Side 1/3
1 947561
Issue 1
VIP-402A-SA
Syn-Apps® Compliant
LAY- ONE-WAY IP CEILING SPEAKER IN
SPECIFICATIONS
Access Methods
S -Apps Server yn
SIP enabled telephone system –
Features
Power over Ethernet (PoE) 802.3af compliant
High E iciency Class-D Amplier ff
Environment
Temperature: 0 to +40° C
Humidity: 0 to 85% non-precipitating
PSE: (Power Sourcing Equipment) to be compliant
IEEE 802.3af
Nominal Power Requirements
Via 802.3af (PoE) Ethernet Switch: Class 3
INSTALLATION
Dimensions/Weight
23.75” L x 23.75” W x 3.75” D
(60.33cm) x (60.33cm) x(9.53cm)
Weight: 5.5 lbs. (2.49kg)
FCC Information
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference when
the equipment is operated in a commercial
environment. This equipment generates uses,
and can radiate radio frequency energy and if
not installed and used in accordance with the
instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a residential area
may cause harmful interference in which case
the user will be required to correct the
interference at his own expense.
2 947561
SPEAKER
-10dB LINE
LEVEL OUT
NETWORK
RESET
Mounting
The VIP-402A- is designed to directly replace a SA
2’ X 2’ ceiling tile.
Network Connection
The VIP-402A- has one RJ-45 network SA
connector on the rear panel. Use a standard patch
cable to connect the VIP-402A- to an Ethernet SA
switch providing Power over Ethernet (PoE)
meeting the 802.3af specication. If the switch
does not provide power, a mid-span power injector
may be used. (See Figure 1)
-10 dB Line Level Out Connection
T -10dB Line Level Out may be connected to up he
to 40 Valcom Self Amplied Speakers to provide
additional sound reinforcement in an area.
IP SPEAKER CONNECTIONS
FIGURE 1
SETUP
The VIP-402A- will automatically acquire an IP SA
address (using DHCP) and connect to the
Syn-Apps server when connected to the network
and powered up. Information specic to your
application will need to be programmed into the
Syn-Apps server. Refer to the Syn-Apps
documentation for further information.
IMPORTANT SAFETY INFORMATION
CONSIGNES DE SÉCURITÉ IMPORTANTES
1. Read these instructions.
Lisez ces instructions.
2. Keep these instructions.
Conservez ces instructions.
3. Heed all warnings.
Respectez tous les avertissements.
4. Follow all instructions.
Suivez toutes les instructions.
5. Do not use this apparatus near water.
Ne pas utiliser cet appareil près de l'eau.
6. Clean only with dry cloth.
Nettoyer avec un chion sec.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
Ne pas bloquer les ouvertures de ventilation. Installer formément aux instructions du
fabricant.
8. Do not install near any heat sources such as radiators, heat registers, stoves or other
apparatus (including ampliers) that produce heat.
Ne pas installer à proximité de sources de chaleur telles que radiateurs, registres de
chaleur, poêles ou autres appareils (y compris les amplicateurs) produisant de la chaleur.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade and the third prong are provided for your safety. If
the provided plug does not t into your outlet consult an electrician for replacement of the
obsolete outlet.
Ne pas contourner le dispositif de sécurité de la che polarisée ou de mise à la terre. Une
che polarisée possède deux lames dont une plus large que l'autre. Une che de terre a
deux lames et une troisième broche de mise à la terre. La lame large et la troisième
broche sont fournies pour votre sécurité. Si la che fournie ne rentre pas dans votre prise,
veuillez consulter un électricien pour le remplacement de la prise obsolète.
10.Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
11.Only use attachments/accessories specied by the manufacturer.
N'utilisez que des xations / accessoires spéciés par le fabricant.
12. Use only with the cart, stand, tripod, bracket or table specied
by the manufacturer or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
Utilisez uniquement avec le chariot, stand, trépied, support ou table spécié par le
fabricant ou vendu avec l'appareil. Quand un chariot est utilisé, Soyez prudent lorsque
vous déplacez l'ensemble chariot / appareil pour éviter des blessures dues au
renversement.
13. Unplug this apparatus during lightning storms or when unused for a long period of time.
Débranchez cet appareil pendant les orages ou lorsqu'il n'est pas utilisé pendant une
longue période de temps.
14. Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way. Such as when the power supply cord or plug is
damaged, liquid has been spilled, objects have fallen into the apparatus or the
aratus has been exposed to rain or moisture and does not operate normally or has app
been dropped.
Conez toute réparation à un personnel qualié. Une réparation est nécessaire lorsque
l'appareil a été endommagé de quelque façon. Par exemple lorsque le cordon
d'alimentation ou la che est endommagé, du liquide a été renversé, si des objets sont
tombés dans l'appareil ou le appareil a été exposé à la pluie ou à l'humidité et ne
fonctionne pas normalement ou s'il est tombé.
