Side 1/3
1 947950
Issue 1
V -410A- IP IC
InformaCast® Compliant
- IP ONE WAY WALL SPEAKER
INTRODUCTION
Speaker enables access to a single paging
location over an The -IP based LAN/WAN.
speaker levels are electrically ad usted dj uring
setup. The enclosure made of steel with a is
durable gray powder coated finish. The color of
the enclosure can easily be changed to match
any decor. A detachable black cloth grille is
included.
Power is provided to the via a -410A-VIP IC
P ower over Ethernet (PoE) switch meeting the
802.3af specification.
SPECIFICATIONS
Features
• Singlewire liantInformaCast comp
• - RJ 45 for network connection
• Power over Ethernet (PoE) 802.3af
compatible
DIMENSIONS/WEIGHT
• 10.13” H x 12.31” W x 4.63” D
(25.73cm x 31.27cm W x 11.75cm D)
• 3 Weight: 4.5 LBS (1.91 kg)
Nominal Power Requirements
Via 802.3af PoE Ethernet Switch: Class 3
PSE (Power Sourcing Equipment) to be
compliant to IEEE 802.3af
Environment
Temperature: 0 to +40° C
Humidity: 0 to 85% non -precipitating
These products are intended for use with a UL
Listed power source marked “Class 2” or “LPS”
rated 24VDC, or 48VDC (PoE).
PoE and all interconnected ITE are intended for
intra- building.
Precautionary Designations
• WARNING-To Reduce The Risk Of Fire Or
Electric Shock. Do Not Expose This
Apparatus To Rain Or Moisture.
• - AVERTISSEMENT Afin de réduire les
risques d'incendie ou de décharge
électrique, évitez d'exposer le système à la
pluie ou à l'humidité.
• Apparatus shall not be exposed to dripping
or splashing and no objects filled with
liquids, such as vases, shall be placed on
the apparatus.
• L’appareil ne doit pas être exposé à des
égouttements et éclaboussures et aucun
Objet Rempli de liquide, comme vase, ne
doit être placé sur l’appareil.
2 947950
CAUTION: To reduce the risk of electric shock,
Do not remove cover.
No user serviceable parts inside.
Refer servicing to qualified serv ice personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature ac companying
this unit.
FCC Information
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated
in a commercial environment. This
equipment generates, uses and can radiate
radio frequency energy and if not installed
and used in accordance with the instruction
manual, may cause harmful interference to
radio communications. Operation of this
equipment in a residential area may cause
harmful interference in which case the user
will be required to correct the interference at
his own expense.
INSTALLATION
MOUNTING
Remove the screw holding the mounting bracket
to the enclosure. Mount the bracket using
appropriate hardware such as # pan head 10
crews. After making the required connections,
reattach the enclosure to the mounting bracket.
(Figure 2)
Network Connection
The VIP 45 network -410A- IC has one RJ-
connector on the rear panel. Use a standard
patch cable to connect the VIP to an -41 -0A IC
Ethernet switch providing Power over Ethernet
(PoE) meeting the 802.3af specification. If the
switch does not provide power, a mid span power -
injector may be used. (See Figure 1)
- 10 dB Line Level Out Connection
The -10dBm Line Level Out may be connected to
up to 40 Valcom Self Amplified Speakers to
provide additional sound reinforcement in an
area.
IMPORTANT SAFETY INFORMATION
CONSIGNES DE SÉCURITÉ IMPORTANTES
1. Read these instructions.
Lisez ces instructions.
2. Keep these instructions.
Conservez ces instructions.
3. Heed all warnings.
Respectez tous les avertissements.
4. Follow all instructions.
Suivez toutes les instructions.
5. Do not use this apparatus near water.
Ne pas utiliser cet appareil près de l'eau.
ry 6. Clean only with d cloth.
Nettoyer avec un chiffon sec.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
Ne pas bloquer les ouvertures de ventilation. Installer formément aux instructions du
fabricant.
8. Do not install near any heat sources such as radiators, heat registers, stoves or other
apparatus (including amplifiers) that produce heat.
Ne pas installer à proximité de sources de chaleur telles que radiateurs, registres de
chaleur, poêles ou autres appareils (y compris les amplificateurs) produisant de la chaleur.
9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug-
has two blades with one wider than the other. A grounding type pl has two blades and aug
third grounding prong. The wide blade and the third prong are provided for your safety. If
the provided plug does not fit into your outlet consult an electrician for replacement of the
obsolete outlet.
Ne pas tourner le dispositif de sécurité de la fiche polarisée ou de mise à la terre. Une con
fiche polarisée possède deux lames dont une plus large que l'autre. Une fiche de terre a
deux lames et une troisième broche de mise à la terre. La lame large et la troisième
broche sont fournies pour votre sécurité. Si la fiche fournie ne rentre pas dans votre prise,
veuillez consulter un électricien pour le remplacement de la prise obsolète.
10.Protect the power cord from being walked on or pinche articularly at plugs, convenienced p
receptacles and the point where they exit from the apparatus.
11.Only use attachments/accessories specified by the manufacturer.
N'utilisez que des fixations / accessoires spécifiés par le fabricant.
12. Use y with the cart, stand, tripod, bracket or table specifiedonl
by the manufacturer or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
Utilisez uni ment avec le chariot, stand, trépied, support ou table spécifié par leque
fabricant ou vendu avec l'appareil. Quand un chariot est utilisé, Soyez prudent lorsque
vous déplacez l'ensemble chariot / appareil pour éviter des blessures dues au
renversement.
13. Unplug this apparatus during lightning storms or when unused for a long period of time.
Débranchez cet appareil pendant les orages ou lorsqu'il n'est pas utilisé pendant une
longue période de temps.
14. Refer all servicing qualified service personnel. Servicing is required when the to
apparatus has been damaged in any way. Such as when the power supply cord or plug is
damaged, liquid has been spilled, objects have fallen into the apparatus or the
apparatus has been exposed to rain or moisture and does not operate normally or has
been dropped.
Confiez toute réparation à un personnel qualifié. Une réparation est nécessaire lorsque
l'appareil a été endommagé de quelque façon. Par exemple sque le cordon lor
d'alimentation ou la fiche est endommagé, du liquide a été renversé, si des objets sont
tombés dans l'appareil ou le appareil a été exposé à la pluie ou à l'humidité et ne
fonctionne pas normalement ou s'il est tombé.
