING TIME 4-6 Hours 4-6 Hours 4-6 Hours

WORKING TIME 12-15 Hours 12-15 Hours 12-15 Hours

MATERIAL PC PC PC

DIMENSION 360x187x55mm 470x190x55mm 600x197x55mm

IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU

FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.

V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B

MULTI-LANGUAGE

MANUAL QR CODE

Please scan the QR code

to access the manual in

multiple languages.

INTRODUCTION & WARRANTY

Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully

before starting the installation and keep this manual handy for future reference. If you have any another query, please contact

our dealer or local vendor from whom you have purchased the product. They are trained and ready to serve you at the best.

The warranty is valid for 2 years from the date of purchase. The warranty does not apply to damage caused by incorrect

installation or abnormal wear and tear. The company gives no warranty against damage to any surface due to incorrect

removal and installation of the product. The products are suitable for 10-12 Hours Daily operation. Usage of product for 24

Hours a day would void the warranty. This product is warranted for manufacturing defects only.

This marking indicates that this

product should not be disposed

of with other household wastes.

Caution, risk of electric shock.

Solar Panel & Solar Light

Solar charging

(The battery is in the lamp housing)

Intermal six angle screw ﬁxation

Solar charging

(The battery is in the lamp housing)

Remote Screw FixExpansion Screw

PACKAGE CONTENT

INSTALLATION INSTRUCTIONS

LAMP POST INSTALLATION WALL MOUNT INSTALLATION

• Before installing please remove all the parts to check if all are in good condition or not.

• Install the Arm Stand on a wall or on a Lamp Pole with the Expansion Screws

• Ensure the solar panel faces the sunlight. Adjust the angle using the inner six-angle screw to

maximize sun exposure.

• Aer installation test the light using the remote control.

• The remote control is designed with an operation distance of 8-10m

WARNING

1. Installation must be performed by a qualiﬁed electrician.

2. The light source of this luminaire is not replaceable; when the light source reaches its end of life

the whole luminaire shall be replaced.

Light Source

Human remote

control module

Human remote

control module

Arm Stand

(For Wall/Pole Installation)

Arm Stand

(For Wall/Pole Installation)
