Side 1/10
SINISTER
AMPLIFIER MANUAL
Congratulations! Thank you for purchasing the Wet Sounds
Sinister
TM
Series amplifier. Wet Sounds Sinister series of marine
amplifiers represents the pinnacle in 12 volt amplifier design.
The Sinister™ amplifiers are the highest power to size amplifiers
anywhere in the world for car or marine use. The Sinister
TM
amplifi-
ers use superior performance circuitry by utilizing Wet Sounds
exclusive full range Class D technology combined with Wet Sounds
MAXED™ Power supply. The MAXED power supply is a patent
pending technology designed to provide high efficiency levels never
thought to be achievable in a mobile audio amplifier. What this
means to you. Less current draw, less strain on the electrical
system, less generated heat. All this results in more play time! The
Sinister amplifiers share one size full cast aluminum chassis for all
models making installation a breeze and the ability to have a clean
install. All Sinister amplifiers feature a fully conformal coated 4
layer pcb board, single side power, speaker and input section, and
top mounted controls with removable cover. Sinister
TM
amplifiers
have a back lit Wet Sounds shield logo with selectable illumination
for red, white or blue that can be mounted horizontally or vertically
for flexible amplifier placement. Other features include high
pass/low pass/full range crossovers, flexible inputs source
selection for single or multiple RCA channel input, RCA pass
through on 4ch and 2ch, and removable speaker plugs that accept
large gauge wire. The Sinister
TM
amplifiers are not only extremely
powerful but also intelligent with a built in microprocessor controller
for overvoltage protection, undervoltage protection, DC offset and
speaker short protection, as well as thermal rollback to ensure
consistent play in the harsh marine environment. One of the most
amazing aspects of the Sinister
TM
amplifiers design is the efficiency
rating. All Sinister amplifiers achieve their efficiency rating at full 4
ohm rated power, the 6 ch is 82%, the 4ch is 84% and the 2ch is
86%. This translates into less current draw and less generated
heat. Over twice that of a conventional class AB amplifier and more
efficiency than any other full range class D amplifier.
WETSOUNDS.COM
SD2
SD4
SD6
ABOUT
1
Full Range Class D Amplifier
We build all Wet Sounds™ products to play at high volumes for extended
periods of time. Your ears however are not designed for high volume
listening. This product can easily generate high volumes that can
permanently damage your hearing. We urge you to limit your exposure to
very high volume sound. You may also find your state has laws governing
the volume of an audio system. Please be aware of all local and state
laws in your area.
A Properly tuned and operated audio system will deliver years of
enjoyment when used properly.
2 3WARNING
Wet Sounds™ Marine Amplifiers are designed for easy installation in
your boat. To ensure proper installation of your new purchase please
follow all the suggestions listed below.
If you do not have experience with marine electrical and mechanical
systems, contact a professional installer. Paying a qualified installer is
almost always cheaper than paying a dealership to repair your boat.
The Laws of Nature
Your amplifier does NOT make power; it converts power, or current, from
your boats electrical system and converts it into high power musical
energy. If the amp can’t get all the power it needs it will not produce its
full output. Your Wet Sounds™ amplifier will produce full output longer
than other amplifies on the market today. Should your voltage or current
drop too low the amplifier will drop below the rated output. Make sure
your boats charging system is in good working order. Any high perfor-
mance audio amplifier will increase the demand on your alternator and
battery. If you are unsure have you charging system checked system
testing by a professional technician.
INSTALLATION INSTRUCTIONS
The amplifier must be securely mounted to a solid surface. Please select
a dry location to mount your amplifier. All Wet Sounds products are
designed to operate in humid environments however direct contact with
water can damage the electronics. Do not mount the amplifier to any
area that may have excessive vibration (like a subwoofer enclosure).
Position the amplifier in an area that receives sufficient airflow for
proper heat dissipation.
LOCATING THE AMPLIFIER
SUPPLYING ENOUGH POWER
**Always keep the signal cable and the power cables separated to
prevent the possibility of inducing noise into the system**
Carefully run the power and the signal cables through the boat. Always
keep all the wire tight and tied down to prevent the power wire from
shorting and reduce the risk of fire. A 4 AWG or larger wire should be
used for power and ground connections. We recommend a fuse to be
installed on the power wire within 18 inches of the battery for safety.
RUNNING THE WIRING CABLES
