Side 1/6

Got questions or need a repair?

Email help@walrusaudio.com to talk with a real live human about your Walrus gear!

This product comes with a limited lifetime warranty.

Click Here for more info.

This is the Canvas Re-Amp! The Canvas Re-Amp is a passive studio tool designed to send

recorded guitar, drums, vocals, or other recorded tracks from your session through pedals and

effects, or different amp combinations. The Re-Amp makes its appearance to facilitate all-new

ways to experiment with your songs.

Instead of spending precious studio time trying to ﬁnd a good sound before recording, you can

track your audio ﬁrst then re-amp later through any amp and pedal combination you choose!

1. From your DAW, audio track goes in to Canvas Re-Amp XLR or 1/4in jack.

2. Out from Re-Amp into pedals and/or amp sim or mic’d guitar amp.

3. Out from pedals/amp back into DAW.

Keep scrolling for the ultra mega

detailed instructions.

CANVAS

HOW TO USE REAMP

GND Lift: When pushed in, isolates the GND pin on the

XLR input to help reduce hum if present from ground

loops. Leave out for normal operation.

Note: Even with the Canvas Reamp’s transformer

isolation of the input and output signal, there is still

a common ground that may result in ground hum.

When pushed in, lifting the input ground helps

isolate the issue to remove hum from your output.

MUTE: When pushed in, mutes the 1/4” output. Leave

out for normal operation. Even in a studio setting when

tracks are pre-recorded, it can be useful to turn off the

audio track playback going to an amp when adjusting

mic placement, or adding pedals into your signal chain

without having to reach your DAW.

PHASE: When pushed in, inverts the polarity of the

output signal by 180 degrees. Leave out for normal

operation.

HPF: When pushed in, applies a gentle high-pass ﬁlter

at 200 Hz. Leave out for normal ﬂat frequency response

operation. Even with well recorded audio tracks, there

are certain amp and pedal signal chains where you

might need to reduce low frequency rumble in your

signal.

Volume: Control the level of the re-amp signal being sent

back into your pedalboard/amp.

Input XLR Jack: Connect an XLR cable from your audio

interface output to the balanced line-level input.

Input ¼” Jack: Connect a 1/4” cable from your audio

interface output to the balanced line-level input that

operates in parallel with the XLR input.

Output Jack – Connect a 1/4” cable to go through your pedalboard or ampliﬁer

of choice from the instrument-level transformer isolated output.

Phase inversion is useful when:

An amp, pedal or audio track

has an inverted signal that needs

to be ﬂipped.

Reducing phase cancellation

when combined with a mic’d

up amp.

Recording with two amps

simultaneously using two Re-

Amp units, and one amp is out

of phase with the other.

Using multiple microphones to

record an amp, especially room

mics that may capture room

modes causing resonance.

Produkt Specifikationer

Mærke:	Walrus Audio
Kategori:	Ikke kategoriseret
Model:	Canvas Re-Amp
