Side 1/3
1 086 947
CAUTION: To reduce the risk of electric shock,
Do not remove cover.
No user serviceable parts inside.
Refer servicing to qualied service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
ISSUE 1
VIP- AL IP /Outdoor Stealth Horn 9831 Indoor
INTRODUCTION
The VIP-9831AL IP Stealth Horn is a
self-contained paging system which enables voice
paging hundreds of feet from an Ethernet connection.
The VIP-9831AL consists of a horn and
Network/Aud Interface allowing standalone io
capability when used with a SIP enabled telephone
system or can be accessed from a variety of Valcom
managed VoIP products.
SPECIFICATIONS
Access Methods
SIP telephone system
PBX, FXO Port w/VIP-811A
POTS telephone set w/VIP- A 811
PBX, FXS Port w/VIP-821A
Valcom M Cast Page Group
Features
- network connection RJ 45
Network activity LEDs
Power over Ethernet (PoE) 802.3af compatible
Dimensions/Weight
Horn Enclosure:
9.3 "H x 15.0 "W x 5.0 "D
(23.6 cm x 38.1 cm x 12.7 cm)
Wei ght: 5.5 lbs (2.05 kg)
Network Interface
1.62” H x 5.63” W x 3.45” D
(4.11 cm) x (14.30 cm) x (8.76 cm)
W (20.87 cm) with brackets – 8.22”
Weight: 2.10 lbs. (0.95 kg)
Environment
Network Interface:
Temperature: +32 to +104°F (0 to +40°C)
Humi ty: 0 to 85% non-precipitating di
Indoor installation only
Horn Enclosure:
Temperature: -4 to +131°F (-20 to +55°C)
Humidity: 0 to 95% non-condensing
Indoor/Outdoor installation
Power
Via 802.3af Po Ethernet Switch: Class 3 E
Precautionary Designations
INSTALLATION
FCC Information
This equipment has been tested and found to
comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These
l its are designed to provide reasonable im
protection against harmful interference when the
equipment is operated in a commercial
environment. This equipment generates uses
and can radiate radio frequency energy and if not
installed and used in accordance w h the it
instruction manual, may cause harmful
interference to radio communications. Operation
of this equipment in a residential area may cause
harmful interference in which case the user will
be required to correct the interference at his own
expense.
2 086 947
Mounting (Enclosure / Horn)
The horn should be mounted 8 feet above the to 12
oor to allow for best sound distribution. This unit
can be mounted to a sing gang, double gang, le
octagon electrical box or wall. See Figure 1.
1. g a Phillips screwdriver, remove 4 screws Usin
attaching grille to enclosure base.
2. The enclosure base has 4 mounting holes near
each corner. If using those holes for installation,
mount the enclosure base to wall using appropriate
hardware. Continue with step 5.
3. If attaching to an outlet or electrical box, the horn
assembly must be removed for access. Using an
11/32 driver, carefully remove horn bracket ”nut
assembly from enclosure base. Do not remove
horn from bracket. Support the horn to prevent
straining the wire connection to the VM-186 block.
If necessary, the horn wiring may be disconnected
from the VM-186 block by carefully ying up the pr
screw terminal connector from the VM-186 block.
4. Mount the enclosure base to the wall with
appropriate hardware. If the horn wiring was
disconnected from the VM-186 block, reconnect
wiring to the Brown/Brown White terminals of the
VM-186. Reinstall the horn assembly, if it was
removed.
5. Connect a standard ethernet patch cable or other
cable meeting the TIA/EIA 568B andard to the st
RJ45 connector on the VM-186 block. Connect the
other end of the cable to the Signal Output RJ45
socket on the Network Interface.
6. Install grille onto enclosure base.
Network Connection
The VIP- 31AL Network Interface has one 98
RJ-45 NETWORK connector and one RJ-45 Signal
Output connector.
Use a standard Ethernet patch cable to connect the
NETWORK connector of the VIP- 31AL Network 98
Interface to an Ethernet switch.
Status Indicator Lights
The VIP-9831AL has 2 status indication lights located
on network jack:
Green LED: (Link) Indicates Ethernet connection
when illuminated.
Yellow LED: (Activity) Indicator ashes to indicate
network activity.
Signal Connections
Audio output connection is made from the Signal
Output to the -186 Junction Box mounted on the VM
inside of the Horn Enclosure This step is generally .
done during the mounting of enclosure. the
See Figure 2.
If additional wiring length between the Network
Interface and the Horn Enclosure is required, any
standard TIA/EIA 568B extension may be used. See
Figure 2.
Operation
Provide paging from SIP connection or via a variety
of Valcom managed VoIP products. Integration to
customer telephone system can be via SIP
registration, FXO port (with VIP-811A), or FXS port
(with VIP- A 821 ).
Setup
Information specific to your application will need to be
programmed into the VIP-9831AL using a computer.
Setup will be done using the IP Solutions Setup Tool.
The IP Solutions Setup Tool may be downloaded
from the Valcom website at
www.valcom.com/vipsetuptool.
IMPORTANT SAFETY INFORMATION
CONSIGNES DE SÉCURITÉ IMPORTANTES
1. Read these instructions.
Lisez ces instructions.
2. Keep these instructions.
Conservez ces instructions.
3. Heed all warnings.
Respectez tous les avertissements.
4. Follow all instructions.
Suivez toutes les instructions.
5. Do not use this apparatus near water.
Ne pas utiliser cet appareil près de l'eau.
6. Clean only with dry cloth.
Nettoyer avec un chion sec.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
Ne pas bloquer les ouvertures de ventilation. Installer formément aux instructions du
fabricant.
8. Do not install near any heat sources such as radiators, heat registers, stoves or other
apparatus (including ampliers) that produce heat.
Ne pas installer à proximité de sources de chaleur telles que radiateurs, registres de
chaleur, poêles ou autres appareils (y compris les amplicateurs) produisant de la chaleur.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade and the third prong are provided for your safety. If
the provided plug does not t into your outlet consult an electrician for replacement of the
obsolete outlet.
Ne pas contourner le dispositif de sécurité de la che polarisée ou de mise à la terre. Une
che polarisée possède deux lames dont une plus large que l'autre. Une che de terre a
deux lames et une troisième broche de mise à la terre. La lame large et la troisième
broche sont fournies pour votre sécurité. Si la che fournie ne rentre pas dans votre prise,
veuillez consulter un électricien pour le remplacement de la prise obsolète.
10.Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
11.Only use attachments/accessories specied by the manufacturer.
N'utilisez que des xations / accessoires spéciés par le fabricant.
12. Use only with the cart, stand, tripod, bracket or table specied
by the manufacturer or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
Utilisez uniquement avec le chariot, stand, trépied, support ou table spécié par le
fabricant ou vendu avec l'appareil. Quand un chariot est utilisé, Soyez prudent lorsque
vous déplacez l'ensemble chariot / appareil pour éviter des blessures dues au
renversement.
13. Unplug this apparatus during lightning storms or when unused for a long period of time.
Débranchez cet appareil pendant les orages ou lorsqu'il n'est pas utilisé pendant une
longue période de temps.
14. Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way. Such as when the power supply cord or plug is
damaged, liquid has been spilled, objects have fallen into the apparatus or the
apparatus has been exposed to rain or moisture and does not operate normally or has
been dropped.
Conez toute réparation à un personnel qualié. Une réparation est nécessaire lorsque
l'appareil a été endommagé de quelque façon. Par exemple lorsque le cordon
d'alimentation ou la che est endommagé, du liquide a été renversé, si des objets sont
tombés dans l'appareil ou le appareil a été exposé à la pluie ou à l'humidité et ne
fonctionne pas normalement ou s'il est tombé.
