Side 1/2

5 Year Warranty – See www.tripodhead.com/warranty.cfm for complete details

Wimberley, Inc. - - - Phone: 1 434 529 8385

1750 Broadway St Toll Free: 1 2746 -888-665-(USA & Canada)

Charlottesville, VA

22902 USA www.tripodhead.com info@tripodhead.com

Made in USA

Dimensions: (L x W x H): 2” x 0.65” x 13.5”

Weight: 3.4 oz (95g)

Arched Recess

reliably grip cylindrical

objects such as small

flashlights and branches.

Foam Jaw Inserts

Grip delicate objects without damage.

Thumbscrew Turn the Nylon thumbscrew to open or close the jaws of the clip.

Compared to typical spring activated clips, thumbscrew activated clip jaws allow -

for more finesse when holding delicate objects, as well as much higher maximum

clamping force when desired.

The Plamp Clip

Clip Body

The clip is custom designed to hold

anything from the most delicate plant stems

to heavy reflectors and diffusers. It is made of

nearly unbreakable ST Nylon

Jaw opening band

This elastomer band puts tension on the clamp s moving ’

jaw so that it opens when you loosen the thumbscrew. It

is made of weather/UV resistant EPDM (the same mate-

rial that industrial rubber roofs are made of)

Special notches in the clip’s jaws grab the steel rim on reflectors and

diffusers, providing a secure, slip-free attachment (applies to typical cloth

reflectors/diffusers with steel perimeter hoop). This new feature is a drastic

improvement over other clips currently on the market.

The firm grip allows you to make precise adjustments to the angle of a reflector.

You can even hold diffusers cantilevered straight out above your subject

Important Feature

Reflector/Diffuser Notches

Package Contents:

The Plamp Extension Rod (Qty 1)

PP-210 Extension Rod

Reflector Support:

Two Plamp Extension Rods can be used to act much like a kickstand

to support a large reflector directly on the ground.

Reconnecting the ball and socket joints:

If the articulating joints are bent beyond the normal

range of motion it is possible for them to pop apart.

Fixing this is simply a matter of popping the segments

back together. If this is exceptionally difficult, heat

the socket with near boiling water to make -

re- attachment easier.

Fine Movement Abilities

The Plamp Extension Rod is an add on accessory -

for the Plamp. It is intended to make capturing

and moving your subject easier with fine

movement capability and extended reach.

Acquire:

The Rod extension makes acquiring your subject

easier. The Plamp is positioned to roughly support

the item in question and the extension rod is slid

forward and backward for fine tuned positioning-

of the Plamp clip on the subject.

Subject Control:

Once Acquired, the Extension Rod enhances

your control of the subject allowing deliberate translation

and rotation of the subject. This is beneficial in most situations,

but can be especially useful when working with fragile subjects

where spring back of the Plamp arm could cause damage or

move the subject from the desired positioning.

Extend:

Lastly the Rod extension can be used to extend the reach of the

Plamp. The rod is made of carbon fiber to achieve very high

rigidity at a fraction of the weight of other materials. It can be

used in series or mounted in a perpendicular fashion.

Extending in series:

The Plamp II or ground Plamp may be extended by placing the end of the

extension rod in the small clip as shown above. This method is slightly less

secure than perpendicular gripping but should be sufficient for most applications.

Please visit our site for more in depth information -

about the Extension Rod including a video tutorial.

www.tripodhead.com/products/plamp rod.cfm-

Video

Available

7” (175 mm)

12” (300 mm)

0.35” (8.9 mm) 73°

Thank you for your interest in Wimberley products. If you have any questions or comments feel free to contact us.
