Side 1/6
Food Waste Disposer
Instruction Manual
See insert for specic information about your new disposer
NOTE: This Food Waste Disposer has been designed to operate on 110-120 Volt, 60 Hz
exclusively. Using any other voltage or Hz adversely affects performance.
IMPORTANT: Read all instructions thoroughly. Keep this guide for future reference.
CAUTION: Be sure to review SAFETY INSTRUCTIONS FIRST PERTAINING TO A RISK OF
FIRE, ELECTRICAL SHOCK OR INJURY TO PERSONS before using disposer.
Record important disposer information here
Model Number* Serial Number*
*Above information appears on the label axed to bottom of the disposer. For your convenience,
write down the model and serial numbers prior to installation.
IMPORTANT SAFETY INSTRUCTIONS
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK OR INJURY TO
PERSONS. SAVE THESE INSTRUCTIONS.
WARNING – When using electrical appliances,
basic precautions should always be followed,
including the following:
1. Read all instructions before using the appliance.
2. To reduce the risk of injury, close supervision is
necessary when an appliance is used near children.
3. Do not put ngers or hands into a waste disposer.
4. Turn the power switch to the o position before
attempting to clear a jam or remove an object from the
disposer.
5. When attempting to loosen a jam in a waste disposer,
use a long wooden object such as a wooden spoon or
the wooden handle of a broom or mop.
6. When attempting to remove objects from a waste
disposer use long-handled tongs or pliers. If the
disposer is magnetically actuated, non-magnetic tools
should be used.
7. To reduce the risk of injury by materials that may be
expelled by a waste disposer, do not put the following
into a disposer: clam or oyster shells; caustic drain
cleaners or similar products; glass, china or plastic;
large whole bones; metal, such as bottle caps, tin
cans, aluminum foil or utensils; hot grease or other
hot liquids; whole cornhusks.
8. When not operating a disposer, leave the stopper in
place to reduce the risk of objects falling into the
disposer.
9. DO NOT operate disposer unless splash guard is in
place.
10. For proper grounding instructions see the ELECTRICAL
CONNECTION portion of this manual.
11. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent, or authorized
person in order to avoid hazard.
12. This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
13. Children should be supervised to ensure that they do
not play with the appliance.
IM-USA-111
If you are utilizing a dishwasher, complete the following
procedure. If dishwasher is not to be connected go on to
section 3.
A. Using a blunt instrument (steel punch or wooden
dowel), knock out entire plug (see 2A). Do not use a
screwdriver or sharp instrument. (When knockout
plug falls into disposer, you may remove it or grind it
up when the disposer is used. This will not damage
the disposer in any way, but may take some time to
grind).
B. Connect dishwasher hose (see 2B) using hose
clamp. Make sure all plumbing connections are tight
and in accordance with all plumbing codes and
ordinances. Run water and check for leaks.
Before starting this step, turn o electrical
power at the circuit breaker or fuse box. Unplug
disposer.
If your old mount is the same type as the mount on your
new disposer, just reverse the assembly instructions found
in section 3. If your new mount system is dierent, follow
these instructions:
A. Use a pipe wrench to disconnect drain line where it
attaches to disposer discharge elbow (see 1A).
B. Remove disposer from sink ange by turning mount
ring to the left clockwise (see 1B). If you are unable to
turn the mount ring, tap on one of the extensions from
the ring with a hammer. Some mounting systems have
tubular extensions. Inserting a screwdriver into one
tube will provide additional leverage for turning the
mount ring (see 1B). Some disposers may require the
removal or loosening of nuts from the mount screws
(see 1C). Some disposers may require the removal of
a clamp.
1. REMOVAL OF OLD UNIT
TYPICAL INSTRUCTIONS, YOUR MODEL MAY VARY.
1A 1B 1C 1D
C. To remove remaining mount system from the sink,
loosen mount screws, push mount ring up. Under it is
the snap ring. Use screwdriver to pop o ring (see
1D). Remove mount ring, protector ring and gasket
from sink flange. Some mounts will require the
unscrewing of a large ring holding the sink ange in
place. Pull sink ange up through sink and clean o
old putty from sink.
IMPORTANT: This is a good time to clean out
the trap and drain lines by running a drain auger
or plumber’s snake before installing your new
disposer.
Caution: Be sure to support the disposer while
performing this step or it may fall when the mounting
ring is disconnected from the mounting assembly.
2. DISHWASHER CONNECTION
KNOCK
OUT PLUG
2B
RUBBER
HOSE
DISHWASHER
HOSE
*
AIR GAP
*Air gap may not be required
for all installations. Check local
plumbing codes.
3. INSTALLATION OF MOUNTING ASSEMBLY
2A
READ COMPLETELY BEFORE STARTING
NOTE: Pay close attention to the order of mount assembly parts, as
they have been correctly assembled by the factory (see 3A). Also,
reference the cushion mount detail in illustration 3G for the proper
position of the cushion mount.
NOTE: Try practicing this assembly before you get under the sink to
get the “feel” of how the parts t together.
A. Disassemble mount assembly from disposer by turning mount
ring to the left (clockwise) and remove.
Speed Master Mount System
SUPPORT RING
CUSHION MOUNT
MOUNT RING
SINK FLANGE
SINK FLANGE
GASKET
DRAIN
DISPOSER
WOOD OR
METAL DOWEL
FIBER GASKET
3A
REMOVABLE SPLASH
GUARD
