Side 1/2
1 947595
CAUTION: To reduce the risk of electric shock,
Do not remove cover.
No user serviceable parts inside.
Refer servicing to qualied service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
ISSUE 2
VIP- -415 IC
InformaCast® Compliant
IP PEND NT SPEAKERS E
INTRODUCTION
VIP-415-IC is InformaCast Compliant Valcom an
Pend nt It is available in white, black eSpeaker.
and gray.
SPECIFICATIONS
Access thods Me
•Singlewire / InformaCast Server
•SIP enabled telephone system–
•Valcom M Cast Page Group
•Talkback Versions Do Not Support Call
Switches
Features
•802.3af compliant
•High E iciency Class-D Amplierff
•14’ Ethernet Cable
Dimensions/Weight
•5.80” Dia. x 8.80”H
(14.73cm Dia. x 22.35cm H)
•3.2 lbs. (1.45kg)
Environment
Temperature: 0 to +40° C
Humidity: 0 to 85% non-precipitating
Nominal Power Requirements
Via 802.3af (PoE) Ethernet Switch Class 3
Precautionary Designations
•WARNING-To Reduce The Risk Of Fire Or
Electric Shock. Do Not Expose This
Apparatus To Rain Or Moisture.
•AVERTISSEMENT - An de réduire les
risques d'incendie ou de décharge
électrique, évitez d'exposer le système à la
pluie ou à l'humidité.
•Apparatus shall not be exposed to dripping
or splashing and no objects lled with
liquids, such as vases, shall be placed on
the apparatus.
• L’appareil ne doit pas être exposé à des
égouttements et éclaboussures et aucun
Objet Rempli de liquide, comme vase, ne
doit être placé sur l’appareil.
These products are intended for use with a UL
Listed power source marked “Class 2” or “LPS”
rated 24VDC, or 48VDC (PoE).
PoE and all interconnected ITE are intended for
intra-building.
FCC Information
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated
in a commercial environment. This equipment
generates, uses and can radiate radio
frequency energy and if not installed and
used in accordance with the instruction
manual, may cause harmful interference to
radio communications. Operation of this
equipment in a residential area may cause
harmful interference in which case the user
will be required to correct the interference at
his own expense.
2 947595
Attach chain here.
FIGURE 1
INSTALLATION
Mounting
The Pend nt Speaker is designed VIP-415-IC eto
be uspended from ceiling using the enclosed s a
chain. The chain is no attached to e ing the t th r at
top f the speaker to prevent damage to e o th
speaker's nish during shippin To install e g. th
chain, en the link on he en the chai and op t d of n
loop the link rough the ring located on he op of th t t
the peaker and close link. Make sure the s the
chai is securely fastened o the eiling. n t c
NOTE: An additional feet Length chain is 6 of
available. Order Part Number V-1093-BK
The area covered by a pend nt speaker is e
determined by the suspended height of the
speaker.
The llowing hart shows he eig and fo c t h ht
horizontal pacing (in fe and the estimated s et)
cov (in squar feet).erage e
Network Connection
The VIP-415-IC has approximately 14
foot Ethernet cable pre-wired at the
factory and terminated with an RJ45
connector. Connect the cable to an
Ethernet switch providing Power over
Ethernet (PoE) meeting the 802.3af
specication. If the switch does not
provide power, a mid-span power
injector may be used.
Setup
The VIP-415- will automatically IC
acquire an IP address (using DHCP)
and connect to the InformaCast
server when connected to the
network and powered up.
Information specic to your
application will need to be
programmed into the InformaCast
server. Refer to the InformaCast
documentation for further
Information.
TECHNICAL ASSISTANCE
Assistance in troubleshooting is available from
the factory. Call (540) 563-2000 and press 1 for
Technical Support or via email at
support@valcom.com.
When requesting assistance, you should include
all available information. Information and trouble-
shooting procedures are available on the Valcom
website at www.valcom.com.
Valcom equipment is not eld repairable.
Valcom, Inc. maintains service facilities in
Roanoke, VA. Should repairs be necessary,
attach a tag to the unit clearly stating your
company name, address, phone number, contact
person and the nature of the problem. Send the
unit to:
Valcom, Inc.
Repair & Return Dept.
5614 Hollins Road
Roanoke, Va. 24019-5056
WARRANTY
Warranty information may be found on our
website at www.valcom.com/warranty.
Suspended Height
8
10
12
16
20
Horizontal Spacing
16
20
25
30
35
Approximate Coverage
250
350
500
800
1000
IMPORTANT SAFETY INFORMATION
CONSIGNES DE SÉCURITÉ IMPORTANTES
1. Read these instructions.
Lisez ces instructions.
2. Keep these instructions.
Conservez ces instructions.
3. Heed all warnings.
Respectez tous les avertissements.
4. Follow all instructions.
Suivez toutes les instructions.
5. Do not use this apparatus near water.
Ne pas utiliser cet appareil près de l'eau.
6. Clean only with dry cloth.
Nettoyer avec un chion sec.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
Ne pas bloquer les ouvertures de ventilation. Installer formément aux instructions du
fabricant.
8. Do not install near any heat sources such as radiators, heat registers, stoves or other
apparatus (including ampliers) that produce heat.
Ne pas installer à proximité de sources de chaleur telles que radiateurs, registres de
chaleur, poêles ou autres appareils (y compris les amplicateurs) produisant de la chaleur.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade and the third prong are provided for your safety. If
the provided plug does not t into your outlet consult an electrician for replacement of the
obsolete outlet.
Ne pas contourner le dispositif de sécurité de la che polarisée ou de mise à la terre. Une
che polarisée possède deux lames dont une plus large que l'autre. Une che de terre a
deux lames et une troisième broche de mise à la terre. La lame large et la troisième
broche sont fournies pour votre sécurité. Si la che fournie ne rentre pas dans votre prise,
veuillez consulter un électricien pour le remplacement de la prise obsolète.
10.Protect the power cord from being walked on or pinched particularly at plugs, convenience
ceptacles and the point where they exit from the apparatus.re
11.Only use attachments/accessories specied by the manufacturer.
by the manufacturer or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
N'utilisez que des xations / accessoires spéciés par le fabricant.
12. Use only with the cart, stand, tripod, bracket or table specied
to avoid injury from tip-over.
Utilisez uniquement avec le chariot, stand, trépied, support ou table spécié par le
fabricant ou vendu avec l'appareil. Quand un chariot est utilisé, Soyez prudent lorsque
vous déplacez l'ensemble chariot / appareil pour éviter des blessures dues au
renversement.
13. Unplug this apparatus during lightning storms or when unused for a long period of time.
Débranchez cet appareil pendant les orages ou lorsqu'il n'est pas utilisé pendant une
longue période de temps.
14. Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way. Such as when the power supply cord or plug is
damaged, liquid has been spilled, objects have fallen into the apparatus or the
apparatus has been exposed to rain or moisture and does not operate normally or has
been dropped.
Conez toute réparation à un personnel qualié. Une réparation est nécessaire lorsque
l'appareil a été endommagé de quelque façon. Par exemple lorsque le cordon
d'alimentation ou la che est endommagé, du liquide a été renversé, si des objets sont
tombés dans l'appareil ou le appareil a été exposé à la pluie ou à l'humidité et ne
fonctionne pas normalement ou s'il est tombé.
