VIP- 9815A
IP PoE CORRIDOR SPEAKER
INTRODUCTION
enables voice paging over an IP network.
The VIP- consists of a high eciency 9815A
speaker in an unobtrusive, stylish enclosure
allowing standalone capability when used with a
SIP telephone system or can be accessed from
a variety of Valcom managed VoIP products.
SPECIFICATIONS
Access Methods
SIP enabled telephone system –
PBX, FXO Port via Valcom Enhanced
Network Station Port
POTS telephone set via Valcom
Enhanced Network Station Port
PBX, FXS Port via Valcom Enhanced
Network Trunk Port
Valcom Multicast Page Group
Features
-45 network connection RJ
Network activity LEDs
Power over Ethernet (PoE) 802.3af
Compatible
Nominal Power Requirements
Via 802.3af PoE Ethernet Switch: Class 3
PSE: (Power Sourcing Equipment) to be
compliant to IEEE 802.3af
Dimensions & Weight
6.75 "H x 15.75 "W x 6. 75 "D
( .1 cm x .0 cm x 17.1 cm) 17 40
Weight: 5.2 lbs (2.35 kg)
Environment
Temperature: 0 to +40° C
Humidity: -precipitating 0 to 85% non
Indoor Installation only
These products are intended for use with a UL
Listed power source marked “Class 2” or “LPS”
rated 24VDC, or 48VDC (PoE).
PoE and all interconnected ITE are intended for
intra-building.
Precautionary Designations
WARNING-To Reduce The Risk Of Fire Or
Electric Shock. Do Not Expose This
Apparatus To Rain Or Moistur e.
• AVERTISSEMENT - An de réduire les
risques d'incendie ou de décharge
électrique, évitez d'exposer le
système à la pluie ou à l'humidité.
• Apparatus shall not be exposed to
dripping or splashing and no
objects lled with liquids, such as
vases, shall be placed on the
apparatus.
• L’a ppareil ne doit pas être exposé
à des égouttements et
éclaboussures et aucun Objet
Rempli de liquide, comme vase, ne
doit être placé sur l’appareil.
2 947837
CAUTION: To reduce the risk of electric shock,
Do not remove cover (or back).
No user serviceable parts inside.
Refer servicing to qualified service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
FCC Information
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated
in a commercial environment. This
equipment generates, uses and can radiate
radio frequency energy and if not installed
and used in accordance with the instruction
manual, may cause harmful interference to
radio communications.
Operation of this equipment in a residential
area may cause harmful interference in which
case the user will be required to correct the
interference at his own expense.
INSTALLATION
Operation:
Provide paging via SIP or via a variety of Valcom
managed VoIP products. Integration to custom er
telephone system can be via SIP registration,
FXO port (when used with a Valcom Enhanced
Network Station Port), or FXS port (when used
with a Valcom Enhanced Network Trunk Port).
Mounting
For enhanced protection against static
electrical discharge, it is recommended the
VIP-9815A be installed onto a grounded
electrical box. If surface mounted, ground
the box to local ground.
The VIP- speaker enclosure is designed 9815A
for double gang FD electrical box mounting and
must be within 10 meters of the network switch. 0
Remove the speaker assembly from the packing
container. Using a Phillips screwdriver, remove
the screws securing the front grille to the
speaker housing Remove the screws holding .
the mounting bracket from the back of the
speaker housing. Pre-drilled 13/64” mounting
holes in the mounting bracket are designed to t
a single gang, double gang or octagon outlet
box. If not attaching to an outlet box, use the
mounting bracket a template. Hold the as
mounting bracket in the desired position on the
wall and mark the location of mounting holes.
Depending on wall construction type, prepare the
mounting hole locations on the wall to securely
attach the mounting bracket.
(See Figure 1)
Before installing the speaker housing to the
mounting bracket, route the Ethernet patch cable
from the network switch through to the speaker
the large hole in the back of the mounting
bracket, then through the slot behind the
speaker in the speaker housing.
Align the speaker housing assembly with the
mounting bracket and secure with four screws
into the mounting bracket. Insert the RJ45
connector from the Ethernet patch cable into the
RJ45 jack on the circuit board. After making the
network connection, align the front grille with the
speaker housing and secure with 8 screws.
IMPORTANT SAFETY INFORMATION
CONSIGNES DE SÉCURITÉ IMPORTANTES
1. Read these instructions.
Lisez ces instructions.
2. Keep these instructions.
Conservez ces instructions.
3. Heed all warnings.
Respectez tous les avertissements.
4. Follow all instructions.
Suivez toutes les instructions.
5. Do not use this apparatus near water.
Ne pas utiliser cet appareil près de l'eau.
6. Clean only with dry cloth.
Nettoyer avec un chion sec.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
Ne pas bloquer les ouvertures de ventilation. Installer formément aux instructions du
fabricant.
8. Do not install near any heat sources such as radiators, heat registers, stoves or other
apparatus (including ampliers) that produce heat.
Ne pas installer à proximité de sources de chaleur telles que radiateurs, registres de
chaleur, poêles ou autres appareils (y compris les amplicateurs) produisant de la chaleur.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade and the third prong are provided for your safety. If
the provided plug does not t into your outlet consult an electrician for replacement of the
obsolete outlet.
Ne pas contourner le dispositif de sécurité de la che polarisée ou de mise à la terre. Une
che polarisée possède deux lames dont une plus large que l'autre. Une che de terre a
deux lames et une troisième broche de mise à la terre. La lame large et la troisième
broche sont fournies pour votre sécurité. Si la che fournie ne rentre pas dans votre prise,
veuillez consulter un électricien pour le remplacement de la prise obsolète.
10.Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
11.Only use attachments/accessories specied by the manufacturer.
N'utilisez que des xations / accessoires spéciés par le fabricant.
12. Use only with the cart, stand, tripod, bracket or table specied
by the manufacturer or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
Utilisez uniquement avec le chariot, stand, trépied, support ou table spécié par le
fabricant ou vendu avec l'appareil. Quand un chariot est utilisé, Soyez prudent lorsque
vous déplacez l'ensemble chariot / appareil pour éviter des blessures dues au
renversement.
13. Unplug this apparatus during lightning storms or when unused for a long period of time.
Débranchez cet appareil pendant les orages ou lorsqu'il n'est pas utilisé pendant une
longue période de temps.
14. Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way. Such as when the power supply cord or plug is
damaged, liquid has been spilled, objects have fallen into the apparatus or the
apparatus has been exposed to rain or moisture and does not operate normally or has
been dropped.
Conez toute réparation à un personnel qualié. Une réparation est nécessaire lorsque
l'appareil a été endommagé de quelque façon. Par exemple lorsque le cordon
d'alimentation ou la che est endommagé, du liquide a été renversé, si des objets sont
tombés dans l'appareil ou le appareil a été exposé à la pluie ou à l'humidité et ne
fonctionne pas normalement ou s'il est tombé.
