TECHNICAL ASSISTANCE

When trouble is reported, verify there are no broken connections to the unit.

Assistance in troubleshoting is available from the factory. When calling, you

should have a Volt-ohm meter and a lineman's test set available and be calling

from the job site. Call (540) 427-3505 and ask for an Applications Engineer or

call (540) 427-6000 for Clarity 24-hour Automated Support.

Clarity equipment is not field repairable. Clarity maintains service facilities in

Roanoke, VA. Should repairs be necessary, attach a tag to the unit clearly stating

your company name, address, phone number, contact person, and the nature of

the problem. Send the unit to:

Clarity

Repair and Return Dept.

5614 Hollins Road

Roanoke, VA 24019-5056

LIMITED WARRANTY

Clarity warrants its products to be free from defects in materials and workmanship under

conditions of normal use and service for a period of one year from the date of shipment. The

obligation under this warranty shall be limited to the replacement, repair or refund of any such

defective device within the warranty period, provided that:

1. Inspection by Clarity indicates the validity of the claim;

2. The defect is not the result of damage, misuse, or negligence after the original

shipment;

3. The product has not been in any way repaired by others and that factory sealed

units are unopened (A service charge plus parts and labor will be applied to units

defaced or physically damaged);

4. Freight charges for the return of products to Clarity are prepaid;

5. All units "out of warranty" are subject to a service charge. The service charge will

cover minor repairs (Major repairs will be subject to additional charges for parts and

labor).

This warranty is in lieu of and excludes all other warranties expressed or implied, and

in no event shall Clarity be liable for any anticipated profits, consequential damages,

loss of time or other losses incurred by the buyer in connection with the purchase,

operation or use of the product.

This warranty specifically excludes damage incurred in shipment. In the event a product is

received in damaged condition, the carrier should be notified immediately. Claims for such

damage should be filed with the carrier involved in accordance with the F.O.B. point.

INSTALLATION INSTRUCTIONS FOR

MODEL NO. S-515

Issue 1 947453

CLARITY TALKBACK SLIMLINE™ WALL SPEAKER

Clarity Slimline Wall Speaker, S-515, is a 45 ohm talkback speaker designed to

be used with Clarity 'handsfree' talkback control units. The distance you can be

away from the speaker and still have good talkback depends on the ambient noise

level. In a typical office environment, the speaker will cover approximately 600

square feet.

Model S-515-BK Black

Model S-515-W White

US Patent Number D357,682, UK Reg.'d 2041547

WIRING

Make connections as shown in Figure 1.

Figure 1

MOUNTING

The baffle provides two methods of mounting:

1. The baffle can be suspended from a nail or hook by a "hanger" that is

attached to the housing. See Figure 2.

2. The unit can be attached to a wall using two mounting bosses. The

distance between the mounting boss hole centers is 8.5". Remove cover

and secure baffle to wall with screws. This mounting provides better low

frequency response for music and a more secure attachment to the wall.

See Figure 3.

Figure 2

Figure 3

TROUBLESHOOTING CHART

SYMPTOM ACTION

• • No sound in page mode. Check tip and ring for audio at

speaker.

• Check tip and ring for audio at

control unit.

• • Low sound in page mode. Check volume controls at page

control.

• • Poor listening in talkback mode. Check talkback volume control at

page control. Set control where

audio is clearly audible.

WALL

MOUNTING

BOSSES

HANGER

Produkt Specifikationer

Mærke:	Valcom
Kategori:	Højttaler
Model:	Clarity S-515
Tænd-/slukkontakt:	Ingen
Bredde:	254 mm
Dybde:	114.3 mm
Højde:	171.5 mm
Vægt:	1700 g
Produktfarve:	Hvid
Wi-Fi:	Ingen
Bluetooth:	Ingen
Relativ luftfugtighed ved drift (H-H):	0 - 85 %
Udgangseffekt (RMS):	5 W
Equalizer:	Ingen
Ethernet LAN:	Ingen
Driftstemperatur (T-T):	0 - 50 °C
Husmateriale:	Polypropylen (PP)
Dimensioner (BxDxH):	254 x 114.3 x 171.5 mm
Anbefalet brug:	Universel
Frekvensområde:	65 - 17000 Hz
Impedens:	45 ohm (Ω)
Forbindelsesteknologi:	Ledningsført
Højttaler, type:	1-vejs
Lyd-output kanaler:	1.0 kanaler
Højttaler, placering:	Kan monteres på væggen
LED-indikatorer:	Ingen
Fjernbetjent:	Ingen
Antal drivere:	1
Driver diameter:	203 mm
Diskanthøjttaler:	Ingen
Sensitivitet:	94 dB
Bashøjttaler:	Ingen
Forstærker:	Ingen
Højttaler kabinet:	Lukket
Subwoofer driver diameter (britisk):	8 "
Højttalerplacering:	Satellit
USB påkrævet:	Ingen
Aftagelig beskyttelsesdæksel:	Ja
Klemskrue:	Ja
