Side 1/8

3iE Operating Guide V5 © Warmup plc - 2015

INTRODUCTION

Your thermostat’s default screen is the Home Screen. This screen displays important information such as the time,

current oor and air temperature as well as the target set temperature. From this page you can either

access the “MENU” page (press “menu”) or override the current programmed temperature (press “ ” or “ ”).

When using the 3IE thermostat there are some general rules to keep in mind:

(1) Pressing “ ” allows you to conrm your selection

(2) Pressing “ ” takes you back to a previous page in the

menu sequence

(3) Pressing the “ ” and “ ” buttons allow you to change

the setting which is highlighted

(4) Pressing an illuminated button in this group will

allow you to highlight another setting to edit

(5) Pressing an illuminated button in this group will

allow you to select another option in the menu

(6) When this light is illuminated it indicates that power is

being directed to the heaters

Hint: You will often nd a “help” button on pages with

several options. Press the help button for more

information on the options available.

If you do not press any button on the thermostat for 1 minute, then it will go to standby mode. In standby mode the

screen will be dimmed but the thermostat will continue to function as normal. To exit standby mode press

“wake” ( ).

The button on bottom of the 3IE (button 7) is the power button. You can turn o your thermostat and Warmup

underoor heating system by holding down this button for 3 seconds. You can turn it on again by holding it down for

another 3 seconds.

This button can also be used if you get lost in the menus, press the power button on the bottom once to return to the

home screen.

GETTING STARTED

On initial power up the thermostat will guide you through set up procedure for the following:

Operating Guide:

for the Warmup 3iE Programmable Thermostat

• Language

• Time preference and Settings

• Date preference and settings

• Daylight savings

• Temperature Preference

• Theme

• Brightness

• Standby Brightness

• Heating LED

• Audio Feedback

• Floor type

• Set heating target

• Program schedule

• Set energy monitor (You may

skip this section and complete at a

later date )

3iE Operating Guide V5 © Warmup plc - 2015

SETTING YOUR HEATING PROGRAM

Press “menu”, then Press “set program”

Press the programming option that suits your needs.

• “seteachdayseparately”: sets each day of the week with a dierent

program

• “setweekdayandweekend” : sets a program for Monday – Friday

and a dierent program for Saturday and Sunday

• “setalldaysthesame”: one program is set for all the days of the

week

• “setxedtemperature”: set a single temperature to be held

constantly

• “selectapre-set” see explanation in pre-set programs table

Press “up” or “down” to set the start time for the rst of the day.

Note: if you hold a button for several seconds it will scroll continuously until

you release your nger.

To change the target oor temperature, press “oor temp”, you can now press

“up” and “down” to change the target oor temperature.

Note: If you would rather use your thermostat to target an air

temperature, please read the “SETTINGS” section of this document.

If you want the target temperature to change later on in the day then press

“add another period”. You can add up to 10 periods in each day.

Note: It is recommended that you nish your daily program on a low target

temperature so that you save energy overnight.

Note: If you do not need the heating to protect against frost, then you

can scroll down to the bottom of the temperature range to set the target

temperature to “OFF”. With this setting, the heating will not come on

regardless of the temperature.

Once you have set all the desired periods in the day press “done” to go to the

summary page.

This summary page allows you to see the program you have set for this day. If

you need to change something press “edit”. This will take you back to the rst

period of the day. Remember that you will need to add all the periods again.

If you are happy with the program and would like to set the same program for the following day press “copy to ”day

If you are happy with the program but would like to set a dierent program for the following day press “OK”

If you would like to return to the preceding day press “back”.

When you have set a program for all the days including Sunday (or Weekend in the case of Weekday/ Weekend) then

pressing “OK” will enter the schedule and return you to the home screen.

Note: The set temperature for the time before the rst period of the day comes from the night before.

THERMOSTAT MENU SYSTEM

By accessing the main menu you can program your thermostat or make any changes to the settings.

To access the menu press “menu” on the main screen. If the thermostat is in sleep mode, press ”wake”.
